TECHNICAL PROFILE: GRS105-24TX/6SFP-2HV-2A, ORDER 942287002
PRODUCT SUMMARY: This GREYHOUND 105 configuration is a 30-port managed industrial Ethernet switch with six 1/2.5GE SFP slots, 24 Gigabit copper ports and two 110–240 VAC power supplies.
SELECTION DATA
| Model | GRS105-24TX/6SFP-2HV-2A |
| Order number | 942287002 |
| Fiber interfaces | 6 × 1/2.5GE SFP |
| Copper interfaces | 24 × Gigabit Ethernet TX |
| Power arrangement | 2 × 110–240 VAC |
| Mechanical format | Fanless 1U 19-inch rack mount |
PRE-ORDER CHECKS
Confirm the complete suffix, supported HiOS release, transceiver speed, fiber type, optical budget, link distance and required approvals. Plan independent power feeds when redundant operation is required.
INSTALLATION PLANNING
Verify rack depth, grounding, cable bend radius and access to management connections. SFP modules should be selected separately for each optical link.
SUPPLIED SHEET 2 REFERENCE TABLE
The attachment follows in full with its original three columns and blank cells preserved.
| Product Description | Port Type and Quantity | Product Detail |
|---|---|---|
| GREYHOUND 105/106 Series, Managed Industrial Aggregation Layer Switch, fanless design, 19″ rack mount, up to 14 fiber ports and 30 ports in total. MACsec in accordance to IEEE 802.1AE and with up to 24 PoE++ ports. | 6 x 1/2.5 GE SFP + 24 x GE TX | GRS105-24TX/6SFP-1HV-2A |
| GRS105-24TX/6SFP-2HV-2A | ||
| GRS105-24TX/6SFP-2HV-3AUR | ||
| 6 x 1/2.5 GE SFP + 8 x GE SFP + 16 x GE TX | GRS105-16TX/14SFP-1HV-2A | |
| GRS105-16TX/14SFP-2HV-2A | ||
| GRS105-16TX/14SFP-2HV-3AUR | ||
| 6 x 1/2.5/10 GE SFP + 8 x 1/2.5 GE TX + 16 x GE TX | GRS106-24TX/6SFP-1HV-2A | |
| GRS106-24TX/6SFP-2HV-2A | ||
| GRS106-24TX/6SFP-2HV-3AUR | ||
| 6 x 1/2.5/10 GE SFP + 8 x 1/2.5 GE SFP + 16 x GE TX | GRS106-16TX/14SFP-1HV-2A | |
| GRS106-16TX/14SFP-2HV-2A | ||
| GRS106-16TX/14SFP-2HV-3AUR | ||
| 2 x 1/2.5 GE SFP + 4 x GE SFP with MACsec + 24 x GE TX | GRS115-24TX/6SFP-2HV-2A - on request | |
| 2 x 1/2.5/10 GE SFP + 4 x 1/10 GE SFP with MACsec + 8 x 1/2.5 GE TX | GRS116-24TX/6SFP-2HV-2A - on request | |
| 6 x 1/2.5 GE SFP + 24 x GE TX with PoE++ | GRS125-24TX/6SFP-2HV-2A | |
| 6 x 1/2.5/10 GE SFP + 8 x 1/2.5 GE TX with PoE++ | GRS126-24TX/6SFP-2HV-2A |
REQUEST PRICE, AVAILABILITY AND LEAD TIME
Email: becky@hkxytech.com
Mobile/WhatsApp/WeChat: +86 15972186287
Technical note: Confirm the current manufacturer datasheet, exact order number, compatible optics, software and approvals before purchase.
