Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock

Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock

Model: KFD2-STC4-EX1.2O-Y1

Supplier: Pepperl+Fuchs

Categories: Safety Barriers

After sales service. If you have any questions, click here.

PRODUCT DESCRIPTION

Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock



Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock



Features of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


• 1-channel isolated barrier

• 24 V DC supply (Power Rail)

• Input 2-wire and 3-wire SMART transmitters and 2-wire

SMART current sources

• Signal splitter (1 input and 2 outputs)

• Dual output 0/4 mA ... 20 mA, current sink

• Terminal blocks with test sockets

• Up to SIL3 acc. to IEC 61508



Function of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


•  This isolated barrier is used for intrinsic safety applications.

•  The device supplies 2-wire and 3-wire SMART transmitters in a hazardous area, and can also be used with 2-wire SMART current sources.

•  It transfers the analog input signal to the safe area as two isolated current values.

•  Digital signals may be superimposed on the input signal in the hazardous or safe area and are transferred bi-directionally.

•  It is designed to provide a sink mode output on the safe area terminals.

•  If the HART communication resistance in the loop is too low,the internal resistance of 250 ohm between terminals 8, 9 and 11, 12 can be used.

•  Test sockets for the connection of HART communicators are integrated into the terminals of the device.



Application of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


The device supports the following SMART protocols:

• HART    • BRAIN     • Foxboro


General specifications of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Signal type Analog input

Functional safety related parameters

Safety Integrity Level (SIL) SIL 3


Supply of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Connection Power Rail or terminals 14+, 15-

Rated voltage Ur 20 ... 35 V DC

Ripple within the supply tolerance

Power dissipation 1.8 W

Power consumption 2.4 W


Input of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Connection side field side

Connection terminals 1+, 2-, 3 or 5-, 6+

Input signal 0/4 ... 20 mA

Open circuit voltage/short-circuit current terminals 1+, 3-: 22.7 V / 38 mA

Voltage drop terminals 5, 6 : ≤ 2.4 V at 20 mA

Input resistance terminals 2-, 3: ≤ 76 ohm

terminals 1+, 3: ≤ 500 ohm (250 ohm load)

Available voltage terminals 1+, 3: ≥ 16 V at 20 mA


Output of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Connection side control side

Connection terminals 7+, 8-; 10+, 11-

Output signal 0/4 ... 20 mA (overload > 25 mA)

Ripple ≤ 50 µA rms

External supply (loop) 11 ... 30 V DC

Transfer characteristics

Deviation at 20 °C (68 °F), 0/4 ... 20 mA

≤ 10 µA incl. calibration, linearity, hysteresis, loads and fluctuations of supply voltage

Influence of ambient temperature 0.25 µA/K

Frequency range field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 7.5 kHz (-3 dB)

control side into the field side: bandwidth with 0.5 Vpp signal 0.3 ... 7.5 kHz (-3 dB)

Settling time 200 µs

Rise time/fall time 20 µs


Galvanic isolation of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Output/power supply functional insulation, rated insulation voltage 50 V AC

Output/Output functional insulation, rated insulation voltage 50 V AC


Indicators/settings of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Display elements LED

Labeling space for labeling at the front


Directive conformity of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Electromagnetic compatibility

Directive 2014/30/EU EN 61326-1:2013 (industrial locations)


Conformity of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Electromagnetic compatibility NE 21:2011

Degree of protection IEC 60529:2001

Protection against electrical shock UL 61010-1:2012


Ambient conditions of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Ambient temperature -20 ... 60 °C (-4 ... 140 °F)


Mechanical specifications of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Degree of protection IP20

Connection screw terminals

Mass approx. 200 g

Dimensions 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) , housing type B2

Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001

Data for application in connection

with hazardous areas

EU-Type Examination Certificate BAS 99 ATEX 7060 X

Marking ¬ II (1)G [Ex ia Ga] IIC , ¬ II (1)D [Ex ia Da] IIIC , ¬ I (M1) [Ex ia Ma] I

Input [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I


Supply of Pepperl+Fuchs KFD2-STC4-EX1.2O-Y1 SMART Transmitter Power Supply KFD2-STC4-EX1.2O-Y1 Isolated Barriers In Stock


Maximum safe voltage Um 250 V (Attention! The rated voltage can be lower.)

Equipment terminals 1+, 3-

Voltage Uo 25.4 V

Current Io 86.8 mA

Power Po 551 mW
