TECHNICAL PROFILE: SPIDER-SL-20-01T1M29999SZ9HHHH
PRODUCT SUMMARY: A fixed-configuration unmanaged Fast Ethernet rail switch with one copper RJ45 interface and one 1300 nm multimode fiber SC interface. Its compact housing and low power draw make it suitable for point-to-point industrial fiber extensions.
SELECTION DATA
| Management | Unmanaged, store-and-forward |
| Copper interface | 1 × 10/100BASE-TX RJ45 |
| Fiber interface | 1 × 100BASE-FX multimode SC |
| Fiber reach | Up to 5 km on 50/125 µm MM fiber; up to 4 km on 62.5/125 µm MM fiber |
| Power input | 12/24 VDC (9.6–32 VDC) |
| Power consumption | Maximum 2.0 W |
| Protection | IP30 |
| Operating temperature | 0°C to +60°C |
PRE-ORDER VERIFICATION
Confirm multimode fiber type, SC connector polish, link distance, optical budget, cabinet voltage, DIN-rail clearance and the required regional approvals. This device does not provide managed functions such as VLAN configuration or ring management.
SUPPLIED HIRSCHMANN SPIDER REFERENCE TABLE
The attachment table follows in full. Its 942132005 / SY9 entry is retained as supplied and should not be confused with the requested SZ9 main model.
| SPIDER Family | Order Code | Description | Product Code |
|---|---|---|---|
| SPIDER III Standard Line Switches | 942132001 | 5 x 10/100Base-TX | SPIDER-SL-20-05T1999999SY9HHHH |
| 942132016 | 5 x 10/100Base-TX* | SPIDER-SL-20-05T1999999TY9HHHH | |
| 942132002 | 8 x 10/100Base-TX | SPIDER-SL-20-08T1999999SY9HHHH | |
| 942132017 | 8 x 10/100Base-TX* | SPIDER-SL-20-08T1999999TY9HHHH | |
| 942335003 | 5 x 10/100/1000Base-T | SSR40-5TX | |
| 942335013 | 5 x 10/100/1000Base-T with QoS for Ethernet/IP | SSR40-5TX-IP | |
| 942335023 | 5 x 10/100/1000Base-T with QoS for PROFINET | SSR40-5TX-PN | |
| 942335004 | 8 x 10/100/1000Base-T | SSR40-8TX | |
| 942335014 | 8 x 10/100/1000Base-T with QoS for Ethernet/IP | SSR40-8TX-IP | |
| 942335024 | 8 x 10/100/1000Base-T with QoS for PROFINET | SSR40-8TX-PN | |
| 942132005 | 1 x 10/100Base-TX, 1 x 100Base-FX, MM-SC | SPIDER-SL-20-01T1M29999SY9HHHH | |
| 942132006 | 1 x 10/100Base-TX, 1 x 100Base-FX, SM-SC | SPIDER-SL-20-01T1S29999SY9HHHH | |
| 942132007 | 4 x 10/100Base-TX, 1 x 100Base-FX, MM-SC | SPIDER-SL-20-04T1M29999SY9HHHH | |
| 942132018 | 4 x 10/100Base-TX, 1 x 100Base-FX, MM-SC* | SPIDER-SL-20-04T1M29999TY9HHHH | |
| 942132008 | 4 x 10/100Base-TX, 1 x 100Base-FX, MM-ST | SPIDER-SL-20-04T1M49999SY9HHHH | |
| 942132019 | 4 x 10/100Base-TX, 1 x 100Base-FX, MM-ST* | SPIDER-SL-20-04T1M49999TY9HHHH | |
| 942132009 | 4 x 10/100Base-TX, 1 x 100Base-FX, SM-SC | SPIDER-SL-20-04T1S29999SY9HHHH | |
| 942132010 | 6 x 10/100Base-TX, 1 x 100Base-FX, MM-SC | SPIDER-SL-20-06T1M29999SY9HHHH | |
| 942132011 | 6 x 10/100Base-TX, 1 x 100Base-FX, SM-SC | SPIDER-SL-20-06T1S29999SY9HHHH | |
| 942132012 | 6 x 10/100Base-TX, 2 x 100Base-FX, MM-SC | SPIDER-SL-20-06T1M2M299SY9HHHH | |
| 942132013 | 6 x 10/100Base-TX, 2 x 100Base-FX, SM-SC | SPIDER-SL-20-06T1S2S299SY9HHHH | |
| 942335015 | 6 x 10/100/1000Base-T, 2 x FE/GE SFP Slot | SSR40-6TX/2SFP | |
| SPIDER III Power over Ethernet Switches | 942274007 | 4 x 10/100BASE-TX, 1 x 100BASE-FX, SM-SC, PoE | SPIDER-SL-24-04T1S29999TY9HHHH |
| 942274005 | 4 x 10/100BASE-TX, 1 x 100BASE-FX, MM-SC, PoE | SPIDER-SL-24-04T1M29999TY9HHHH | |
| 942274009 | 5 x 10/100BASE-TX, PoE | SPIDER-SL-24-05T1999999TY9HHHH | |
| 942274002 | 5 x 10/100/1000BASE-T, PoE | SPIDER-SL-44-05T1999999TY9HHHH | |
| 942274001 | 5 x 10/100/1000BASE-T, 1 x FE/GE SFP Slot, PoE | SPIDER-SL-44-05T1O69999TY9HHHH | |
| 942274003 | 8 x 10/100/1000BASE-T, PoE | SPIDER-SL-44-08T1999999TY9HHHH | |
| 942274004 | 8 x 10/100/1000BASE-T, 2 x FE/GE SFP Slot, PoE | SPIDER-SL-44-08T1O6O699TY9HHHH | |
| SPIDER III Premium Line Switches | 942335017 | 8 x 10/100Base-TX | SPR20-8TX-EEC |
| 942335020 | 8 x 10/100/1000Base-T | SPR40-8TX-EEC | |
| 942335028 | 8 x 10/100Base-TX, 1 x 100Base-FX, MM-SC | SPR20-8TX/1FM-EEC | |
| 942335030 | 7 x 10/100Base-TX, 2 x 100Base-FX, MM-SC | SPR20-7TX/2FM-EEC | |
| 942335031 | 7 x 10/100Base-TX, 2 x 100Base-FX, SM-SC | SPR20-7TX/2FS-EEC | |
| 942335033 | 1 x 10/100/1000Base-T, 1 x FE/GE SFP Slot | SPR40-1TX/1SFP-EEC | |
| 942141036 | 16 x 10/100BASE-TX | SPIDER-PL-20-16T1999999TY9HHHV | |
| 942141037 | 24 x 10/100BASE-TX, 2 x FE SFP Slot | SPIDER-PL-20-24T1Z6Z699TY9HHHV |
REQUEST PRICE, AVAILABILITY AND LEAD TIME
Email: becky@hkxytech.com
Mobile/WhatsApp/WeChat: +86 15972186287
Technical note: Confirm the manufacturer's current datasheet, exact order number, compatible transceivers, software release, approvals and lifecycle status before purchase.
