Pressure sensors / Vacuum sensors - Sensors with digital display for sanitary applications, Type PI
High overall accuracy and electronic temperature compensation
Programmable analog and switching output
Hygienic, flush design
Aseptoflex Vario - G 1 process connection with four sealing options
High temperature resistance
Features of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Flush pressure sensor with display
PI2797
PI-001BREA01-MFRKG/US/ /P
* Robust stainless steel housing for use in the food and beverage industry
* Hygienic, flush design
* Resistant to high-pressure cleaning with aggressive cleaning agents
* High temperature resistance and high protection rating
* Programmable analog and switching output
Technical Details of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Product characteristics of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Output signal switching signal; analog signal; IO-Link; (configurable)
Measuring range of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
-0.05...1 bar -50...1000 mbar -0.73...14.5 psi -5...100 kPa
Process connection threaded connection G 1 external thread Aseptoflex Vario
Application of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
System gold-plated contacts
Application flush mountable for the food and beverage industry
Media viscous media and liquids with suspended particles; liquids and gases
Medium temperature [°C] -25...125; (145 max. 1h)
Min. bursting pressure
30000 mbar 435 psi 3000 kPa
Pressure rating
10000 mbar 145 psi 1000 kPa
Vacuum resistance [mbar] -1000
Type of pressure relative pressure
No dead space yes
MAWP (for applications according to CRN) [bar] 10
Electrical data of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Min. insulation resistance [MΩ] 100; (500 V DC)
Protection class III
Reverse polarity protection yes
Integrated watchdog yes
2-wire
Operating voltage [V] 20...32 DC
Current consumption [mA] 3.6...21
Power-on delay time [s] 1
3-wire
Operating voltage [V] 18...32 DC
Current consumption [mA] < 45
Power-on delay time [s] 0.5
Inputs / outputs of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Number of inputs and outputs Number of digital outputs: 2; Number of analog outputs: 1
Outputs of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Total number of outputs 2
Output signal switching signal; analog signal; IO-Link; (configurable)
Electrical design PNP/NPN
Number of digital outputs 2
Output function normally open / closed; (configurable)
Number of analog outputs 1
Analog current output [mA] 4...20, invertible; (scalable)
Short-circuit protection yes
Type of short-circuit protection yes (non-latching)
Overload protection yes
2-wire
Max. load [Ω] 300
3-wire
Max. voltage drop switching output DC [V] 2
Permanent current rating of switching output DC [mA] 250
Switching frequency DC [Hz] 125
Max. load [Ω] (Ub - 10 V) / 20 mA
Measuring/setting range of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Measuring range
-0.05...1 bar -50...1000 mbar -0.73...14.5 psi -5...100 kPa
Set point SP
-48...1000 mbar -0.7...14.5 psi -4.8...100 kPa
Reset point rP
-50...998 mbar -0.73...14.47 psi -0.5...99.8 kPa
Analog start point
-50...750 mbar -0.73...10.88 psi -5...75 kPa
Analog end point
200...1000 mbar 2.9...14.5 psi 20...100 kPa
In steps of
1 mbar 0.01 psi 0.1 kPa
Factory setting
SP1 = 250 mbar rP1 = 230 mbar
SP2 = 750 mbar rP2 = 730 mbar
ASP = 0 mbar AEP = 1000 mbar
Accuracy / deviations of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Switch point accuracy [% of the span] < ± 0,2; (Turn down 1:1)
Repeatability [% of the span] < ± 0,1; (with temperature fluctuations < 10 K; Turn down 1:1)
Characteristics deviation [% of the span] < ± 0,2; (Turn down 1:1 , linearity, incl. hysteresis and repeatability , limit value setting to DIN EN IEC 62828-1)
Linearity deviation [% of the span] < ± 0,15; (Turn down 1:1)
Hysteresis deviation [% of the span] < ± 0,15; (Turn down 1:1)
Long-term stability [% of the span] < ± 0,1; (Turn down 1:1; per year)
Temperature coefficient zero point [% of the span / 10 K] < ± 0,05; (0...70 °C)
Temperature coefficient span [% of the span / 10 K] < ± 0,15; (0...70 °C)
Reaction times of IFM PI2797 Flush Pressure Sensors With Display PI-001BREA01-MFRKG/US/ /P Inductive sensors In Stock
Damping for the switching output dAP [s] 0...30
Damping for the analog output dAA [s] 0.01...99.99
