BAT-ANT-N-MIMO5-18N-IP65 PRODUCT OVERVIEW
BAT-ANT-N-MiMo5-18N-IP65 is an exact Hirschmann ordering reference for industrial communication, replacement and project sourcing. Confirm the complete configuration before ordering.
SELECTED CONFIGURATION
Product family: Hirschmann BAT-ANT
Ordering model: BAT-ANT-N-MiMo5-18N-IP65
PRODUCT POSITIONING
This configuration supports project evaluation where reliable industrial data connectivity and lifecycle continuity are important.
INDUSTRIAL APPLICATIONS
Project teams may assess it for plant-floor, control-room and distributed infrastructure connectivity according to the selected interfaces.
ORDERING CHECK
Review topology, media type, installation conditions and accessory requirements with the project bill of materials.
HIRSCHMANN BAT WIRELESS ORDERING DATA
| Order No. | Product Name | Description |
|---|---|---|
| Virtual Wireless LAN Controllers | ||
| 942313001 | BAT Controller License 100 | Up to 100 managed Access Points or VPN tunnels, 64 ARF routing contexts, 500 MBit/s throughput limit (through the Controller, unlimited traffic can also directly go into the network from the Access Points) |
| 942313002 | BAT Controller License 200 | Up to 200 managed Access Points or VPN tunnels, 128 ARF routing contexts, 500 MBit/s throughput limit (through the Controller, unlimited traffic can also directly go into the network from the Access Points) |
| 942313010 | BAT Controller License 1000 | Up to 1000 managed Access Points or VPN tunnels, 256 ARF routing contexts, throughput is not limited |
| Wireless LAN Antennas | ||
| 943981002 | BAT-ANT-N-6G-IP65 | Omnidirectional antenna for 2.4 GHz band, 6dBi Gain |
| 943981003 | BAT-ANT-N-5A-IP65 | Omnidirectional antenna for 5 GHz band, 5dBi Gain |
| 943981004 | BAT-ANT-N-6ABG-IP65 | Hemispherical Omnidirectional antenna for 2.4 and 5 GHz band; 6dBi at 2.4GHz, 8dBi at 5GHz |
| 943981005 | BAT-ANT-N-14G-IP23 | Directional antenna for 2.4 GHz with 14 dBi gain |
| 943981006 | BAT-ANT-N-18A-V-IP65 | Directional antenna for 5 GHz with 18dBi gain |
| 943981009 | BAT-ANT-N-8G-DS-IP65 | Directional diversity antenna linear for 2.4 GHz with 8.5dBi gain |
| 943981010 | BAT-ANT-N-9A-DS-IP65 | Directional diversity antenna linear for 5 GHz with 9dBi gain |
| 943981012 | BAT-ANT-N-MiMoDB-5N-IP65 | Omni-directional dual band antenna for MiMo for the 2.4GHz and 5GHz band |
| 943981016 | BAT-ANT-N-MiMoDB-6N-IP65 | 2.4G/5.8G WiFi Omni Antenna, 6dBi, VSWR≤1.5, φ145×180mm |
| 943981017 | BAT-ANT-N-MiMoDB-11N-IP65 | 2.4G/5.8G WiFi Directional Antenna, 10/11dBi, VSWR≤1.8, 261x261x35mm |
| 943981018 | BAT-ANT-SMA-MiMoDB-4N-IP65 | 2.4G/5.8G WiFi Omni Antenna, 3/4dBi, VSWR≤2.0, φ90×40mm, RP-SMA female with cable length 1 meter |
| 942046001 | BAT-ANT-RSMA-2AGN-R (10pcs) | 2.4G/5G WiFi Omni Antenna, 3/5dBi, VSWR≤2.0, φ21 mm × 160 mm, Reverse-SMA male connector |
| 943981013 | BAT-ANT-N-MiMo5-9N-IP65 | Directional diversity antenna for usage with 802.11n, 9dBi at 5GHz |
| 943981014 | BAT-ANT-N-MiMo5-18N-IP65 | 5 GHz MiMo antenna for sectoral illumination with high amplification factor |
| 943903373 | BAT-ANT-Protector m-f | Overvoltage protector for antennas N jack to N plug; frequency range 2 GHz-6 GHz; attenuation up to 0.2 dB |
| 943903360 | BAT-Pigtail | Adapter cable (N female/RP-SMA-Plug), attenuation 0.5 dB at 2.4GHz, 1dB at 5GHz |
| 943903513 | BAT-CLB-2 N m-m | Antenna cable 2 m, N plug to N plug, Attenuation 2 dB at 2.4 GHz, 3 dB at 5 GHz |
| 943903514 | BAT-CLB-2 N m-f | Antenna Cable. 2m, N-plug to N-jack, 2,4GHz to 6GHz, Attenuation 1.4 dB at 2.4 GHz, 3 dB at 5 GHz |
| 943903516 | BAT-CLB-5 N m-f | Antenna Cable. 5m, N-plug to N-jack, 2,4GHz to 6GHz, Attenuation 1.3 dB at 2.4 GHz, 2.3 dB at 5 GHz |
| 943903515 | BAT-CLB-15 N m-f | Antenna cabel. 15 m, N-plug to N-jack, 2.4GHz to 6GHz , Attenuation 3 dB at 2.4 GHz, 4 dB at 5 Ghz |
| 942042105 | WWAN-A-I-41-S-0 (1 pcs) | Omnidirectional antenna |
| 943981117 | BAT-ANT-N-MiMoDB-11N-IP65-R | 2.4G/5.8G WiFi Directional Antenna, 10/11dBi, VSWR≤1.8, 261x261mm, reinforced Bracket: JM-TD2A |
HIRSCHMANN BAT COMPLETE MODEL DIRECTORY
All 25 populated model entries from the supplied workbook are reproduced below for configuration, replacement and sourcing enquiries.
BAT Controller License 100
BAT Controller License 200
BAT Controller License 1000
BAT-ANT-N-6G-IP65
BAT-ANT-N-5A-IP65
BAT-ANT-N-6ABG-IP65
BAT-ANT-N-14G-IP23
BAT-ANT-N-18A-V-IP65
BAT-ANT-N-8G-DS-IP65
BAT-ANT-N-9A-DS-IP65
BAT-ANT-N-MiMoDB-5N-IP65
BAT-ANT-N-MiMoDB-6N-IP65
BAT-ANT-N-MiMoDB-11N-IP65
BAT-ANT-SMA-MiMoDB-4N-IP65
BAT-ANT-RSMA-2AGN-R (10pcs)
BAT-ANT-N-MiMo5-9N-IP65
BAT-ANT-N-MiMo5-18N-IP65
BAT-ANT-Protector m-f
BAT-Pigtail
BAT-CLB-2 N m-m
BAT-CLB-2 N m-f
BAT-CLB-5 N m-f
BAT-CLB-15 N m-f
WWAN-A-I-41-S-0 (1 pcs)
BAT-ANT-N-MiMoDB-11N-IP65-R
