Yokogawa ANB10D-425/CU2N/NDEL ESB Bus Node Units (for FIO) ANB10D-425/CU2N/NDEL DCS Module In Stock

ESB Bus Node Connection

When connecting an ESB Bus Node Unit to FCU, install ESB Bus Coupler Module (EC401 or EC402) to FCU (*1).

EC401 or EC402 must be installed in slot 7 and slot 8. To make single configuration, EC401 or EC402 must be

installed in slot 7, and Slot 8 must be empty.

EC402 can be installed in AFV30 or AFV40.

*1: AFV30, AFV40, AFV10, or AFF55.

 Power Supply

Specify with Suffix Codes

Voltage: 100-120 V AC, Frequency: 50/60 Hz

Voltage: 220-240 V AC, Frequency: 50/60 Hz

Voltage: 24 V DC

 Electric Power Consumption

100-120 V AC: 200 VA, 120 W

220-240 V AC: 230 VA, 120 W

24 V DC: 5.5 A

 Weight

10 kg (incl. 8 I/O Modules)

 Mounting

19-inch Rack Mounting

 Rack mount (M5 x 4 screws)

 Insulation bash (accessory)

 Regulatory Compliance

For the detailed information of following standards, see “System Overview” (GS 33K01A10-50E).

Safety Standards

[CSA] (for 100-120 V AC and 24 V DC power supply)

[CE Marking] (for 100-120 V AC, 220-240 V AC and 24 V DC power supply)

EMC Conformity Standards

[CE Marking] (for 100-120 V AC, 220-240 V AC and 24 V DC power supply)

[C-Tick Marking] (for 220-240 V AC and 24 V DC power supply)

[KC Marking] (for 100-120 V AC, 220-240 V AC and 24 V DC power supply)

Standards for Hazardous Location Equipment

[CSA Non-Incendive] (for 100-120 V AC and 24 V DC power supply)

[FM Non-Incendive] (for 100-120 V AC, 220-240 V AC and 24 V DC power supply)

[Type n] (for 24 V DC power supply)

 CONFIGURATION

 Module configuration

Power Supply Module (PW481 or PW482 or PW484): Two modules in case of a dual-redundant configuration.

 Power supply to the I/O Modules, and supply power to the transmitters.

 The power supply terminals use M4 screws.

ESB Bus Interface Slave Module (SB401): Two modules in case of a dual-redundant configuration.

I/O Modules (*1): Max. 8

*1: Non-standard components.

 LIMITATIONS OF INSTALLATION AND NOTICES FOR INSTALLATION

For installing I/O modules in node unit, the quantity and allocation are limited. Also, when installing a node unit to

the dedicated cabinet, there are limitations of installation under the ambient operating temperature conditions. When

modules with built-in barriers are installed in any node unit, an insulating partition (Part No. T9083NA) must be

installed.

For details, please refer to “FIO System Overview (for Vnet/IP)” (GS 33K50F10-50E) and “Installation Guidance” (TI

33K01J10-50E).

Description

Model ANB10D Node Unit for Dual-Redundant ESB

Bus

Suffix

Codes

-4 Dual-redundant power supply

 1 100 - 120 V AC power supply

 2 220 - 240 V AC power supply

 4 24 V DC power supply

 5 Basic type with no explosion

protection

 6

With ISA Standard G3 option,

temperature (-20 ˚C to 70 ˚C) option,

and no explosion protection (*1)

 7 With ISA Standard G3 option and no

explosion protection

 E Basic type with explosion protection

 F

With ISA Standard G3 option,

temperature (-20 ˚C to 70 ˚C) option,

and explosion protection (*1)

 G With ISA Standard G3 option and

explosion protection

Option

Codes

/CU2N Connector Unit for ESB Bus

[part No.: S9562FA (2 pieces)]

/CU2T

Connector Unit with Terminator for

ESB Bus

[part No.: S9564FA (2 pieces)]

/ATDOC Explosion Protection Manual (*2)

/NDEL Software License for Node Expansion

(*3)
