Model: KFD2-SCD2-Ex1.LK

Supplier: Pepperl+Fuchs

Categories: Safety Barriers

After sales service. If you have any questions, click here.

PRODUCT DESCRIPTION

Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock




Product Features of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


- SMART Current Driver KFD2-SCD2-Ex1.LK

1-channel isolated barrier

24 V DC supply (Power Rail)

Current output up to 650 Ω load

HART I/P and valve positioner

Line fault detection (LFD)

Accuracy 0.1 %

Up to SIL 2 acc. to IEC 61508



Specification of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


General specifications of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock

Signal type Analog output



Functional safety related parameters of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Safety Integrity Level (SIL) SIL 2

Supply

Connection Power Rail or terminals 14+, 15-

Rated voltage 19 ... 30 V DC

Ripple ≤ 10 %

Rated current ≤ 30 mA at 24 V

Power dissipation ≤ 600 mW at 20 mA and 500 Ω load

Power consumption ≤ 700 mW



Input of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Connection side control side

Connection terminals 7-, 8+, (9+)

Input signal 4 ... 20 mA , limited to approx. 30 mA

Input voltage open loop voltage of the control system ≤ 30 V

Voltage drop approx. 6 V at 20 mA

Input resistance field wiring open circuit : > 100 kΩ

field wiring < 50 Ω : > 100 kΩ when using terminals 1 and 2



Output of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Connection side field side

Connection terminals 1+, 2-

terminals 3+, 2- (no short circuit detection)

Voltage ≥ 13 V at 20 mA

Current 4 ... 20 mA

Load 100 ... 650 Ω , for terminals 1, 2

0 ... 550 Ω , for terminals 2, 3

Ripple 20 mV rms

Line fault detection breakage, load > 100 kΩ, short-circuit, load < 50 Ω



Fault indication output of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Output type open collector transistor (internal fault bus)



Transfer characteristics of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Deviation at 20 °C (68 °F), 4 ... 20 mA

< 0.1 % of full scale, incl. non-linearity and hysteresis

Influence of ambient temperature < 2 µA/K (-20 ... 70 °C (-4 ... 158 °F)); < 4 µA/K (-40 ... -20 °C (-40 ... -4 °F))

Frequency range field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 3 kHz (-3 dB)

control side into the field side: bandwidth with 0.5 Vpp signal 0 ... 3 kHz (-3 dB)

Rise time 10 to 90 % ≤ 10 ms



Galvanic isolation of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Input/Output basic insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Input/power supply basic insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Output/power supply reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff



Indicators/settings of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Display elements LEDs

Labeling space for adhesive label at the front



Directive conformity of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Electromagnetic compatibility

Directive 2014/30/EU EN 61326-1:2013 (industrial locations)



Conformity of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Electromagnetic compatibility NE 21:2017

EN 61326-3-2:2018

Degree of protection IEC 60529

Protection against electrical shock UL 61010-1:2012



Ambient conditions of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock

Ambient temperature -40 ... 70 °C (-40 ... 158 °F)



Mechanical specifications of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


Degree of protection IP20

Connection screw terminals

Mass approx. 115 g

Dimensions 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) , housing type B2

Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001



Ordering Codes of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-STC3-EX1

KFD2-ST2-E2

Z 787.H

KFD2-SR2-EX2.W

KFD2-UT2-EX1

KFD2-CD-EX1.32-0

KFD2-CD-1.32

KFD2-CD-Ex1.32-1

KFD2-CR-EX1.30-200

KFD2-STC4-EX1.H

KFD2-CR4-1.2O

KFD2-CR4-1.2O

KFD2-GS-1.2W

KFD0-CS-EX1.54


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-SCD2-EX1-LK

KFD2-EB2.R4A.B

KFD2-STC4-EX1

HD2-DM-B

KFD2-SL2-EX.1B

HD2-FBPS-1.25.360

MBHD-FB-4R.YO

Z961

KFD2-SR2-Ex1.W

KFD2-SCD-EX1.LK

KFD2-STC4-1

KFD2-SH-EX1

NCN3-F25F-N4P

UPR-03

KFD2-SCD2-Ex1.LK


Ordering Models of Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KCD2-SCD-1 KCD2-SCD-EX1 KCD2-SR-EX1.LB KCD2-SR-EX2 KCD2-STC-1 KCD2-STC-EX1 KCD2-STC-EX1.2O KCD2-UT2-EX1 KFA6-SR2-Ex1.W KFD0-SD2-Ex1.1045 KFD2-CD2-EX1 KFD2-CRG2-EX1.D KFD2-DWB-1.D KFD2-EB2 KFD2-GU-1 KFD2-GUT-Ex1.D KFD2-SCD2-EX2.LK KFD2-SH-EX1.T.OP KFD2-SOT2-Ex2 KFD2-SR2-Ex1.W.LB  KFD2-SR2-Ex2.W KFD2-ST2-Ex2 KFD2-STC4-1 KFD2-STC4-EX2 KFD2-STC4-Ex2 KFD2-UT2-1 KFD2-UT2-2 KFD2-UT2-EX1 KFD2-UT2-Ex2 KFD2-VR4-EX1.26



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KCD2-STC-Ex1 KCD2-STC-Ex1.ES KFD2-CRG2-Ex1.D KFD2-HLC-Ex1.D KFD2-HLC-Ex1.D.2W KFD2-STC4-Ex1 KFD2-STC4-Ex1.2O KFD2-STC4-Ex1.2O.H KFD2-STC4-Ex1.H KFD2-STC4-Ex2 KFU8-CRG2-Ex1.D KCD2-STC-Ex1.2O KCD2-STC-Ex1.2O.ES KCD2-STC-Ex1.ES.SP KCD2-STC-Ex1.SP KFD2-STC3-Ex1 KFD2-STC4-Ex1-Y1 KFD2-STC4-Ex1.2O-Y1 KFD2-STC4-Ex1.ES KFD2-STC4-Ex2-Y1 KFD2-STC5-Ex1 KFD2-STC5-Ex1.2O KFD2-STC5-Ex1.2O.H KFD2-STC5-Ex1.H KFD2-STC5-Ex2 KFD2-STC5-Ex2 KFD2-STC5-Ex2 KFD2-STV4-Ex1.2O-1 KFD2-STV4-Ex2-1 KFD2-STV4-Ex2-2 KFD2-STV5-Ex1-1 KCD2-STC-Ex1.2O.DE KFD2-HLC-Ex1.D.4S KFD2-STV4-Ex1.2O-2 KCD2-STC-Ex1.HC KCD2-STC-Ex1.HC.SP KFD2-STC4-Ex1 KFD2-STC4-Ex1-Y1 KFD2-STC4-Ex1.2O KFD2-STC4-Ex1.2O-Y1 KFD2-STC4-Ex1.2O.H KFD2-STC4-Ex1.H KFD2-STV4-Ex1-1 KFD2-STV4-Ex1-2 KFD2-STV4-Ex1.2O-1 KFD2-STV4-Ex2-1 KFD2-STV4-Ex2-2 KFD2-STV4-Ex1.2O-2 KFD2-STC3-Ex1 KCD2-STC-Ex1-Y1



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KCD2-STC-Ex1 KCD2-STC-Ex1.ES KFD2-CRG2-Ex1.D KFD2-HLC-Ex1.D KFD2-HLC-Ex1.D.2W KFD2-STC4-Ex1 KFD2-STC4-Ex1.2O KFD2-STC4-Ex1.2O.H KFD2-STC4-Ex1.H KFD2-STC4-Ex2 KFU8-CRG2-Ex1.D KCD2-STC-Ex1.2O KCD2-STC-Ex1.2O.ES KCD2-STC-Ex1.ES.SP KCD2-STC-Ex1.SP KFD2-STC3-Ex1 KFD2-STC4-Ex1-Y1 KFD2-STC4-Ex1.2O-Y1 KFD2-STC4-Ex1.ES KFD2-STC4-Ex2-Y1 KFD2-STC5-Ex1 KFD2-STC5-Ex1.2O KFD2-STC5-Ex1.2O.H KFD2-STC5-Ex1.H KFD2-STC5-Ex2 KFD2-STC5-Ex2 KFD2-STC5-Ex2 KFD2-STV4-Ex1.2O-1 KFD2-STV4-Ex2-1 KFD2-STV4-Ex2-2 KFD2-STV5-Ex1-1 KCD2-STC-Ex1.2O.DE KFD2-HLC-Ex1.D.4S KFD2-STV4-Ex1.2O-2 KCD2-STC-Ex1.HC KCD2-STC-Ex1.HC.SP KFD2-STC4-Ex1 KFD2-STC4-Ex1-Y1

KFD2-STC4-Ex1.2O KFD2-STC4-Ex1.2O-Y1 KFD2-STC4-Ex1.2O.H KFD2-STC4-Ex1.H KFD2-STV4-Ex1-1 KFD2-STV4-Ex1-2 KFD2-STV4-Ex1.2O-1 KFD2-STV4-Ex2-1 KFD2-STV4-Ex2-2 KFD2-STV4-Ex1.2O-2 KFD2-STC3-Ex1 KCD2-STC-Ex1-Y1



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KCD2-SCD-1 KCD2-SCD-EX1 KCD2-SR-EX1.LB KCD2-SR-EX2 KCD2-STC-1 KCD2-STC-EX1 KCD2-STC-EX1.2O KCD2-UT2-EX1 KFA6-SR2-Ex1.W KFD0-SD2-Ex1.1045 KFD2-CD2-EX1 KFD2-CRG2-EX1.D KFD2-DWB-1.D KFD2-EB2 KFD2-GU-1 KFD2-GUT-Ex1.D KFD2-SCD2-EX2.LK KFD2-SH-EX1.T.OP KFD2-SOT2-Ex2 KFD2-SR2-Ex1.W.LB KFD2-SR2-Ex2.W KFD2-ST2-Ex2 KFD2-STC4-1 KFD2-STC4-EX2 KFD2-STC4-Ex2 KFD2-UT2-1 KFD2-UT2-2 KFD2-UT2-EX1 KFD2-UT2-Ex2 KFD2-VR4-EX1.26 KFU8-FSSP-1.D NBB0,8-5GM25-E2 NBB1,5-8GM50-E0 NBB10-30GM40-Z0 NBB10-30GM50-E2 NBB15-30GM50-WO NBB15-30GM50-WS NBB15-U1-A2 NBB15-U1-A2-T NBB15-U1-E2 NBB15-U1-Z2 NBB2-12GM50-E0-V1 NBB2-12GM50-E2 NBB2-6,5M30-E0 NBB2-8GM30-E2-5M NBB20-L2-A2-V1-3G-3D NBB20-L2-E0-V1 NBB20-L2-E2-V1 NBB20-U1-A2 NBB20-U1-E0 NBB20-U1-E2 NBB3-V3-Z4 NBB4-12GM50-E0 NBB4-12GM50-E0-V1 NBB4-12GM50-E2-V1 NBB5-18GM50-E2-V1 NBB5-18GM60-A2-V1 NBB8-18GM50-E2-V1 NBB8-18GM60-A2-V1 NBN12-18GM50-E2-V1 NBN12-18GM50-E2-V1-Y261468 NBN15-30GM50-E0 NBN15-30GM50-E2-V1 NBN15-30GM60-A2 NBN25-30GM50-E2 NBN3-F31-E8-V1 NBN30-L2-E2-V1 NBN30-U1-A2 NBN30-U1-E2 NBN4-12GM50-E2 NBN4-12GM50-E2-V1 NBN40-L2-E2-V1 NBN40-U1-A2 NBN40-U1-A2-T NBN40-U1-Z2 NBN40-U1K-N0 NBN5-F7-E0 NBN5-F7-E2 NBN8-12GM50-E0-V1 NBN8-12GM50-E2-V1 NBN8-18GM50-E0 NBN8-18GM50-E2-V1 NBN8-18GM60-WS NCB10-30GM40-NO NCB15-30GM50-Z5 NCB50-FP-A2-P1 NCB8-18GM40-N0 NCN15-30GM40-Z1 NJ15+U1+DW1-10 NJ2-12GK-SN NJ2-V3-N NJ4-12GK-N NJ40-FP-SN-P1 NJ5-18GM-N NJ5-18GM50-A2-V1 NJ8-18GM-N NRB10-30GM50-E2-C-V1 NRB15-30GM50-E2-C-V1



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KCD2-SR-Ex1.LB KCD2-SR-Ex2 KFA6-DU-Ex1.D KFA6-ER-Ex1.W.LB KFA6-SOT2-Ex2 KFA6-SR2-Ex1.W KFA6-SR2-Ex1.W.LB KFA6-SR2-Ex2.W KFA6-SR2-Ex2.W.IR KFD2-DU-Ex1.D KFD2-ELD-Ex16 KFD2-ER-Ex1.W.LB KFD2-SH-Ex1 KFD2-SH-Ex1.T.OP KFD2-SOT3-Ex1.LB KFD2-SOT3-Ex1.LB.IO KFD2-SOT3-Ex2 KFD2-SOT3-Ex2.IO KFD2-SR2-Ex1.W KFD2-SR2-Ex1.W.LB KFD2-SR2-Ex2.W KFD2-SR3-Ex2.2S KFD2-SRA-Ex4 KFD2-ST3-Ex1.LB KFD2-ST3-Ex2 KHA6-SH-Ex1 KCD2-SON-Ex1 KCD2-SOT-Ex1.LB KCD2-SOT-Ex2 KCD2-SOT-Ex2.SP



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KCD2-SR-Ex1.LB.SP KCD2-SR-Ex2.SP KCD2-ST-Ex1.LB KCD2-ST-Ex2 KFA5-SOT2-Ex2 KFA5-SR2-Ex1.W KFA5-SR2-Ex1.W.LB KFA5-SR2-Ex2.W KFA5-SR2-Ex2.W.IR KFD2-SH-Ex1.T KFD2-SOT3-Ex2.IO-Y1 KCD2-SON-Ex1.R1  KCD2-SON-Ex1.SP KCD2-SON-Ex2 KCD2-SON-Ex2.R1 KCD2-SON-Ex2.SP KCD2-SOT-Ex1.LB.SP KCD2-ST-Ex1.LB.SP KCD2-ST-Ex2.SP KFA4-SR2-Ex2.W KFA5-DU-Ex1.D KFA4-SR2-Ex1.W KFA4-SR2-Ex1.W.LB KFD2-SOT2-Ex1.LB KFD2-SOT2-Ex1.LB.IO KFD2-SOT2-Ex2 KFD2-SOT2-Ex2.IO KFD2-SOT2-Ex2.IO-Y181008 KFD2-SR2-Ex2.2S KFD2-ST2-Ex1.LB KFD2-ST2-Ex2



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock



KFD2-STC4-EX1 KFD2-SR2-EX1.W KFD2-SR2-EX2.W KFD2-CD-EX1.32 KFD2-UT2-EX1. KFD2-ST-EX1 KFD2-UFC-EX1.D KFA5-SR2-EX2.W KFA5-SR2-EX1.W KFA6-SR2-EX2.W KFA5-SR2-EX1.W KFD2-ST-EX1 KFD2-SOT2-EX1 KFU8-UFC-EX1.D KFD2-CD-EX1.32 KFU8-FSSP-1.D KFA6-DWB-EX1.D KFD2-DWB-EX1.D KFA5-SR2-EX1,W KFA5-SR2-EX2,W KFD2-VR4-EX1.26 KFD2-STC4-EX1.20 KFD2-SOT2-EX2 KFD2-ST2-EX1.B KFD2-DWB-EX1.D KFD2-UFC-EX1.D KFA6-STR-1.24.500 KFD2-UT2-1 KFD2-UT2-2 KFD2-CD-1.32 KFD2-SOT2-EX1.LB KFA6-SR2-EX1.LB KFA6-SOT2-EX2 KFU8-FSSP-1.D KFU8-UFC-EX1,D KFU8-UFT-EX2.D KFA6-DWB-EX1.D KFD0-SCS-EX1.55 KFD2-STC4-EX2 KFD2-STC4-EX1Y125882 KFD2-UT2-EX2 UPR-03 KFD2-EB2.B4.AB KFD2-CD-EX1.32 KFD2-STC4-EX1 KFD2-UT2-EX1 KFD2-SR2-Ex1.W KFD2-SCD-EX1.LK KFD2-SOT2-EX2 KFD2-STC4-EX2 KFD2-SR2-Ex2.W KFD2-SR2-Ex1.W KFD2-STC4-EX1.2O KFD0-SCS-EX1.55 KFU8-UFC-EX1.D KFD2-SOT2-EX2 KFD2-STC4-EX1 KFD2-UT2-EX2 KFD2-VR4-EX1.26 KFD2-EB2.R4A.B KFD2-BR-1.PA.93 KFU8-DWB-1.D KFU8-DW-1.D KFU8-UFT-EX2.D Z787.H UPR-03



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFA6-STR-1.24.500

Power Supply

115/230 V AC supply, Output 24 V DC, 500 mA, Electronic short circuit protection, Power Rail connection



KFD0-SCS-Ex1.55

SMART Current Driver/Repeater

1-channel isolated barrier, 24 V DC supply (loop powered), Current input/output 4 mA ... 20 mA, HART I/P or transmitter power supply, Low voltage drop, Line fault detection (LFD), Up to SIL 2 acc. to IEC 61508, Rated voltage: loop powered, Explosion protection: Ex protection, Transfer direction: to the field / to the control system



KFD2-CRG2-1.D

Transmitter Power Supply

1-channel signal conditioner, 24 V DC supply (Power Rail), Input 2-wire and 3-wire transmitters and 2-wire current sources, Output 0/4 mA ... 20 mA, 2 relay contact outputs, Adjustable energized/de-energized delay, Programmable high/low alarm, Linearization function (max 20 points), Line fault detection (LFD), Up to SIL 2 acc. to IEC 61508/IEC 61511


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-CRG2-Ex1.D

Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire transmitters and 2-wire current sources, Output 0/4 mA ... 20 mA, 2 relay contact outputs, Adjustable energized/de-energized delay, Programmable high/low alarm, Linearization function (max 20 points), Line fault detection (LFD), Up to SIL 2 acc. to IEC 61508/IEC 61511



KFD2-HLC-Ex1.D

HART Loop Converter

1-channel isolated barrier, 24 V DC supply (Power Rail), HART field device input with transmitter power supply, Usable as signal splitter (1 input and several outputs), 3 analog outputs 4 mA ... 20 mA, Sink and source mode output, Configurable by keypad



KFD2-HLC-Ex1.D.2W

HART Loop Converter

1-channel isolated barrier, 24 V DC supply (Power Rail), HART field device input with transmitter power supply, Usable as signal splitter (1 input and several outputs), 2 relay contact outputs (change-over contacts), 3 analog outputs 4 mA ... 20 mA, Sink and source mode output, Configurable by keypad



KFD2-STC5-1

SMART Transmitter Power Supply

1-channel signal conditioner, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/4 mA ... 20 mA current sink/current source, Terminals with test points, Up to SIL 2 acc. to IEC 61508


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-STC5-1.2O

SMART Transmitter Power Supply

1-channel signal conditioner, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA, current sink/current source, Terminals with test points, Up to SIL 3 acc. to IEC 61508



KFD2-STC5-2

SMART Transmitter Power Supply

2-channel signal conditioner, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/4 mA ... 20 mA current sink/current source, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KFD2-STC5-Ex1.2O

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA, current sink/current source, Terminals with test points, Up to SIL 3 acc. to IEC 61508



KFD2-STC5-Ex1.H

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/4 mA ... 20 mA current sink/current source, Terminals with test points, High field voltage 17 V DC, Up to SIL 2 acc. to IEC 61508


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-STC5-Ex2

SMART Transmitter Power Supply

2-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/4 mA ... 20 mA current sink/current source, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KFU8-CRG2-1.D

Transmitter Power Supply

1-channel signal conditioner, Universal usage at different power supplies, Input 2-wire and 3-wire transmitters and 2-wire current sources, Output 0/4 mA ... 20 mA, 2 relay contact outputs, Adjustable energized/de-energized delay, Programmable high/low alarm, Linearization function (max 20 points), Line fault detection (LFD), Up to SIL 2 acc. to IEC 61508/IEC 61511



KFU8-CRG2-Ex1.D

Transmitter Power Supply

1-channel isolated barrier, Universal usage at different power supplies, Input 2-wire and 3-wire transmitters and 2-wire current sources, Output 0/4 mA ... 20 mA, 2 relay contact outputs, Adjustable energized/de-energized delay, Programmable high/low alarm, Linearization function (max 20 points), Line fault detection (LFD), Up to SIL 2 acc. to IEC 61508/IEC 61511


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFU8-VCR-1

Transmitter Power Supply/Converter

1-channel signal conditioner, Universal usage at different power supplies, Input 2-wire and 3-wire transmitters, current and voltage sources, Current and voltage output, Rated voltage: 19 ... 90 V DC / 48 ... 253 V AC



KLD2-FBPS-1.25.360

Fieldbus Power Supply

Output: 25 ... 27 V/360 mA, For most fieldbus applications, High-power trunk for high device count and long cable lengths, Installation in Zone 2/Class I, Div. 2, For FOUNDATION Fieldbus H1


KFD2-STC5-Ex1

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/4 mA ... 20 mA current sink/current source, Terminals with test points, Up to SIL 2 acc. to IEC 61508


KCD2-STC-1.2O

SMART Transmitter Power Supply

1-channel signal conditioner, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V, Terminal blocks with test sockets, Up to SIL 2 acc. to IEC 61508



KCD2-STC-Ex1

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Output for 4 mA ... 20 mA or 1 V ... 5 V, Housing width 12.5 mm, Up to SIL 2 acc. to IEC 61508



KCD2-STC-Ex1.2O

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V, Terminal blocks with test sockets, Up to SIL 2 acc. to IEC 61508



KCD2-STC-Ex1.ES

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Output for 4 mA ... 20 mA or 1 V ... 5 V, Sink or source mode, Line fault detection (LFD), Housing width 12.5 mm, Up to SIL 3 acc. to IEC 61508



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KCD2-STC-Ex1.SP

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Output for 4 mA ... 20 mA or 1 V ... 5 V, Housing width 12.5 mm, Connection via spring terminals with push-in connection technology, Up to SIL 2 acc. to IEC 61508



KFA6-STR-1.24.4

Power Supply

115/230 V AC supply, Output 24 V DC, 4 A, Fused output, Power Rail connection



KFD0-CS-1.50

Repeater

1-channel signal conditioner, 24 V DC supply (loop powered), Current input/output 4 mA ... 20 mA, transmitter power supply, Accuracy 0.1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD0-CS-2.50

Repeater

2-channel signal conditioner, 24 V DC supply (loop powered), Current input/output 4 mA ... 20 mA, transmitter power supply, Accuracy 0.1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD0-CS-Ex1.50P

Repeater

1-channel isolated barrier, 24 V DC supply (loop powered), Current input/output 4 mA ... 20 mA, transmitter power supply, Accuracy 0.1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD0-CS-Ex1.51P

Current Driver/Repeater

1-channel isolated barrier, 24 V DC supply (loop powered), Current input/output 0 mA ... 40 mA, I/P or transmitter power supply, Accuracy 1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD0-CS-Ex2.50P

Repeater

2-channel isolated barrier, 24 V DC supply (loop powered), Current input/output 4 mA ... 20 mA, transmitter power supply, Accuracy 0.1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD0-CS-Ex2.51P

Current Driver/Repeater

2-channel isolated barrier, 24 V DC supply (loop powered), Current input/output 0 mA ... 40 mA, I/P or transmitter power supply, Accuracy 1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD2-STC3-Ex1

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), 2-wire SMART transmitter, Output 4 mA ... 20 mA, SMART capable up to 40 kHz (-1dB), Suitable for Honeywell DE protocol, Terminals with test points



KFD2-STC4-Ex2-Y1

SMART Transmitter Power Supply, Output Current Sink

2-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire SMART transmitters, Output 0/4 mA ... 20 mA current sink, Terminal blocks with test sockets, Up to SIL 2 acc. to IEC 61508


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-STC5-Ex1

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/4 mA ... 20 mA current sink/current source, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KFD2-STC5-Ex1.2O.H

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA, current sink/current source, Terminals with test points, High field voltage 17 V DC, Up to SIL 3 acc. to IEC 61508


KCD2-STC-Ex1.2O.DE

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V, Terminal blocks with test sockets, Up to SIL 2 acc. to IEC 61508



KCD2-STC-Ex1.2O.ES

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V, Terminal blocks with test sockets, Up to SIL 3 acc. to IEC 61508



KCD2-STC-Ex1.ES.SP

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input for 2-wire SMART transmitters and current sources, Output for 4 mA ... 20 mA or 1 V ... 5 V, Sink or source mode, Line fault detection (LFD), Housing width 12.5 mm, Connection via spring terminals with push-in connection technology, Up to SIL 3 acc. to IEC 61508


KFD0-CS-2.51P

Current Driver/Repeater

2-channel signal conditioner, 24 V DC supply (loop powered), Current input/output 0 mA ... 40 mA, I/P or transmitter power supply, Accuracy 1 %, Reverse polarity protection, Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD0-SCS-1.55

SMART Current Driver/Repeater

1-channel signal conditioner, 24 V DC supply (loop powered), Current input/output 4 mA ... 20 mA, HART I/P or transmitter power supply, Low voltage drop, Line fault detection (LFD), Up to SIL 2 acc. to IEC 61508, Transfer direction: to the field / to the control system



KFD2-HLC-Ex1.D.4S

HART Loop Converter

1-channel isolated barrier, 24 V DC supply (Power Rail), HART field device input with transmitter power supply, Usable as signal splitter (1 input and several outputs), 4 relay contact outputs (NO contact), 3 analog outputs 4 mA ... 20 mA, Sink and source mode output, Configurable by keypad



Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


KFD2-STC4-Ex1.2O-Y1

SMART Transmitter Power Supply, Output Current Sink

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Signal splitter (1 input and 2 outputs), Dual output 0/4 mA ... 20 mA, current sink, Terminal blocks with test sockets, Up to SIL 3 acc. to IEC 61508



KFD2-STV4-Ex1-2

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/2 V ... 10 V, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KFD2-STV4-Ex1.2O-1

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Signal splitter (1 input and 2 outputs), Dual output 0/1 V ... 5 V, Terminal blocks with test sockets, Up to SIL 3 acc. to IEC 61508



KFD2-STV4-Ex2-1

SMART Transmitter Power Supply

2-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire SMART transmitters, Output 0/1 V ... 5 V, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KFD2-STV4-Ex2-2

SMART Transmitter Power Supply

2-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire SMART transmitters, Output 0/2 V ... 10 V, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KFD2-STV5-Ex1-1

SMART Transmitter Power Supply

1-channel isolated barrier, 24 V DC supply (Power Rail), Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources, Output 0/1 V ... 5 V, Terminals with test points, Up to SIL 2 acc. to IEC 61508



KLD2-FBPS-1.12.220

Fieldbus Power Supply

Output: 12 ... 13 V/220 mA, For battery or solar-powered applications, For demanding environmental conditions , Installation in Zone 2/Class I, Div. 2, For FOUNDATION Fieldbus H1


Pepperl+Fuchs KFD2-SCD2-Ex1.LK Safety Barriers KFD2-SCD2-Ex1.LK SMART Current Driver In Stock


We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.





We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.



Contact:

HONGKONG XIEYUAN TECH CO., LIMITED

Email:becky@hkxytech.com   Web:www.hkxytech.com

Mobile:+86-15972186287(Whatsapp & Wechat)


Related Products

CONTACT ADDRESS

UNIT A1.9/F SILVERCORP INTERNATIONAL TOWER707-713 NATHAN ROAD MONGKOK KOWLOON HONGKONG

WRITE TO US

becky@hkxytech.com

CALL US

+86 027-8580 6199

MOBILE PHONE

+86 15972186287
