Coron QF30U-D series Ultrasonic Sensor In Stock

Features：

√ Sensing not affected by object color, transparency, gloss and ambient light.

√ Small blind zone, larger detection range to 2 meters

√ Temperature compensation function, not affected by ambient temperature.

√ Strong anti-interference ability, enhanced resistance to electromagnetic

interference and radio frequency interference.

√ Equipped with NPN, PNP switching output, and 4-20mA, 0-10VDC analog

output.

√ Sensing distance and sensing range freely adjustable by remote setting line or

setting button in operating window.

√ Equipped with LED indicators, visually displaying power status, signal

strength and output status.

√ IP67, completely unaffected by dust, dirt and fog.

Model and Technical Parameters：

Sensing method：Ultrasonic Reflective Type

Model：

NPN 4-20mA：QF30U-D100NI-XY QF30U-D100NI-G-XY QF30U-D200NI-XY QF30U-D200NI-G-XY

NPN 0-10VDC ：QF30U-D100NU-XY QF30U-D100NU-G-XY QF30U-D200NU-XY QF30U-D200NU-G-XY

PNP 4-20mA ：QF30U-D100PI-XY QF30U-D100PI-G-XY QF30U-D200PI-XY QF30U-D200PI-G-XY

PNP 0-10VDC：QF30U-D100PU-XY QF30U-D100PU-G-XY QF30U-D200PU-XY QF30U-D200PU-G-XY

Sensing distance ：200mm-1000mm or 250mm-2000mm

Blind zone：200mm or 250mm

Standard det. object：100×100mm

Supply voltage：DC24V±10%, pulsation(P-P)≤10%

Consumption：≤90mA

Output：

Switch output NPN, PNP open collector output: load current 100mA, residual voltage <2V

Analog output 4-20mA, 0-10VDC output

Response time：Switching output: 48ms min; analog output: 48ms min, updated every 16ms

Indicators：Power indicator (yellow), safety indicator (yellow), ultrasonic intensity indicator (red)

Output status：Switch output’s normmaly open / normally closed changable

Precision：Analog resolution or switching repeatability: ±0.25% of detection distance

Adjustment：Sensing range and output method can be set by window key and remote setting line

Ambient temperature：Operation: -20...+60℃(with no freezing); storage: -25...+75℃(with no freezing)

Ambient humidity：Operation: 35...85%RH; storage: 35...85%RH

Vibrance resistance：Vibration frequency: 10-55Hz, amplitude: 1.5mm, 2 hours each in the X, Y, and Z directions

Shock resistance：Acceleration: 500m/s2 about 50g, 3 times each in X, Y, Z directions

Interference resistance：±240V square pulse wave(width: 1us) generated by jammer

Voltage resistance：AC1000V, 50/60Hz for 1 minute

Insulation resistance：DC500V, 20MΩ or above

Dielectric strengths：AC1000V, 50/60Hz for 1 minute (0-40℃, 85&RH)

Connection method：5-pole cable, 2m M12 5-pole connector 5-pole cable, 2m M12 5-pole connector

Material：ABS

Protection level：IEC IP67
