GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Model: DPI611-07G

Supplier: Products

Categories: GE

After sales service. If you have any questions, click here.

Need a Quote?Online Message

PRODUCT DESCRIPTION

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Overview of GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Druck DPI 612 Flex Series

Range Flexible Pressure Calibrators

These fully self-contained pressure test and calibration systems have interchangeable pressure modules for flexible ranging, generate pneumatic or hydraulic pressures, measure process signals and supply loop power. They provide all the convenience of the Druck DPI 610/615 series with significantly improved generation capabilities, higher

accuracy and simplified touch screen operation.

Features of GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

• The complete pressure calibration tool: pump, measure, analyse

• Best in class Pressure accuracy

• Fast and dependable from vacuum to 1000 bar/15000 psi

• Easy to use touch screen

• No in-the-field leaks with quick-to-fit pressure adaptors & hoses

Description of GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Druck DPI 612 Flex Series

Range Flexible Pressure Calibrators

The Druck DPI 612 Flex series is the fifth generation in the DPI 600 family, which was first introduced in

1984. The DPI 600 family revolutionized test and calibration by providing all the tools for pressure generation and signal measurement in self-contained portable packages. The DPI 600 soon became the industry workhorse and today it is simply known as

the “Druck.”

Building on the technical legacy and more than three decades of experience in pressure sensor development and calibration, the DPI 612 Flex series provides all the convenience and reliability of a true “Druck,” yet offers interchangeable pressure modules, higher accuracy and significantly improved pressure generation.

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Dependable and efficient pressure generation

Three model choices to generate from 95% vacuum to 1000 bar/ 15000 psi

• 20 bar/300 psi in 30 seconds

• 100 bar/1500 psi without gas bottles and regulators

• 1000 bar/15000 psi hydraulic pressure

Flexible pressure ranging – swap the module not the instrument

• Re-range for different applications and expand the system over time

• 31 interchangeable pressure modules from 25 mbar/10 inH20 to 1000 bar/15000 psi

• Accuracy from 0.005% FS

• “Hot swap” without tools, seals or cables

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

For convenience and to protect your budget, the pressure modules are fully interchangeable between the DPI 612 Flex series and the DPI 620 Genii multifunction calibrator / communicator series.

Leak free, field serviceable pressure connections

• “Quick-to-fit” pressure adaptor/hose system requires no tools or sealing

Simple touch screen operation

• Application DASHBOARD, quick TASK selection and FAVOURITES storage

• Fast, three touch set-up for any application

• Calculates PASS/FAIL errors, documents results and interfaces with calibration software

Technical Data of GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Display Size: 110 mm (4.3in) diagonal. 480 x 272 pixels. LCD colour display with touch screen

Internal memory 8Gb (nominal) user memory for automated procedures, calibration data and data log files

Languages English (default), Chinese, Dutch, French, German, Italian, Japanese, Korean, Portuguese, Russian,

Spanish

Pressure units

25 pressure units are available for the user to select (country restrictions may apply)

Calibration certificates are provided with data in three pressure units based on bar, psi (or inH2O

or inHg depending on range) and Pa

Operating temperature -10o to 50oC (14o to 122oF). 0o to 40oC (32o to 104oF) when powered from optional mains adaptor

IO620-PSU. For DPI 612 hFlexPro +4 to +50°C (39 to 122°F) with water as media

Storage temperature -20o to 70oC (-4o to 158oF). For DPI 612 hFlexPro +4 to +70°C (39 to 158°F) with water as media

Ingress protection IP 54. Protected against dust and splashing water from any direction

Humidity 0 to 90% RH none condensing. To Def Stan 66-31, 8.6 cat III

Shock / vibration BS EN 61010-1:2010 / MIL-PRF-28800F CLASS 2. 1 m drop tested

Altitude Up to 2000m

EMC BS EN 61326-1:2013

Electrical safety BS EN 61010-1:2010

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Pressure safety Pressure Equipment Directive - Class: Sound Engineering Practice (SEP)

Enclosure materials Polycarbonate, polyamide, polypropylene, acrylic, cotton

Approved CE marked

Power supply

Lithium-ion battery GE Part number: CC3800GE supplied as standard; Capacity: 3800 mAh

14.1Wh. Nominal voltage: 3.7 V. Charge temperature: 0° to 40°C (32° to 104°F) Discharge

temperature: -10° to 60°C (14° to 140°F). Charge/discharge cycles: > 500 > 70% capacity.

Battery eliminator / charger (GE part number: IO620-PSU) supplied as standard.

Alternatively 8 AA alkaline cells (not supplied)

Battery life For lithium-ion battery 12 to 26 hours depending on functions

For AA alkaline cells 18 to 26 hours depending on functions

Connectivity USB type A, USB type mini B

Accessories of GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

Part number Compatible model

Factory setting Adjustable range bar psi bar psi

IO620-PRV-P1 PFX / PFP 1 15 0.2 to 1 3 to 15

IO620-PRV-P2 PFX / PFP 5 100 3 to 7 45 to 100

IO620-PRV-P3 PFX / PFP 30 435 16 to 32 230 to 460

IO620-PRV-P4 PFP 60 870 30 to 60 435 to 870

IO620-PRV-P5 PFP 100 1500 60 to 100 870 to 1500

IO620-PRV-P6 PFX / PFP 3 45 1.1 to 3 16 to 45

IO620-PRV-P7 PFX / PFP 12 170 6.1 to 12 90 to 170

IO620-PRV-P8 PFX / PFP 18 260 12.1 to 18 175 to 260

IO620-PRV-H1 HFP 50 725 10 to 50 145 to 725

IO620-PRV-H2 HFP 200 3000 50 to 200 725 to 2900

IO620-PRV-H3 HFP 400 6000 200 to 400 2900 to 5800

IO620-PRV-H4 HFP 700 10000 300 to 700 4350 to 10000

IO620-PRV-H5 HFP 1000 15000 600 to 1000 8700 to 15000

Ordering Models of GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DPI611-05G -100kPa ~ 100kPa

DPI611-07G -100kPa ~ 200kPa

DPI611-10G -100kPa ~ 700kPa

DPI611-11G -100kPa ~ 1MPa

DPI611-13G -100kPa ~ 2MPa

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DRUCK DPI880

DPI611-13G -100kPa~2MPa，0.025

DPI611-11G -100kPa~1MPa，0.025

DPI611-10G （0-700）kPa，0.025

DPI611-07G -100kPa~200kPa，0.025

DPI611-05G -100kPa~100kPa，0.025

DPI610LP ±15KPag ，0.05

DPI610LP ±20PKa

DPI610HC （0~40）MPa ，0.025

DRUCK DPI603 0-20ba

DRUCK DPI104 (0-7）Mpa，0.05

DRUCK DPI104 (0-250）kPa，0.05级

DRUCK DPI104 (0-25）Mpa，0.05

DRUCK DPI104 (0-2.5）Mpa，0.05

DRUCK DPI104 (0-16）Mpa，0.05

DRUCK DPI104 (0-1.0）Mpa，0.05

DRUCK DPI705 70526671

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DRUCK PTX5072-TC-A1-CAH0-PA

HD1KA-008GM010-SR HD1KZ-008GM010-SR

DRUCK DPI605/0-2000KPa

DRUCK RPT200-3206(35-2605)

DRUCK RPT200-3206(35-1100)

DRUCK RPT200-3018(35-2650)

DRUCK RPT200-3018(35-1100)

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DRUCK PTX7517-4426 0-35Mpa 4-20mA 24V

DRUCK PTX7517-4426 0-35MPa 4-20mA

DRUCK PTX7517-1/0-350BAR

DRUCK PTX7517-1 35mpa sg 9-28vdc

DRUCK PTX7517_0-35MPa

DRUCK PTX7517 100mbar 4+20mA

DRUCK PTX7517 0-6MPA/G

DRUCK PTX7517 0-10MPA/G

DRUCK PTX7517 (0-25MPA)

DRUCK PTX-7516-3662 0-250BAR

DRUCK PTX661-3663/0-35MPa

DRUCK PTX661-3663 700BAR

DRUCK PTX-661-3663 0-250BAR

DRUCK PTX661-363/0-700bar

DRUCK PTX611 0-10Mpa G

DRUCK PTX611 0-400bar psi-sg

DRUCK PTX611

DRUCK PTX610

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DRUCK PTX-510-1519 35MPA

DRUCK PTX5100-250MBARABSOLUTE

DRUCK PTX510 0-250MBAR ABSOLUTE(CONNECTION: G1/4 INSIDE)

DRUCK PTX50A2-TC-A2-CB-H1-PA（-1~19bar，g）

DRUCK PTX50A2-TC-A2-CB-H1-PA（0~0.2bar，g）

DRUCK PTX50A2-TB-A3-CA-HO-PB

DRUCK PTX5072-TC-A1-HO-PA

DRUCK PTX5072-TC-A1-H1-PA 0~6MPa

DRUCK PTX5072-TC-A1-H1-PA 0~4.5MPa

DRUCK PTX5072-TC-A1-H1-PA 0~3MPa

DRUCK PTX5072-TC-A1-CA-HO-PA0-35bar

DRUCK PTX5072-TC-A1-CA-H1-TA

DRUCK PTX5072-TC-A1-CA-H1-PB

DRUCK PTX5072-TC-A1-CA-H1-PA 0-6bar

DRUCK PTX5072-TC-A1-CA-H1-PA

DRUCK PTX5072-TC-A1-CA-H0-PA（-0.1-2.5MPA）G1/4

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DRUCK PTX5072-TC-A1-CA-H0-PA0-10bar

DRUCK PTX5072-TC-A1-CA-H0-PA 0-6bar

DRUCK PTX5072-TC-A1-CA-H0-PA 0-75PSI A

DRUCK PTX5072-TC-A1-CA-H0-PA 0-100PSI G

DRUCK PTX5072-TB-A2-CB-HO-PR(0-40MPA)

DRUCK PTX5072-TB-A2-CB-H0-PR （0 -6MPA ）

DRUCK PTX5072-TB-A2-CB-H0-PR （0 -40MPA ）

DRUCK PTX5072-TB-A1-CA-H1-PA 1/4 0-25BAR

DRUCK PTX5072-AT-A1-CB-HO-PR(0-40mpa)

DRUCK PTX5072-AB-A2-CB-HO-PR(0-40MPA)

DRUCK PTX5072 ±0.25%FS

DRUCK PTX5032-TC-A1-CA-H1-PH

DRUCK PTX5032-TB-A1-CA-HO-PW

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

DRUCK PTX1730-3084 S/N 2384159 1.5mH20

DRUCK PTX1400(0-10)

DRUCK PTX-1400 0-250mbar

DRUCK PTX1400

DRUCK PTX1240-0005-005 100MPa

DRUCK PTX-1061-3273

DRUCK PTX610-1176 S/N1963758 -1to+3bar 4-20mA

DRUCK PTX 610/0-6bar

DRUCK PTX 510-1519 S/N.2910230

DRUCK PTX 5072-TB-A3-CA-H1-PA 0-400bar 7-28VDC 30mA

DRUCK PTX 5072-TA-A2-CB-H0-PA

DRUCK PMP5066-TB-A2-CA-H0-PE

DRUCK PMP 2060 8520

DRUCK GE100550 PTX1400 0-//16BAR

DRUCK JC-YZJ-T03/0-600KPa/0.05%

DRUCK GE113201 PTX7517(New model:UNIK5000)

DRUCK DRUCKSCHALITER*0250*EDS3000*DM

DRUCK DRUCKSCHALITER*0-10*EDS3000*DM

DRUCK DRUCKREG-VENT*AS3*R4120079814

DRUCK DRUCKREG-VENT*-*CDK3-5R-130

GE Druck DPI 611 Flex Series DPI611-07G Pressure Calibrators DPI611-07G Handy Calibrators In Stock

We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers,Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.

We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.
