Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Product Overview of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Hirschmann MACH102-8TP Modular Ethernet Switch, 8 x 10/100Base-TX Ports Fixed, 2 FE/GE Combo Ports, 2 Open 8-Port Media Module Slots (Media Modules Sold Separately), 100-240 VAC Powered, 19" Rackmount, Professional Management.

MACH102 switches are intended for basic standalone applications; for backbone applications consider MACH104 switches.

Port Type & Quantity of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Up to 26 Ethernet ports

Up to 16 Fast-Ethernet ports via media modules realiable

8x TP (10/100 BASE-TX, RJ45) Fast Ethernet ports

2 Fast Ethernet / Gigabit Combo ports

Features

Software: Layer 2 Professional

Operating voltage: 100 - 240 VAC, 47 - 63 Hz

Power input: 1 x plug-in terminal block, 2-pin

Product Description of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

26 port Fast Ethernet/Gigabit Ethernet Industrial Workgroup Switch (fix installed: 2 x GE, 8 x FE; via Media Modules 16 x FE), managed, Software Layer 2

Professional, Store-and-Forward-Switching, fanless Design

Technical Specifications of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Product description of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Description: 26 port Fast Ethernet/Gigabit Ethernet Industrial Workgroup Switch (fix installed: 2 x GE, 8 x FE; via Media Modules 16 x FE), managed, Software Layer 2 Professional,Store-and-Forward-Switching, fanless Design

Part Number: 943969001

Port type and quantity: Up to 26 Ethernet ports, thereof up to 16 Fast-Ethernet ports via media modules realisable; 8x TP (10/100 BASE-TX, RJ45) Fast Ethernet ports and 2 Gigabit Combo ports fix installed

More Interfaces of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Power supply/signaling

contact: 1 x plug-in terminal block, 2-pin, output manual or automatic switchable (max. 1 A, 24 V DC bzw. 24 V AC)

V.24 interface: 1 x RJ11 socket, serial interface for device configuration

USB interface: 1 x USB to connect auto-configuration adapter ACA21-USB

Network size - length of cable of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Twisted pair (TP): 0-100 m

Single mode fiber (SM)

9/125 µm: Fast Ethernet: see SFP LWL module M-FAST SFP-SM/LC and M-FAST SFP-SM+/LC; Gigabit Ethernet: see SFP LWL module M-SFP-LX/LC

Single mode fiber (LH) 9/125

µm (long haul transceiver): Fast Ethernet: see SFP LWL module M-FAST SFP-LH/LC; Gigabit Ethernet: see SFP LWL module M-SFP-LH/LC and M-SFP-LH+/LC

Multimode fiber (MM) 50/125

µm:

Fast Ethernet: see SFP LWL module M-FAST SFP-MM/LC; Gigabit Ethernet: see SFP LWL module M-SFP-SX/LC and M-SFP-LX/LC

Multimode fiber (MM)

62.5/125 µm: Fast Ethernet: see SFP LWL module M-FAST SFP-MM/LC; Gigabit Ethernet: see SFP LWL module M-SFP-SX/LC and M-SFP-LX/LC

Network size - cascadibility of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Line - / star topology: any

Ring structure (HIPER-Ring)

quantity switches: 50 (reconfiguration time 0.3 sec.)

Power requirements of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Operating Voltage: 100 - 240 VAC, 47 - 63 Hz

Power consumption: 12 W (without media modules)

Power output in BTU (IT)/h: 41 (without media modules)

Redundancy functions: HIPER-Ring, MRP, MSTP, RSTP - IEEE802.1D-2004, MRP and RSTP gleichzeitig, Link Aggregation, dual homing, link aggregation

Software of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Switching:

Disable Learning (hub functionality), Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP

Prioritization, Egress Broadcast Limiter per Port, Flow Control (802.3X), VLAN (802.1Q), GARP VLAN Registration Protocol (GVRP), Double VLAN Tagging (QinQ), Voice VLAN,

GARP Multicast Registration Protocol (GMRP), IGMP Snooping/Querier (v1/v2/v3)

Redundancy: Advanced Ring Configuration for MRP, HIPER-Ring (Manager), HIPER-Ring (Ring Switch), Fast HIPER-Ring, Link Aggregation with LACP, Media Redundancy Protocol (MRP)

(IEC62439-2), Redundant Network Coupling, RSTP 802.1D-2004 (IEC62439-1), MSTP (802.1Q), RSTP Guards

Management: Dual Software Image Support, TFTP, LLDP (802.1AB), LLDP-MED, SSHv1, SSHv2, V.24, HTTP, HTTPS, Traps, SNMP v1/v2/v3, Telnet

Diagnostics:

Management Address Conflict Detection, Address Relearn Detection, MAC Notification, Signal Contact, Device Status Indication, TCPDump, LEDs, Syslog, Port Monitoring with

Auto-Disable, Link Flap Detection, Overload Detection, Duplex Mismatch Detection, Link Speed and Duplex Monitoring, RMON (1,2,3,9), Port Mirroring 1:1, Port Mirroring 8:1,

Port Mirroring N:1, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check Dialog, Switch Dump

Configuration:

AutoConfiguration Adapter ACA11 Limited Support (RS20/30/40, MS20/30), Automatic Configuration Undo (roll-back), Configuration Fingerprint, BOOTP/DHCP Client with

Auto-Configuration, DHCP Server: per Port, DHCP Server: Pools per VLAN, DHCP Server: Option 43, AutoConfiguration Adapter ACA21/22 (USB), HiDiscovery, DHCP Relay

with Option 82, Command Line Interface (CLI), CLI Scripting, Full-featured MIB Support, Web-based Management, Context-sensitive Help

Security:

IP-based Port Security, MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, RADIUS VLAN Assignment, Multi-Client Authentication

per Port, MAC Authentication Bypass, Access to Management restricted by VLAN, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner,

SNMP Logging, Local User Management, Remote Authentication via RADIUS

Time synchronisation: Buffered Real Time Clock, SNTP Client, SNTP Server

Industrial Profiles: EtherNet/IP Protocol, PROFINET IO Protocol

Miscellaneous: Manual Cable Crossing

Ambient conditions of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MTBF (MIL-HDBK 217F: Gb

25 ºC): (without media modules) 15.67 Years

Operating temperature: 0-+50 °C

Storage/transport

temperature: -20-+85 °C

Relative humidity

(non-condensing): 10-95 %

Mechanical construction of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

Dimensions (WxHxD): 448 mm x 44 mm x 310 mm (without fixing bracket)

Weight: 3.60 kg

Mounting: 19" control cabinet

Protection class: IP20

Ordering Codes of Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH102-24TP-F

MACH102-24TP-FR

MACH102-24TP-F

MACH102-24TP-FR

MACH102-8TP

MACH102-8TP-F

MACH102-8TP-FR

MACH102-8TP-R

MACH104-20TX-F

MACH104-20TX-FR

MACH104-20TX-F-4PoE

MACH104-16TX-PoEP

MACH104-16TX-PoEP-R

MACH104-16TX-PoEP-E

MACH104-16TX-PoEP+2X

MACH104-16TX-PoEP+2X-R

MACH104-16TX-PoEP+2X-E

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

M1-8MM-SC

M1-8SFP

M1-8SM-SC

M1-8TP-RJ45

M1-8TP-RJ45 PoE

MACH4002 48+4G-L2P

MACH4002 48+4G-L3E

MACH4002 48+4G-L3P

MACH4002-24G-L2P

MACH4002-24G-L3E

MACH4002-24G-L3P

MACH4002-24G+3X-L2P

MACH4002-24G+3X-L3E

MACH4002-24G+3X-L3P

MACH4002-48G-L2P

MACH4002-48G-L3E

MACH4002-48G-L3P

MACH4002-48G+3X-L2P

MACH4002-48G+3X-L3E

MACH4002-48G+3X-L3P

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

M4-8TP-RJ45

M4-FAST 8-SFP

M4-FAST 8TP-RJ45-PoE

M4-GIGA 8-SFP

M4-AIR

M4-S-AC/DC 300W

M4-S-24VDC 300W

M4-S-48VDC 300W

M4-POWER

M4-P AC/DC

M4-P DC 24V

M4-P DC 48V

M4-POWERCABLE

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH102-8TP

MACH102-8TP-R

M1-8TP-RJ45

M1-8MM-SC

M1-8SM-SC

M1-8SFP

M1-8TP-RJ45 PoE

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH102-8TP-F

MACH102-8TP-FR

MACH102-24TP-F

MACH102-24TP-FR

MACH104-20TX-F

MACH104-20TX-FR

MACH104-20TX-F-4PoE

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH102-24TP-F

MACH102-24TP-FR

MACH102-8TP

MACH102-8TP-F

MACH102-8TP-FR

MACH102-8TP-R

MACH104-20TX-F

MACH104-20TX-FR

MACH104-20TX-F-4PoE

MACH104-16TX-PoEP

MACH104-16TX-PoEP-R

MACH104-16TX-PoEP-E

MACH104-16TX-PoEP+2X

MACH104-16TX-PoEP+2X-R

MACH104-16TX-PoEP+2X-E

M1-8MM-SC

M1-8SFP

M1-8SM-SC

M1-8TP-RJ45

M1-8TP-RJ45 PoE

MACH4002 48+4G-L2P

MACH4002 48+4G-L3E

MACH4002 48+4G-L3P

MACH4002-24G-L2P

MACH4002-24G-L3E

MACH4002-24G-L3P

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH4002 24G-L2PHC

MACH4002 24G-L3EHC

MACH4002 24G-L3PHC

MACH4002 48+4G-L2PHC

MACH4002 48+4G-L3EHC

MACH4002 48+4G-L3PHC

MACH4002 48G+3X-L2PHC

MACH4002 48G+3X-L3EHC

MACH4002 48G+3X-L3PHC

MACH4002-24G+3X-L2PHC

MACH4002-24G+3X-L3EHC

MACH4002-24G+3X-L3PHC

MACH4002-48G-L2PHC

MACH4002-48G-L3EHC

MACH4002-48G-L3PHC

MAR1020-99MM...UG9HPHC

MAR1020-99TT...UG9HPHC

MAR1030-CCMM...UG9HPHC

MAR1030-CCTT...UG9HPHC

MB-2T

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH102-8TP

MACH102-8TP-R

M1-8TP-RJ45

M1-8MM-SC

M1-8SM-SC

M1-8SFP

M1-8TP-RJ45 PoE

MACH102-8TP-F

MACH102-8TP-FR

MACH102-24TP-F

MACH102-24TP-FR

MACH104-20TX-F

MACH104-20TX-FR

MACH104-20TX-F-4PoE

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTUGGHP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUC9HP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUCCHP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUCGHP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1020-99ZZTTTTTTTTTTTTTTTTTTTTTTUGGHP

MAR1020-99ZZZZTTTTTTTTTTTTTTTTTTTTUGGHP

MAR1120-99NNTTTTTTTTTTTTTTTTTT9999FMMHP

MAR1122-99TTTTTTTTTTTTZZZZZZZZ9999UMMHP

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MAR1030-4OTTTTTTTTTTTTTTTT99999999SMMHP

MAR1030-4OTTTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1030-CCTTTTTTTTTTTTTTTTNNNNNNNNUGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTMMMMSGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTMMMMUGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUGGHP

MAR1030-CCVVTTTTTTTTTTTTTTTTTTTTTTUC9HP

MAR1030-CCVVVVTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCZZTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCZZZZTTTTTTTTTTTTTTTTTTTTFGGHP

MAR1030-CCZZZZTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1130-4TTTTTTTTTTTTTTTTTTTTT9999ULMHP

MAR1132-OTTTTTTTTTTTTTTTTTTTTT9999ULMHP

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MAR1040-4C4C4C4C9999EMMHP

MAR1040-4C4C4C4C9999SL9HP

MAR1040-4C4C4C4C9999SLLHP

MAR1040-4C4C4C4C9999SMMHP

MAR1040-4C4C4C4C9999TLLHP

MAR1040-4C4C4C4C9999TMMHP

MAR1140-4C4C4C4C9999SMMHP

MAR1140-4C4C4C4C9999TMMHP

MAR1140-4C4C4C4C9999EL9HP

MAR1140-4C4C4C4C9999SLLHP

MAR1042-4C4C4C4C9999EMMHP

MAR1042-4C4C4C4C9999SL9HP

MAR1042-4C4C4C4C9999SLLHP

MAR1042-4C4C4C4C9999SMMHP

MAR1042-4C4C4C4C9999TMMHP

MAR1040-4C4C4C4C9999TMMHR

MAR1040-4C4C4C4C9999SMMHR

MAR1040-4C4C4C4C9999EMMHR

MAR1140-4C4C4C4C9999EMMHR

MAR1140-4C4C4C4C9999TMMHR

MAR1140-4C4C4C4C9999SMMHR

MAR1042-4C4C4C4C9999SLLHR

MAR1042-4C4C4C4C9999TMMHR

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUC9HP

MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTUGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUGGHP

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MACH4002 48+4G-L2P 943 859-101

MACH4002 48+4G-L3E 943 859-201

MACH4002 48+4G-L3P 943 859-301

MACH4002-24G-L2P 943 916-101

MACH4002-24G-L3E 943 916-201

MACH4002-24G-L3P 943 916-301

MACH4002-24G+3X-L2P 943 915-101

MACH4002-24G+3X-L3E 943 915-201

MACH4002-24G+3X-L3P 943 915-301

MACH4002-48G-L2P 943 911-101

MACH4002-48G-L3E 943 911-201

MACH4002-48G-L3P 943 911-301

MACH4002-48G+3X-L2P 943 878-101

MACH4002-48G+3X-L3E 943 878-201

MACH4002-48G+3X-L3P 943 878-301

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MAR1030-CCTTTTTTTTTTTTTTTTNNNNNNNNUGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTMMMMSGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTMMMMUGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSG9HP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUG9HP

MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUGGHP

MAR1030-CCVVTTTTTTTTTTTTTTTTTTTTTTUC9HP

MAR1030-CCVVVVTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCZZTTTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1030-CCZZZZTTTTTTTTTTTTTTTTTTTTFGGHP

MAR1030-CCZZZZTTTTTTTTTTTTTTTTTTTTSGGHP

MAR1130-4TTTTTTTTTTTTTTTTTTTTT9999ULMHP

MAR1132-OTTTTTTTTTTTTTTTTTTTTT9999ULMHP

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

MAR1040-4C4C4C4C9999EMMHP

MAR1040-4C4C4C4C9999SL9HP

MAR1040-4C4C4C4C9999SLLHP

MAR1040-4C4C4C4C9999SMMHP

MAR1040-4C4C4C4C9999TLLHP

MAR1040-4C4C4C4C9999TMMHP

MAR1140-4C4C4C4C9999SMMHP

MAR1140-4C4C4C4C9999TMMHP

MAR1140-4C4C4C4C9999EL9HP

MAR1140-4C4C4C4C9999SLLHP

MAR1042-4C4C4C4C9999EMMHP

MAR1042-4C4C4C4C9999SL9HP

Hirschmann MACH102-8TP Modular Workgroup-Switches MACH102-8TP Industrial Rail Switches Arrived

We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.

We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.

Contact:

HONGKONG XIEYUAN TECH CO., LIMITED

Email:becky@hkxytech.com   Web:www.hkxytech.com

Mobile:+86-15972186287(Whatsapp & Wechat)
