IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Product Features of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Pressure sensor with display

PN7094

PN-010-RER14-QFRKG/US/ /V

*  Two switching outputs, one of them with IO-Link communication interface

*  Red/green display for clear identification of the acceptable range

*  The process connection can be rotated for optimum alignment

*  With long-term stability thanks to high overload protection

*  Robust design for use in harsh industrial environments

Product characteristics of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Output signal switching signal; IO-Link; (configurable)

Measuring range

-1...10 bar -14.5...145 psi -0.1...1 MPa

Process connection threaded connection G 1/4 Internal thread

Application of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

System gold-plated contacts

Measuring element ceramic-capacitive pressure measuring cell

Application for industrial applications

Media liquids and gases

Medium temperature [°C] -25...80

Min. bursting pressure

150 bar 2175 psi 15 MPa

Pressure rating

75 bar 1087 psi 7.5 Mpa

Vacuum resistance [mbar] -1000

Type of pressure relative pressure; vacuum

Electrical data of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Operating voltage [V] 18...30 DC; (according to EN 50178 SELV/PELV)

Current consumption [mA] < 35

Min. insulation resistance [MΩ] 100; (500 V DC)

Protection class III

Reverse polarity protection yes

Power-on delay time [s] < 0.3

Integrated watchdog yes

Inputs / outputs

Number of inputs and outputs Number of digital outputs: 2

Outputs of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Total number of outputs 2

Output signal switching signal; IO-Link; (configurable)

Electrical design PNP/NPN

Number of digital outputs 2

Output function normally open / closed; (configurable)

Max. voltage drop switching output DC [V] 2.5

Permanent current rating of switching output DC [mA] 150; (200 (...60 °C) 250 (...40 °C))

Switching frequency DC [Hz] < 170

Short-circuit protection yes

Type of short-circuit protection yes (non-latching)

Overload protection yes

Measuring/setting range of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Measuring range

-1...10 bar -14.5...145 psi -0.1...1 MPa

Factory setting / CMPT = 2 of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Set point SP

-0.9...10 bar -13.5...145 psi -0.09...1 MPa

Reset point rP

-0.95...9.95 bar -14...144.5 psi -0.095...0.995 MPa

Min. difference between SP and rP

0.05 bar 1 psi 0.005 MPa

In steps of

0.05 bar 0.5 psi 0.005 MPa

IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Status_B High Resolution / CMPT = 3

Set point SP

-0.92...10 bar -13.3...145 psi -0.092...1 MPa

Reset point rP

-0.97...9.95 bar -14...144.3 psi -0.097...0.995 MPa

Min. difference between SP and rP

0.05 bar 0.8 psi 0.005 MPa

In steps of

0.01 bar 0.1 psi 0.001 MPa

Accuracy / deviations of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Switch point accuracy [% of the span] < ± 0,5

Repeatability [% of the span] < ± 0,1; (with temperature fluctuations < 10 K)

Characteristics deviation [% of the span] < ± 0,25 (BFSL) / < ± 0,5 (LS); (BFSL = Best Fit Straight Line; LS = limit value setting)

Hysteresis deviation [% of the span] < ± 0,25

Long-term stability [% of the span] < ± 0,05; (per 6 months)

Temperature coefficient zero point [% of the span / 10 K] < ± 0,2; (0...80 °C)

Temperature coefficient span [% of the span / 10 K] < ± 0,2; (0...80 °C)

Reaction times of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Response time [ms] < 3

Delay time programmable dS, dr [s] 0...50

Software / programming of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Parameter setting options hysteresis / window; normally open / closed; switching logic; switch-on/switch-off delay;

Damping; Display unit

Interfaces of IFM PN7094 Pressure Sensors with Display PN7094 Pressure Switches In Stock

Communication interface IO-Link

Transmission type COM2 (38,4 kBaud)

IO-Link revision 1.1

SDCI standard IEC 61131-9

SIO mode yes

Required master port class A; (when pin 2 not connected: B)

Supported DeviceIDs

Type of operation DeviceID

Factory setting / CMPT = 2 403

Status_B High Resolution / CMPT = 3 601

PN7004 311

Note

For further information please see the IODD PDF file at "Downloads"
