HIRSCHMANN DRAGON MACH4000 GIGABIT BACKBONE SWITCH IN STOCK
Request price, stock status and lead time for DRAGON MACH4000-48G+4X-L3A-UR, part number 942154002, using the complete order reference.
48-PORT MODULAR 10GE INDUSTRIAL CORE
This active DRAGON MACH4000 configuration delivers a full Gigabit Ethernet backbone with four 1/2.5/10GE SFP+ uplinks, modular expansion and HiOS Layer 3 unicast routing. It is suited to power, transportation, process industry and large automation networks requiring flexible high-density connectivity.
QUOTE AND SELECTION CHECKLIST
Confirm part number 942154002 and the complete L3A-UR model
Specify required copper, SFP and PoE media modules
Confirm one or two high-voltage power-supply units
Check optical transceiver type, wavelength and distance
Verify unicast routing, redundancy and software requirements
Ask for current price, availability and delivery schedule
| DRAGON MACH4000/4500 | |||
|---|---|---|---|
| Sub-Group | Ordering Code | Part Number/Model | Detailed Product Description |
| DRAGON MACH4500 Chassis | 942153001 | DRAGON MACH4500-80G+8X-L2A | DRAGON MACH4500 Chassis with 8x10G (SFP+ - Fixed) + 32x1G (TX - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L2A |
| 942153002 | DRAGON MACH4500-80G+8X-L3A-UR | DRAGON MACH4500 Chassis with 8x10G (SFP+ - Fixed) + 32x1G (TX - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L3A UR (Unicast Routing only) | |
| 942153003 | DRAGON MACH4500-80G+8X-L3A-MR | DRAGON MACH4500 Chassis with 8x10G (SFP+ - Fixed) + 32x1G (TX - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L3A MR (Unicast + Multicast Routing) | |
| DRAGON MACH4000 Chassis | 942154001 | DRAGON MACH4000-48G+4X-L2A | DRAGON MACH4000 Chassis with 4x10G (SFP+ - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L2A |
| 942154002 | DRAGON MACH4000-48G+4X-L3A-UR | DRAGON MACH4000 Chassis with 4x10G (SFP+ - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L3A UR (Unicast Routing only) | |
| 942154003 | DRAGON MACH4000-48G+4X-L3A-MR | DRAGON MACH4000 Chassis with 4x10G (SFP+ - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L3A MR (Unicast + Multicast Routing) | |
| 942318001 | DRAGON MACH4000-52G-L2A | DRAGON MACH4000 Chassis with 4x1G (SFP+ - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L2A | |
| 942318002 | DRAGON MACH4000-52G-L3A-UR | DRAGON MACH4000 Chassis with 4x1G (SFP+ - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L3A UR (Unicast Routing only) | |
| 942318003 | DRAGON MACH4000-52G-L3A-MR | DRAGON MACH4000 Chassis with 4x1G (SFP+ - Fixed) + 48x1G (with modules); Fan Unit Installed; HiOS L3A MR (Unicast + Multicast Routing) | |
| Components | 942155001 | D4K-12TP-RJ45, Linecard | DRAGON MACH4K Module with 12 x RJ45 10/100/1000 Ports |
| 942155501 | D4K-12SFP, Linecard | DRAGON MACH4K Module with 12 x 100/1000 SFP Ports | |
| 942294001 | D4K-10TP-PoE, Linecard | DRAGON MACH4K Module with 10 x 100/1000/10000 RJ45 PoE Ports | |
| 942156001 | D4K-PSU-300W-HV, PowerSupply | DRAGON 4K 300-Watt High Voltage Power Supply Unit | |
| 942157001 | D4K-AIR, Fan Unit | DRAGON M4K Fan Unit; field-replaceable / hot-swappable; 5 load sharing inbuilt fans | |
| Blank Panels | 942222001 | D4K-LC-PANEL | Blind Panel to cover one empty Line Card Slot if module is not used |
| 942222002 | D4K-PSU-PANEL | Blind Panel to cover redundant PSU Slot if second PSU is not used | |
REQUEST PRICE, AVAILABILITY AND LEAD TIME
Email: becky@hkxytech.com
Mobile/WhatsApp/WeChat: +86 15972186287
Technical note: Confirm the complete configuration and current manufacturer documentation before purchase.
