​Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived

News November 13, 2020

Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived





Brief Description of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived


Our Bulletin 1769 CompactLogix™ L3x controllers are ideal for small to mid-size control applications that don’t require motion or safety functionality. These controllers offer integrated serial, EtherNet/IP™, or ControlNet™ channels; and modular DeviceNet™ communications.



Overview of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived



*  Includes a built-in RS-232 serial port on every 1769-L3x controller

*  Offers built-in communication ports for EtherNet/IP or ControlNet networks

*  Includes a 1769-SDN communication interface module for I/O control and remote device configuration over DeviceNet

*  Lets you control distributed I/O via EtherNet/IP, ControlNet, or DeviceNet (select models only)

*  Provides seamless bridging with data control and collection over the same network

*  Integrates with 1769 Compact I/O™ modules

*  Offers flexible user memory options

*  Does not require a chassis




Specifications of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived


Part Number: 1769-L32E

Available user memory: 750 KB

CompactFlash card: 1784-CF128

Communication ports:

1 EtherNet/IP port

1 RS-232 serial port (DF1 or ASCII)

Module expansion capacity: 16 1769 modules

Power supply distance rating: 4 modules



Additional Information of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived



Our CompactLogix L23x Controllers (Bulletin 1769) are discontinued and no longer available for sale.  To support your transition, we recommend that you migrate to our CompactLogix 5380 control platform.



Rockwell Automation announces that as of December 2020, our CompactLogix controllers catalog numbers 1769-L32E, 1769-L32EK and 1769-L35E will be discontinued and no longer available for sale. To support your transition, we recommend that you migrate to our CompactLogix 5380 control platform.





Technical Specifications of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived


Manufacturer Rockwell Automation / Allen-Bradley

Brand Allen-Bradley

Part Number/Catalog No. 1769-L32E

Product Line CompactLogix

Product Type: Programmable Automation Controller

Module Type Processor Module

Communication Ethernet/IP

Communication ports: 1 RS232; 1 Ethernet

Software RSLogix5000

Supported Protocols: DH485; DF1; ASCII; EtherNet

Memory 750 KB

Maximum number of I/O modules supported: 16 Modules

Shipping Weight 2 pounds

Maximum number of I/O banks supported: 3 banks

Shipping Dimensions 8 x 8 x 5 inches

Power supply distance rating: 4

Series A and B

Battery 1747-BA

Programming cable: 1747-CP3 / 1756-CP3

Wire Type Copper-90 degrees Celsius

Wire Size (Solid) 22 to 14 AWG

Vibration: Operating: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak

Modules Supported 16 I/O Modules

Operating Temperature: 0° to +60°C (+32° to +140°F)

Wire Size (Stranded) 22 to 16 AWG

Programming Language: Relay ladder, Structured Text, Function block, SFC

Programming Software: RSLogix 5000 / Studio 5000 Logix Designer

UPC 10612598313935

Mounting: DIN Rail; Panel Mounting

UNSPSC 32151705

Certifications: c-UL-us; CE; C-Tick; CI



Ordering Codes of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived


1769 CompactLogix Controllers

Catalog Numbers 1769-L31, 1769-L32C, 1769-L32E, 1769-L35CR, 1769-L35E




CompactLogix Controllers Specifications of Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived



CompactLogix 5370 Controller Catalog Numbers

1769-L16ER-BB1B, 1769-L18ER-BB1B, 1769-L18ERM-BB1B, 1769-L19ER-BB1B,1769-L24ER-QB1B, 1769-L24ER-QBFC1B, 1769-L24ER-QBFC1BK, 1769-L27ERMQBFC1B,1769-L30ER, 1769-L30ER-NSE, 1769-L30ERM, 1769-L30ERMK, 1769-L30ERMS, 1769-L33ER, 1769-L33ERM, 1769-L33ERMK, 1769-L33ERMS,1769-L33ERMSK, 1769-L36ERM, 1769-L36ERMS, 1769-L37ERM, 1769-L37ERMK,1769-L37ERMS, 1769-L37ERMSK, 1769-L38ERM, 1769-L38ERMK, 1769-L38ERMS,1769-L38ERMSK


Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived



Armor CompactLogix and Armor Compact GuardLogix

Controller Catalog Numbers

1769-L33ERMO, 1769-L33ERMOS, 1769-L36ERMO, 1769-L36ERMOS, 1769-L37ERMO,

1769-L37ERMOS,1769-L38ERMO, 1769-L38ERMOS



1769 Packaged Controller Catalog Numbers

1769-L23-QBFC1B, 1769-L23E-QB1B, 1769-L23E-QBFC1B


Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived



1769 Modular Controller Catalog Numbers

1769-L31, 1769-L32C, 1769-L35CR, 1769-L32E, 1769-L32EK, 1769-L35E



1768 Controller Catalog Numbers

1768-L43, 1768-L43S, 1768-L45, 1768-L45S



Memory Card Catalog Numbers

1784-CF128, 1784-SD1, 1784-SD2


Allen Bradley 1769-L32E CompactLogix EtherNet Processor 1769-L32E CompactLogix Controller Arrived
