Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock

Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock

Model: STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX

Supplier: Honeywell

Categories: Pressure Transmitters

After sales service. If you have any questions, click here.

PRODUCT DESCRIPTION

Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock




Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock




Product Overview of Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


SmartLine® ST800 Differential Pressure Transmitters bring smart technology to a wide spectrum of measurement applications ranging from furnace combustion airflow rate to hydrostatic tank gauging. The transmitters can be used with any primary flow element to provide proven, repeatable flow measurement.
You can also select and configure your SmartLine Pressure Transmitter using the Application and Validation Tool.



Product Introduction of Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


Part of the SmartLine® family of products, the STD800 is a high performance differential pressure transmitter featuring piezoresistive sensor technology. By combining differential pressure sensing with on chip static pressure and temperature compensation the STD800 offers high accuracy and stability over a wide range of application pressures and temperatures. The SmartLine family is also fully tested and compliant with Experion® PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.



Best in Class Features of Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


*  Accuracies up to 0.035% of span standard & 0.025% of span optional
*  Stability up to 0.01% of URL per year for 15 years
*  Automatic static pressure & temperature compensation
*  Rangeability up to 400:1
*  Response times as fast as 90ms
*  Multiple local display capabilities
*  External zero, span, & configuration capability
*  Polarity insensitive electrical connections
*  Comprehensive on-board diagnostic capabilities
*  Integral Dual Seal design for highest safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
*  World class overpressure protection
*  Full compliance to SIL 2/3 requirements.
*  Modular design characteristics
*  Available with additional 15-year warranty
*  Plugged Impulse Line Detection Option
*  Dual/Triple Calibration Option (HART & Fieldbus only)




What Is It?  Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


ST800 Differential Pressure Transmitters are ideal for critical process loops and high-value applications such as custody transfer, and energy and material balances. Four models are available with the following ranges:


STD810         -10 to 10 inH2O                  -25 to 25 mbar
STD820         -400 to 400 inH2O              -996 to 996 mbar
STD830         -100 to 100 psi                    -6.9 to 6.9 bar
STD870         -3,000 to 3,000 psi              -207 to 207 bar



Specification of Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


Manufacturer : Honeywell
Product Type : STD800 Differential Pressure Transmitter
Measurement Range
URL : 400/(1000)
LRL : -400/(-1000)
Max Span : 400/(1000)
Min Span :1.0 (2.5)
Units : " H2O (mbar)
Process Wetted Heads & Diaphragm Materials : E
Process Head Material : 316 Stainless Steel
Diaphragm Material : 316 Stainless Steel
Fill Fluid : 1 = Silicone Oil 200
Process Connection : A = None None (1/4" NPTF female thread Std)
Bolt/Nut Materials : C = Carbon Steel
Vent/Drain Type/Location : 1
Head Type : Single Ended
Vent Type : None
Location : None
Vent Material : None

Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


Gasket material : A = Teflon® or PTFE (Glass Filled)
Static Pressure : S = Standard Static Pressure - 4500 psig (310 bar) except STD810: 50 psi (3.5 bar)
Head/Connect Orientation : 1 = Standard, High Side Left, Low Side Right2 / Std Head Orientation
Approvals : 0 = No Approvals Required
Electronic Housing Material & Connection Type : A
Material : Polyester Powder Coated Aluminum
Connection : 1/2 NPT
Lightning Protection : None
Output/Protocol : H
Analog Output : 4-20 mA dc
Digital protocol : HART Protocol
Customer Interface Selections : B
Indicator : Basic
Ext Zero, Span & Config Buttons : None
Languages : EN
Application Software : 1 = Standard Diagnostics
Output Limit, Fail safe & Write Protect Settings : 1
Write protect : Disabled
Fail mode : High> 21.0mAdc
High & Low Output Limits : Honeywell Std (3.8 - 20.8 mAdc)
General Configuration : S = Factory standard

Honeywell STD820-E1HS4AS-1-C-BHC-13S-B-31A0-F1,TP,FE,FX SmartLine Differential Pressure Transmitters STD820 Transmitters In Stock


Accuracy and Calibration : A
Accuracy : Standard
Calibrated Range : Factory Std
Calibration Qty : Single Calibration
Mounting Bracket : 6
Bracket Type : Flat Bracket
Material : 304 SS
Customer Tag : 0 = No customer tag
Unassembled Conduit Plugs & Adapters : A0 = No Conduit Plugs or Adapters Required
