PRODUCT DESCRIPTION

MTL4544 MTL4544S Safety Barriers MTL4544 MTL4544S Repeater Power Supply


MTL4544 MTL4544S Safety Barriers MTL4544 MTL4544S Repeater Power Supply



Description of MTL4544 MTL4544S Safety Barriers MTL4544 MTL4544S Repeater Power Supply


MTL4544/S provides fully-floating dc supplies for energising two conventional 2-wire or 3-wire 4/20mA or HART transmitters located in a hazardous area, and repeats the current in other circuits to drive two safe-area loads. For smart transmitters, the unit allows bi-directional transmission of digital communication signals superimposed on the 4/20mA loop current. Alternatively, the MTL4544S acts as a current sink for a safe-area connection rather than driving a current into the load. Separately powered current sources, such as 4-wire transmitters, can be connected but will not support HART communication.


Specification of MTL4544 MTL4544S Safety Barriers MTL4544 MTL4544S Repeater Power Supply


See also common specification

Number of channels  Two

Location of transmitter  Zone 0, IIC, T4–6 hazardous area if suitably certified

Div. 1, Group A hazardous location

Safe-area output

Signal range: 4 to 20mA

Under/over-range: 0 to 24mA

Safe-area load resistance (MTL5544)

@ 24mA: 0 to 360Ω

@ 20mA: 0 to 450Ω

Safe-area load (MTLx544S)

Current sink: 600Ω max.

Maximum voltage source: 24V dc

Safe-area circuit output resistance: > 1MΩ

Safe-area circuit ripple

< 50µA peak-to-peak

Hazardous-area input

Signal range:  0 to 24mA (including over-range)

Transmitter voltage:  16.5V at 20mA

Transfer accuracy at 20°c

Better than 15µA

Temperature drift

< 0.8µA/°C

Response time

Settles to within 10% of final value within 50µs

Communications supported

HART (terminals 1 & 2 and 4 & 5 only)
