Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
Description of Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New6ES7134-6JF00-0CA1SIMATIC ET 200SP, Analog input module, AI 8xRTD/TC 2-wire High Feature suitable for BU type A0, A1, Color code CC00, channel diagnostics, 16 bit, +/-0.1%
General information of Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
Product type designation AI 8xRTD/TC 2-wire HF, PU 1
HW functional status From FS05
Firmware version
● FW update possible Yes
usable BaseUnits BU type A0, A1
Color code for module-specific color identification plate CC00
Product function of Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
● I&M data Yes; I&M0 to I&M3
● Isochronous mode No
● Measuring range scalable Yes
Engineering with
● STEP 7 TIA Portal configurable/integrated from
version
V14 / -
● PROFIBUS from GSD version/GSD revision One GSD file each, Revision 3 and 5 and higher
● PROFINET from GSD version/GSD revision GSDML V2.3
Operating mode
● Oversampling No
● MSI No
Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
CiR - Configuration in RUN
Reparameterization possible in RUN Yes
Calibration possible in RUN Yes
Supply voltage
Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Reverse polarity protection Yes
Input current
Current consumption, max. 35 mA
Power loss
Power loss, typ. 0.75 W
Address area
Address space per module
● Address space per module, max. 16 byte; + 1 byte for QI information
Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
Analog inputs
Number of analog inputs 8
permissible input voltage for voltage input (destruction
limit), max.
30 V
Constant measurement current for resistance-type
transmitter, typ.
2 mA
Cycle time (all channels), min. Sum of the basic conversion times and additional processing times
(depending on the parameterization of the active channels)
Technical unit for temperature measurement adjustable Yes; °C/°F/K
Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
Input ranges (rated values), voltages
● -1 V to +1 V Yes; 16 bit incl. sign
— Input resistance (-1 V to +1 V) 1 MΩ
● -250 mV to +250 mV Yes; 16 bit incl. sign
— Input resistance (-250 mV to +250 mV) 1 MΩ
● -50 mV to +50 mV Yes; 16 bit incl. sign
— Input resistance (-50 mV to +50 mV) 1 MΩ
● -80 mV to +80 mV Yes; 16 bit incl. sign
— Input resistance (-80 mV to +80 mV) 1 MΩ
Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
Ambient conditions
Ambient temperature during operation
● horizontal installation, min. -30 °C; < 0 °C as of FS05
● horizontal installation, max. 60 °C
● vertical installation, min. -30 °C; < 0 °C as of FS05
● vertical installation, max. 50 °C
Altitude during operation relating to sea level
● Installation altitude above sea level, max. 5 000 m; Restrictions for installation altitudes > 2 000 m, see manual
Accessory of Siemens 6ES7134-6JF00-0CA1 SIMATIC ET 200SP Analog Input Modules 6ES71346JF000CA1 PLC Modules In Stock Brand Original New
6ES7193-6BP00-0BA0
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+2B, BU type A0, Push-in terminals, without AUX terminals, bridged to the left, WxH: 15x 117 mm
6ES7193-6BP00-0BA1
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+2B/T, BU type A1, Push-in terminals, without AUX terminals, bridged to the left, WxH: 15x 117 mm, with temperature acquisition
6ES7193-6BP00-0DA0
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+2D, BU type A0, push-in terminals, without aux. terminals, new load group, WxH: 15x 117 mm
6ES7193-6BP00-0DA1
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+2D/T, BU type A1, Push-in terminals, without AUX terminals, New load group, WxH: 15x 117 mm, with temperature acquisition
6ES7193-6BP20-0BA0
SIMATIC ET 200SP, BaseUnit BU15-P16+A10+2B, BU type A0, Push-in terminals, with 10 AUX terminals, bridged to the left, WxH: 15 mmx141 mm
6ES7193-6BP20-0DA0
SIMATIC ET 200SP, BaseUnit BU15-P16+A10+2D, BU type A0, Push-in terminals, with 10 AUX terminals, New load group, WxH: 15 mmx141 mm
6ES7193-6BP40-0BA1
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+12B/T, BU type A1, Push-in terminals, with 2x 5 add-on terminals, bridged to the left, WxH: 15 mm x 141 mm, with temperature acquisition
6ES7193-6BP40-0DA1
SIMATIC ET 200SP, BaseUnit BU15-P16+A0+12D/T, BU type A1, Push-in terminals, with 2x 5 add-on terminals, New load group, WxH: 15 mm x 141 mm, with temperature acquisition
