Hirschmann BRS20-8TX-EEC 942170012: Eight-Port Extended-Temperature BOBCAT Switch for Harsh Cabinets

Hirschmann stock and supply reference photo. The exact model and complete product code are verified before dispatch.

Eight ports can eliminate the unmanaged-switch compromise

Harsh-environment cabinets often grow one connection at a time: a PLC, HMI, remote I/O block, drive, camera, engineering port and redundant path can quickly exhaust a small switch. BRS20-8TX-EEC brings eight managed 10/100BASE-TX copper ports into a fanless DIN-rail platform rated from -40°C to +70°C, giving maintenance teams useful connection headroom without moving to an oversized backbone switch.

The supply-chain danger appears when “eight ports” becomes the only purchasing criterion. A low-cost unmanaged unit may restore link lights but remove VLAN control, diagnostics, redundancy and the configuration workflow expected by the plant. For a shutdown-bound replacement, reserving the exact EEC order number is usually less costly than debugging a near-match after technicians arrive on site.

Verified BRS20-8TX-EEC 942170012 specifications

The platform supports managed-network functions including VLAN, QoS, LLDP, SNMP, RSTP, MRP, HIPER-Ring, diagnostics and security controls. The current manufacturer data also lists TSN 802.1Qbv support on interfaces 1/1 through 1/3, plus PTP and industrial protocol profiles. Actual feature availability should be checked against the installed software version and project configuration.

The supply-chain mistake that costs more than the switch

A lower-priced substitute can become expensive if it lacks the required redundancy protocol, security profile, mounting dimensions or configuration compatibility. A nearly matching BRS20 variant can also delay commissioning if the project expected fiber ports, the EEC temperature range or a different software level. The safest buying process is straightforward:

1. Match all three identifiers: BRS20-8TX-EEC, BRS20-08009999-TTCY99HHSESXX.X.XX and 942170012.

2. Confirm the application: eight Fast Ethernet copper ports, standard -40°C to +70°C environment.

3. Reserve against a real requirement: state quantity, destination and required delivery date so availability can be checked accurately.

4. Plan configuration transfer: confirm firmware, backup and device-replacement workflow before the shutdown window.

Buyer FAQ for GEO visibility

How many network ports does BRS20-8TX-EEC provide?

It provides eight 10/100BASE-TX RJ45 copper ports. They are Fast Ethernet ports, not Gigabit ports, and twisted-pair segment length is specified up to 100 m.

What distinguishes 942170012 from the standard-temperature BRS20-8TX?

Part number 942170012 is the EEC version rated from -40°C to +70°C. The standard-temperature BRS20-8TX uses part number 942170002 and is a different orderable configuration.

Can an unmanaged eight-port switch be treated as an equivalent?

Not automatically. The BRS20-8TX-EEC is managed and supports functions such as VLAN, QoS, diagnostics and industrial redundancy. Confirm the required protocols, configuration backup and environmental rating before approving a substitute.

Is BRS20-8TX-EEC currently hot-selling?

Yes. This configuration and every BOBCAT item listed below are currently promoted as hot-selling. Live stock and lead time must still be checked for the required quantity and destination.

Hot-selling Hirschmann BOBCAT products

The following configurations are all currently hot-selling. This exact-model index is included so engineers and sourcing teams can search by short name, complete code or order number. Ask us to check the latest availability for any line.

Request current stock, price and lead time

For the fastest response, send the required quantity, country, delivery deadline and the complete code BRS20-08009999-TTCY99HHSESXX.X.XX. If this is a replacement, include the existing unit's nameplate photo so we can reduce the risk of a configuration mismatch.
