Model: SD55

Supplier: MTL

Categories: Surge Protection

After sales service. If you have any questions, click here.

PRODUCT DESCRIPTION

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Product Features of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL SD range
Ultra-slim user-friendly devices for protecting electronic equipment and systems against surges on signal and I/O cabling
• Range of ATEX Certified intrinsically safe surge protectors
• Ultra-slim space-saving design;easy installation
• Multistage hybrid protection circuitry – 20kA maximum surge current
• Range of voltage ratings – to suit all process I/O applications
• High bandwidth, low resistance, RTD, PSTN and 3-wire transmitter versions available

• 10 year product warranty


Overview of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


The SD range is a series of surge protection devices combine unparalleled packing densities, application versatility, proven reliable hybrid circuitry, simple installation and optional ‘loop disconnect’ facilities – features which make the range the ultimate surge protection solution for process equipment, I/O systems and communications networks.


The exceptionally high packing densities are the consequence of an ultra slim ‘footprint’ for individual modules which can thus‘double-up’ as feedback terminals. Each module provides full hybrid surge protection for 2 and 3 wire loop protection.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Modules with a comprehensive range of voltage ratings cover all process related signals such as RTDs, THCs, 4 to 20mA loops, telemetry outstations, shut-down systems and fire and gas detectors.


Optional ‘loop disconnect’, is a feature which allows commissioning and maintenance to be carried out without removal of the surge protection device. This facility is provided by the SD07, SD16, SD32 and SD55 units. In addition, a third connection on the field and safe side of the protector is provided in order to terminate screens safely


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

For three wire applications the specially designed SDRTD (Resistance Temperature Detector) and the SD32T3, (for separately powered 4-20mA loops) provide full 3-wire protection in a single compact unit. The recommended choice for the protection of 3-wire pressure transducers on low power circuits is the SD07R3.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

For higher bandwidth applications, the SDR range has been developed to meet the demands of today’s highest speed communication systems.


120V and 240V AC versions are available for I/O and power supplies up to three Amps of load current and telephone networks can be protected by the SDPSTN.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


One simple manual operation clamps modules securely onto DIN rail, which automatically provides the essential high-integrity earth connection.


‘Top-hat’ (T-section) DIN rail is generally suitable for mounting SD modules although for adverse environments, a specially-plated version is available. A comprehensive range of mounting and earthing accessories can also be supplied


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Analogue inputs (high-level)
2-wire transmitters, 4-20mA, conventional and smart
The SPDs recommended for use with‘conventional’ and ‘smart’ 4-20mA transmitters (fed by a well-regulated supply) are the SD32 and SD55, the choice depending upon the maximum working voltage of the system (32V and 55V respectively). The diagram illustrates a prime example of an application for which the fuse/disconnect facility is particularly useful, however, both models are available in ‘X’ versions without the optional fuse/disconnect feature.


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Analogue inputs (low-level)
RTDs
These applications are best served using the SDRTD. For optimum accuracy, the energising current should be chosen to ensure the voltage across the RTD does not exceed 1V over the full measurement range. When using a PT100 device, we recommend an energising current of 1mA.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Photocells, THCs, mV sources and turbine flowmeters

The SD07 or SD16 (depending upon the operational voltage) are the favoured choices for this application. SD07X and SD16X are also suitable.


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Analogue outputs
Controller outputs (I/P converters)

For this application, the recommendations are the SD16, SD32 and SD55 (and the equivalent‘X’ versions), the final choice depending upon the operating voltage.


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Digital (on/off) inputs
Switches
Suitable SPDs for switches include the SD07, SD16, SD32 and SD55 modules – the choice depending upon the operating voltage of the system. The ‘X’ versions of these are also suitable.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Digital (on/off) outputsAlarms, LEDs, solenoid valves, etc
Alarms, LEDs, solenoid valves, etc
The recommended choice for this application is the SD32 or SD32X.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Telemetry (PSTN)
Telemetry outstations
The SDPSTN has been designed specifically for the protection of signals transmitted on public switched telephone networks.

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

AC supplied equipment
PLC, I/O systems
For systems on 110-120V ac, the SD150X is the recommended choice and for 220-240V ac systems, the SD275X is recommended.


Technical Data of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


All figures typical at 77°F (25°C) unless
otherwise stated
Protection
Full hybrid line to line
Each line to screen/ground
Max discharge surge current (Imax) (8/20µs)
20kA (8/20µs)
6.5kA (SD150X and SD275X only)

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Nominal discharge surge current (isn)  3kA (8/20µs)
Lightning impulse current (Iimp) (10/350µs)
2.8kA
1.0kA (SD150X and SD275X only)
Response time  <1ns
RTD resistance range (SDRTD) 10 to 1500

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Degradation accuracy (SDRTD at 1mA)
0.1% (RTD resistance > 100 )
0.1W (RTD resistance < 100 )
Ambient temperature
–40°C to +80°C / -40°F to 176°F storage
–40°C to +80°C / -40°F to 176°F working
For IS working applications:
Pi = 1.0W (–30°C to +75°C / -22°F to 167°F)
Pi = 1.2W (–30°C to +60°C / -22°F to 140°F)
Pi = 1.3W (–30°C to +40°C / -22°F to 104°F)

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Humidity  5 to 95% RH (non-condensing)
Category tested A2, B2, C1, C2, C3
Overstressed fault mode in=3kA
12kA
9kA (SD150X and SD275X only)
Impulse durability (8/20µs)
10kA
6.5kA (SD150X and SD275X only)
Terminals  2.5mm2(12 AWG)
Mounting  T-section DIN-rail 35 x 7.5 or 35 x 15mm rail(1.38” x 0.3” x 0.6”)

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Weight 70g approximately (2.5oz)
Case flammability  UL94 V-2

AC durability   1Arms, 5T


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

Service conditions
80kPa - 160kPa
5% - 95% RH
EMC compliance
To Generic Immunity Standards,
EN 61326-1, part 2 for industrial
environments
R&TTE compliance
EN 61326-1, EN 41003 : 1999
EN 60950 - 1 : 2006
(not applicable to SD150X and SD275X)
LVD compliance
SD150X & SD275X
EN 60950 - 1 : 2006, EN 61010 : 2010
SDPST
EN 41003 : 1999
IEC compliance
EN 61643-21:2001
ANSI/IEEE testing
C62.41-1-2002
C62.41-2-2002

C62.45-2002


Ordering Models of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL SD16R
SD series
SD07
SD16
SD32
SD55
SD07R
SD16R
SD32R
SD55R
SD07X
SD16X
SD32X
SD55X
SD32T3
SD07R3
SD16R3
SD32R3
SD55R3
SDRTD
SDPSTN
SD150X

SD275X


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL7706+
MTL7707+
MTL7707P+
MTL7710-
MTL7710+
MTL7710P+
MTL7715+
MTL7715P+
MTL7722-
MTL7722+
MTL7728-
MTL7728+
MTL7728AC
MTL7728P+
MTL7729P+
MTL7741
MTL7742
MTL7743
MTL7744
MTL7745
MTL7751AC
MTL7755AC
MTL7756AC
MTL7758-
MTL7758+
MTL7760AC
MTL7761AC
MTL7761PAC
MTL7764-
MTL7764+
MTL7764AC
MTL7765AC
MTL7766AC
MTL7766PAC
MTL7767+
MTL7768+
MTL7772AC
MTL7778AC
MTL7779+
MTL7787-
MTL7787+
MTL7787P+
MTL7788+
MTL7788R+
MTL7789+
MTL7796-
MTL7796+
MTL7798

MTL7799


Ordering Codes of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL7760AC MTL7760AC MTL7755AC MTL7756AC MTL7764AC MTL7761AC MTL7766PAC MTL7728+ MTL7728P+ MTL7729P+ MTL7787+ MTL7787P+ MTL7728+ MTL7728P+ MTL7729P+ MTL7764+ MTL7767+ MTL7765AC MTL7778AC MTL7728- MTL7799 MTL7706 MTL7707+ MTL7707P+ MTL7741 MTL7742 MTL7743 MTL7744 MTL7745 MTL7787+ MTL7787P+ MTL7788+ MTL7788R+ MTL7789+ MTL7706+ MTL7707+ MTL7707P+ MTL7741 MTL77742 MTL7743 MTL7744 MTL7745 MTL7798


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL5011B , upgraded model: MTL5511
MTL5018 , upgraded model: MTL5516C
MTL5041 , upgraded model: MTL5541
MTL5042 , upgraded model: MTL5541
MTL5043 , upgraded model: MTL5544
MTL5044 , upgraded model: MTL5544
MTL5045 , upgraded model: MTL5546
MTL5046 , upgraded model: MTL5546
MTL5074 , upgraded model: MTL5575
MTL7787+
MTL5022 , upgraded model: MTL5522

MTL5031 , upgraded model: MTL5531 or MTL5533


Part Number & Description of MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


Digital Input    MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4501-SR     1ch DI failsafe solid-state output + LFD alarm
MTL4504          1ch DI relay output + LFD alarm + phase reversal
MTL4510          4ch DI solid-state output
MTL4510B        4ch DI multifunction solid-state output
MTL4511          1ch DI relay output
MTL4513          2ch DI solid-state output
MTL4514/B       1ch DI relay output + LFD alarm
MTL4516          2ch DI relay output
MTL4516C        2ch DI with changeover relay output

MTL4517          2ch DI relay output + LFD alarm



Digital Output  MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4521          Loop powered solenoid driver
MTL4521L         Loop powered solenoid driver IIC
MTL4523          Solenoid driver with LFD
MTL4523L         Loop powered solenoid driver + LFD
MTL4523R         Solenoid driver with LFD
MTL4523V/VL    Solenoid/Alarm driver with voltage control
MTL4524           Switch operated solenoid driver
MTL4524S         Switch operated solenoid driver, 24V override
MTL4525           Switch operated solenoid driver low power

MTL4526           2ch switch operated relay


Analogue Input   MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4541           1ch 2/3 wire Transmitter repeater
MTL4541A         1ch Transmitter repeater, passive input
MTL4541AS       1ch Transmitter repeater, passive input, current sink
MTL4541B          MTL4041B replacement
MTL4541P          MTL4041P replacement
MTL4541S          1ch 2/3 wire Transmitter repeater, current sink
MTL4544            2ch 2/3 wire Transmitter repeater
MTL4544A          2ch Transmitter repeater, passive input
MTL4544AS        2ch Transmitter repeater, passive input, current sink
MTL4544B          MTL4044 replacement
MTL4544D          2/3 wire transmitter repeater, dual output

MTL4544S          2ch 2/3 transmitter repeater, current sink


Analogue Output  MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4546            1ch 4-20mA smart isolating driver + LFD
MTL4546C          1ch 4-20mA smart isolating driver + oc LFD
MTL4546Y          1ch 4-20mA smart isolating driver + oc LFD
MTL4549            2ch 4-20mA smart isolating driver + LFD
MTL4549C          2ch 4-20mA smart isolating driver + oc LFD

MTL4549Y          2ch 4-20mA smart isolating driver + oc LFD



Temperature Input   MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4575            1ch Temperature converter with alarm
MTL4576-RTD     2ch Temperature converter, RTD
MTL4576-THC     2ch Temperature converter, THC

MTL4581            1ch mV/THC isolator for low-level signals



Pulse and Vibration   MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived
MTL4531            1ch vibration probe interface
MTL4532            1ch pulse isolator, digital or analogue output

MTL4533            2ch vibration probe interface


Fire and Smoke   MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL4561            2ch loop-powered, for fire and smoke detectors


General             MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived
MTL4599             Dummy isolator

MTL4599N           General purpose feed-through module


MTL4500 Series Barriers     MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514 (B)(D), MTL4516, MTL4516C, MTL4517, MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524, MTL4524S, MTL4525, MTL4526, MTL4531, MTL4532, MTL4533, MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4541T, MTL4544, MTL4544A, MTL4544AS, MTL4544B, MTL4544D, MTL4544S, MTL4546, MTL4546C, MTL4546S, MTL4546Y, MTL4549, MTL4549C, MTL4549Y, MTL4561, MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL5501-SR, MTL5510, MTL5510B, MTL5511, MTL5513, MTL5514, MTL5514D, MTL5516C, MTL5517, MTL5521, MTL5522, MTL5523, MTL5523V, MTL5523VL, MTL5524, MTL5525, MTL5526, MTL5531, MTL5532, MTL5533, MTL5541, MTL5541A, MTL5541AS, MTL5541S, MTL5544, MTL5544A, MTL5544AS, MTL5544D, MTL5544S, MTL5546, MTL5546Y, MTL5549, MTL5549Y, MTL5561, MTL5575, MTL5576-RTD, MTL5576-THC, MTL5581, MTL5582 MTL5544D MTL5575 MTL5516C MTL4541 MTL5541 MTL5546Y ICC212 IOP32 IOP32D


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL7706+ MTL7707+ MTL7707P+ MTL7710+ MTL7715+ MTL7715P+ MTL7722+ MTL7728+ MTL7728- MTL7728AC MTL7728P+ MTL7729P+ MTL7741 MTL7742 MTL7743 MTL7744 MTL7745 MTL7755AC MTL7756AC MTL7758- MTL7758+ MTL7760AC MTL7761AC MTL7761PAC MTL7764+ MTL7764AC MTL7765AC MTL7766AC MTL7766PAC MTL7767+ MTL7778AC MTL7779+ MTL7787+ MTL7787- MTL7787P+ MTL7788+ MTL7788R+ MTL7789+ MTL7796- MTL7796+ MTL7798 MTL7799


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL705+ MTL706+ MTL707+ MTL707P+ MTL708+ MTL710+ MTL710AC MTL710P+ MTL715+ MTL715P+ MTL722+ MTL722P+ MTL728+ MTL728AC MTL728P+ MTL729P+ MTL751AC MTL755AC MTL758+ MTL760AC MTL761AC MTL761PAC MTL764+ MTL764AC MTL765AC MTL766AC MTL766PAC MTL767+ MTL768+ MTL772AC MTL778AC MTL779+ MTL786+ MTL787+ MTL787S+ MTL787SP+ MTL788+ MTL788R+ MTL791 MTL796+ MTL799


ICC     MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


ICC201-I1-O1 ICC201-I1-O2 ICC201-I2-O1 ICC201-I2-O2 ICC201-I2-O2 ICC211-I1-O2 ICC211-I2-O1 ICC211-I2-O2 ICC212 ICC221

 ICC222 ICC241-T3 ICC241-T1 ICC241-T2 ICC301-I9-O1 ICC312 ICC316-T2 ICC317-T2-LFD ICC352-T1 ICC352-T2 ICC441 ICC446


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4510 MTL4510B MTL4511 MTL4513 MTL4514 MTL4514B MTL4514D MTL4516 MTL4516C MTL4517 MTL4521 MTL4521L MTL4523 MTL4524R MTL4523L MTL4524 MTL4524S MTL4524 MTL4526 MTL4531 MTL4532 MTL4541 MTL4541A MTL4541B MTL4544 MTL4544A MTL4544D MTL4544S MTL4546Y MTL4549 MTL4549Y MTL4546 MTL4573 MTL4575 MTL4576-RTD MTL4576-THC MTL4581 MTL4599 MTL4599N

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5514D MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5523V MTL5523VL MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5533 MTL5541 MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S MTL5546 MTL5546Y MTL5549 MTL5549Y MTL5561 MTL5573 MTL5575 MTL5576-RTD MTL5576-THC MTL5581 MTL5582 MTL5599 MTL5314 MTL5501-SR MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5533 MTL5541 MTL5541A MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4501-SR MTL4504 MTL4510 MTL4510B MTL4511 MTL4513 MTL4514 MTL4516 MTL4516C MTL4517 MTL4521 MTL4521L MTL4523 MTL4523R MTL4523L MTL4524 MTL4524S MTL4525 MTL4526 MTL4531 MTL4532 MTL4533 MTL4541 MTL4541A MTL4541AS MTL4541B MTL4541P MTL4541S MTL4544 MTL4544A MTL4544AS MTL4544B MTL4544D MTL4544S MTL4546 MTL4546C MTL4546Y MTL4549 MTL4549C MTL4549Y MTL4561 MTL4575 MTL4576-RTD MTL4576-THC MTL4599 MTL4599N


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL7706+ MTL7707+ MTL7707P+ MTL7710+ MTL7715+ MTL7715P+ MTL7722+ MTL7728+ MTL7728- MTL7728AC MTL7728P+ MTL7729P+ MTL7741 MTL7742 MTL7743 MTL7744 MTL7745 MTL7755AC MTL7756AC MTL7758- MTL7758+ MTL7760AC MTL7761AC MTL7761PAC MTL7764+ MTL7764AC MTL7765AC MTL7766AC MTL7766PAC MTL7767+ MTL7778AC MTL7779+ MTL7787+ MTL7787- MTL7787P+ MTL7788+ MTL7788R+ MTL7789+ MTL7796- MTL7796+ MTL7798 MTL7799

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL705+ MTL706+ MTL707+ MTL707P+ MTL708+ MTL710+ MTL710AC MTL710P+ MTL715+ MTL715P+ MTL722+ MTL722P+ MTL728+ MTL728AC MTL728P+ MTL729P+ MTL751AC MTL755AC MTL758+ MTL760AC MTL761AC MTL761PAC MTL764+ MTL764AC MTL765AC MTL766AC MTL766PAC MTL767+ MTL768+ MTL772AC MTL778AC MTL779+ MTL786+ MTL787+ MTL787S+ MTL787SP+ MTL788+ MTL788R+ MTL791 MTL796+ MTL799


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


SD07 SD16 SD32 SD55 SD07X SD16X SD32X SD55X SD150X SD275X SD07R SD16R SD32R SD55R SD07R3 SD16R3 SD32R3 SD55R3 SDRTD SD32T3 SDPSTN SLP07D SLP16D SLP32D MA15/D/1/SI MA15/D/2/SI MA15/D/1TT/SI MA15/D/2TT/L MA30/D/1/SI MA30/D/2/SI MA30/D/3/SI MA05/D/1 MA05/D/2 MA10/D/1 MA10/D/2 MA05/SC/1 MA05/SC/2 MA10/SC/1 MA10/SC/2 MA05/I/1 MA05/I/2 MA10/I/1 MA10/I/2


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


TP48-N TP48-N-NDI TP48-I TP48-I-NDI TP48-G TP48-G-NDI TP48-3-N-NDI TP48-3-I-NDI TP48-3-G-NDI TP48-3-N TP48-3-I TP48-3-G TP48-4-N-NDI TP48-4-I-NDI TP48-4-G-NDI TP48-4-N TP48-4-I TP48-4-G ICC201-I1-O1 ICC201-I1-O2 ICC201-I2-O1 ICC201-I2-O2 ICC201-I2-O2  ICC211-I1-O2 ICC211-I2-O1 ICC211-I2-O2 ICC212 ICC221 ICC222 ICC241-T3 ICC241-T1 ICC241-T2 ICC301-I9-O1 ICC312 ICC316-T2 ICC317-T2-LFD ICC352-T1 ICC352-T2 ICC441 ICC446


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL5011B MTL5012 MTL5012S MTL5014 MTL5015 MTL5017 MTL5018 MTL5018AC MTL5021 MTL5021-SR MTL5022 MTL5022-SR MTL5023 MTL5024 MTL5025 MTL5025-SR MTL5031 MTL5032 MTL5040 MTL5041 MTL5042 MTL5042-SR MTL5043 MTL5044 MTL5045 MTL5046 MTL5049 MTL5051 MTL5061 MTL5061-SR MTL5074 MTL5074-RTD MTL5081 MTL5082 MTL5099 MTL5314 MTL5344 MTL5349 MTL5531-111LI MTL5531-115LI MTL5991 MPA5500

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL5501-SR MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5514D MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5523V MTL5523VL MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5532-R MTL5533 MTL5541 MTL5541A MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S MTL5546 MTL5546Y MTL5549 MTL5549Y MTL5561 MTL5573 MTL5575 MTL5575-R MTL5576-RTD MTL5576-THC MTL5581 MTL5582 MTL5599


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5514D MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5523V MTL5523VL MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5533 MTL5541 MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S MTL5546 MTL5546Y MTL5549 MTL5549Y MTL5561 MTL5573 MTL5575 MTL5576-RTD MTL5576-THC MTL5581 MTL5582 MTL5599 MTL5314 MTL5011B MTL5014 MTL5022 MTL5024 MTL5031 MTL5042 MTL5042 MTL5046 MTL5074 MTL5082


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived


MTL4510 MTL4510B MTL4511 MTL4513 MTL4514 MTL4514B MTL4514D MTL4516 MTL4516C MTL4517 MTL4521 MTL4521L  MTL4523 MTL4524R MTL4523L MTL4524 MTL4524S MTL4524 MTL4526 MTL4531 MTL4532 MTL4541 MTL4541A MTL4541B MTL4544 MTL4544A MTL4544D MTL4544S MTL4546Y MTL4549 MTL4549Y MTL4546 MTL4573 MTL4575 MTL4576-RTD MTL4576-THC MTL4581 MTL4599 MTL4599N

MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived

HAZ1-3 HAZ4-6 SAF1-3 SAF4-6 SAF7-9 SAF10-12 PWR5000 HAZ-CJC TAG57 TGL57 PB-8T PB-16T PB-24T PB-32T IMB57 MLTHR2 ERB57S ERB57O ERL7 MLETM7 MS010 TH5000 PCS45 PCL45USB DX070 DX170 BMK08 BMK16 DMK01 DMP08 DVK16 MCC45 MCK45 SCK45 MPL01 PCL45USB PCS45 CPM08 CPM16U CPM32U CPS04 CGS08 CPS08 CPS16 CPS16C-250 CPS24 CPS16C BPS04 BPS08 ERK04 ERK06 ERK08 ERK16 HMP24 SVK16 TSK08 TSK16 TSK24


MTL SD55 Surge Protection Devices SPD SD55 Safe Surge Protectors Arrived




We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.


We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,

MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.


Contact:
HONGKONG XIEYUAN TECH CO., LIMITED
Email:becky@hkxytech.com   Web:www.hkxytech.com
Mobile:+86-15972186287(Whatsapp & Wechat)


Related Products

CONTACT ADDRESS

UNIT A1.9/F SILVERCORP INTERNATIONAL TOWER707-713 NATHAN ROAD MONGKOK KOWLOON HONGKONG

WRITE TO US

becky@hkxytech.com

CALL US

+86 027-8580 6199

MOBILE PHONE

+86 15972186287
