Coron QF25L-D series Ultrasonic Sensor In Stock

Features:

√  Sensing not affected by object color, transparency, gloss and ambient light.

√  Plastic housing, lightweight and corrosion resistant.

√  Small blind zone, larger detection range.

√  Temperature compensation function, not affected by ambient temperature.

√  Strong anti-interference ability, enhanced resistance to electromagnetic interference and radio frequency interference.

√  Equipped with NPN, PNP switching output, RS485 communication output and 4-20mA, 0-10VDC analog output.

√  Sensing distance and sensing range freely adjustable by remote setting line.

√  Equipped with LED indicators, visually displaying power status, signal strength and output status.

√  IP67, completely unaffected by dust, dirt and fog.

Model and Technical Parameters:

Sensing Method: Ultrasonic Reflective Type

Sensing distance: 50mm-500mm with 50mm blind zone or 100mm-1000mm with 100mm blind zone

Standard det. object： 100×100mm

Supply voltage：DC24V±10%, pulsation(P-P)≤10% , consumption≤50mA

Output：

Switch NPN, PNP open collector output: load current 100mA, residual voltage <2V

Analog 4-20mA, 0-10VDC output

Communication RS485 output (Modbus)

Response time：≥50ms or ≥125ms

Indicators: Action indicator (green LED), Action indicator (red LED)

Output status: Switch output’s normmaly open / normally closed changable

Repeatability: Switching repeatability: ±0.5% of full scale, analog repeatability: ±0.1% of full scale

Resolution: Analog resolution: 0.13mm Analog resolution: 0.35mm

Adjustment: Sensing range and output method can be set by window key and remote setting line

Ambient temperature: Operation: -20...+60℃(with no freezing); storage: -25...+75℃(with no freezing)

Ambient humidity: Operation: 35...85%RH; storage: 35...85%RH

Light resistance: Incandescent lamp： 3000Lux； sunlight: 10000Lx

Vibrance resistance: Vibration frequency: 10-55Hz, amplitude: 1.5mm, 2 hours each in the X, Y, and Z directions

Shock resistance: Acceleration: 500m/s2 about 50g, 3 times each in X, Y, Z directions

Voltage resistance: AC1000V, 50/60Hz for 1 minute

Insulation resistance: DC500V, 20MΩ or above

Dielectric strengths: AC1000V, 50/60Hz for 1 minute (0-40℃, 85&RH)

Connection method: 2m cable

Protection level: IEC IP67
