Cisco Catalyst Switch C9200L-24T-4G-E Cisco Catalyst 24-Port C9200L-24T-4G-E Gigabit Switch

Product News

Cisco Catalyst Switch C9200L-24T-4G-E Cisco Catalyst 24-Port C9200L-24T-4G-E Gigabit Switch

November 14, 2025

Cisco Catalyst Switch C9200L-24T-4G-E Cisco Catalyst 24-Port C9200L-24T-4G-E Gigabit Switch

Core Categorization Overview

The C9200 series is divided primarily by three factors:

1. Series: Standard (Essentials) vs. Network Advantage (Advantage)

2. Port Type: All Ethernet vs. Multi-Gigabit

3. Power: Non-PoE, PoE+, Enhanced PoE, and Ultra PoE

1. Fixed Configuration Switches (Main Product Line)

This is the core of the C9200 series, segmented by port type and count.

1.1 24-Port Models (1Gbps Data Ports)

Model Name	Port Configuration	Key Feature / Power	Series
C9200-24T	24 x 1G RJ45, 4 x 1G SFP	Data Only (Non-PoE)	Essentials
C9200-24P	24 x 1G RJ45, 4 x 1G SFP	PoE+	Essentials
C9200L-24T-4G	24 x 1G RJ45, 4 x 1G SFP	Energy Efficient Data Only	Essentials
C9200L-24P-4G	24 x 1G RJ45, 4 x 1G SFP	Energy Efficient PoE+	Essentials
C9200-24PB	24 x 1G RJ45, 4 x 1G SFP	Enhanced PoE+ (740W)	Network Advantage
C9200-24PX	24 x 1G RJ45, 4 x 1G SFP	Ultra PoE/UPOE (UPoE & UPoE+)	Network Advantage
C9200-24PXG	24 x 1G RJ45, 2 x 10G SFP+	Ultra PoE with 10G Uplinks	Network Advantage

1.2 48-Port Models (1Gbps Data Ports)

Model Name	Port Configuration	Key Feature / Power	Series
C9200-48T	48 x 1G RJ45, 4 x 1G SFP	Data Only (Non-PoE)	Essentials
C9200-48P	48 x 1G RJ45, 4 x 1G SFP	PoE+	Essentials
C9200L-48T-4G	48 x 1G RJ45, 4 x 1G SFP	Energy Efficient Data Only	Essentials
C9200L-48P-4G	48 x 1G RJ45, 4 x 1G SFP	Energy Efficient PoE+	Essentials
C9200-48PB	48 x 1G RJ45, 4 x 1G SFP	Enhanced PoE+ (740W)	Network Advantage
C9200-48PX	48 x 1G RJ45, 4 x 1G SFP	Ultra PoE/UPOE (UPoE & UPoE+)	Network Advantage
C9200-48PXG	48 x 1G RJ45, 2 x 10G SFP+	Ultra PoE with 10G Uplinks	Network Advantage

1.3 Multi-Gigabit Models (Data Ports: 100M/1G/2.5G/5G/10G)

These models support higher speeds like 2.5GbE and 5GbE for devices like Wi-Fi 6/6E APs and advanced IoT.

Model Name	Port Configuration	Key Feature / Power	Series
C9200-24S	12 x Multi-Gigabit RJ45, 12 x 1G RJ45, 4 x 1G SFP	Data Only (Non-PoE)	Essentials
C9200-24SX	12 x Multi-Gigabit RJ45, 12 x 1G RJ45, 4 x 1G SFP	Ultra PoE/UPOE	Network Advantage
C9200-24SXE	12 x Multi-Gigabit RJ45, 12 x 1G RJ45, 2 x 10G SFP+	Ultra PoE with 10G Uplinks	Network Advantage
C9200-48S	24 x Multi-Gigabit RJ45, 24 x 1G RJ45, 4 x 1G SFP	Data Only (Non-PoE)	Essentials
C9200-48SX	24 x Multi-Gigabit RJ45, 24 x 1G RJ45, 4 x 1G SFP	Ultra PoE/UPOE	Network Advantage
C9200-48SXE	24 x Multi-Gigabit RJ45, 24 x 1G RJ45, 2 x 10G SFP+	Ultra PoE with 10G Uplinks	Network Advantage

2. Stacking Models

These are dedicated switches used to form a stack with the fixed configuration switches above, providing additional port density.

Model Name	Port Configuration	Key Feature / Power	Series
C9200-24S-ST	12 x Multi-Gigabit RJ45, 12 x 1G RJ45, 4 x 1G SFP	Data Only Stacking Unit	Essentials
C9200-24SX-ST	12 x Multi-Gigabit RJ45, 12 x 1G RJ45, 4 x 1G SFP	Ultra PoE Stacking Unit	Network Advantage
C9200-48S-ST	24 x Multi-Gigabit RJ45, 24 x 1G RJ45, 4 x 1G SFP	Data Only Stacking Unit	Essentials
C9200-48SX-ST	24 x Multi-Gigabit RJ45, 24 x 1G RJ45, 4 x 1G SFP	Ultra PoE Stacking Unit	Network Advantage

Key to Model Naming & Suffixes

-T: Data Only (No PoE)

-P: Standard PoE+

-PB: Enhanced PoE+ (Higher Power Budget)

-PX / -SX: Ultra PoE (Supports UPoE/UPoE+ up to 60W/90W per port)

-L: "Lite" / Energy Efficient model (Lower power supply, fixed configuration, cannot be stacked upon)

-G (in -PXG, -SXE): Indicates native 10 Gigabit SFP+ uplink ports

-S: Multi-Gigabit (mGig) capable data ports

-ST: Dedicated Stacking Unit (must be connected to a master switch in a stack)

Catalyst 9200 Series models and configurations

ModelsFRU Power SupplyFRU FansModular UplinksStacking Bandwidth SupportSD-Access Support1

"Modular uplink models

(C9200 Enhanced VN SKUs)"YesYesYes160 GbpsYes (32 Virtual Networks)2

"Modular uplink models

(C9200 SKUs)"YesYesYes160 GbpsYes (4 Virtual Networks)

"Fixed uplink Models

(C9200L SKUs)"YesNoNo80 GbpsLimited (1 Virtual Network)

"Compact Models

(C9200CX SKUs)"Fixed internal power supplyFanlessNoNoYes (16 Virtual Networks)

Cisco Catalyst 9200 Series Switch configurations

Switch modelDownlinks total 10/100/1000 or PoE+ copper portsUplink configurationDefault primary power supplyFans

Modular uplink models

C9200-24T24 ports dataModular uplink optionsPWR-C6-125WACFRU redundant

C9200-24P24 ports full PoE+Modular uplink optionsPWR-C6-600WACFRU redundant

C9200-24PB24 ports full PoE+Modular uplink optionsPWR-C6-600WACFRU redundant

C9200-24PXG24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)Modular uplink optionsPWR-C6-600WACFRU redundant

C9200-48T48 ports dataModular uplink optionsPWR-C6-125WACFRU redundant

C9200-48P48 ports full PoE+Modular uplink optionsPWR-C6-1KWACFRU redundant

C9200-48PL48 Ports partial PoE+Modular uplink optionsPWR-C6-600WACFRU redundant

C9200-48PB48 ports full PoE+Modular uplink optionsPWR-C6-1KWACFRU redundant

C9200-48PXG48 ports full PoE+ (8 mGig ports up to 10G, 40 ports up to 1G)Modular uplink optionsPWR-C6-1KWACFRU redundant

Fixed uplink models

C9200L-24T-4G24 ports data4x 1G fixed uplinksPWR-C5-125WACFixed redundant

C9200L-24P-4G24 ports full PoE+4x 1G fixed uplinksPWR-C5-600WACFixed redundant

C9200L-48T-4G48 ports data4x 1G fixed uplinksPWR-C5-125WACFixed redundant

C9200L-48P-4G48 ports full POE+4x 1G fixed uplinksPWR-C5-1KWACFixed redundant

C9200L-48PL-4G48 Ports partial PoE+4X 1G Fixed uplinksPWR-C5-600WACFixed redundant

C9200L-24T-4X24 ports data4x 1/10G fixed uplinksPWR-C5-125WACFixed redundant

C9200L-24P-4X24 ports full PoE+4x 1/10G fixed uplinksPWR-C5-600WACFixed redundant

C9200L-48T-4X48 ports data4x 1/10G fixed uplinksPWR-C5-125WACFixed redundant

C9200L-48P-4X48 ports full PoE+ ENERGY STAR庐certified4x 1/10G fixed uplinksPWR-C5-1KWACFixed redundant

C9200L-48PL-4X48 Port partial PoE+4X 1/10G Fixed uplinksPWR-C5-600WACFixed redundant

C9200L-24PXG-4X24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)4x 1/10G fixed uplinksPWR-C5-600WACFixed redundant

C9200L-48PXG-4X48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G)4x 1/10G fixed uplinksPWR-C5-1KWACFixed redundant

C9200L-24PXG-2Y24 ports full PoE+ (8 mGig ports up to 10G, 16 ports up to 1G)2x 1/10/25G fixed uplinksPWR-C5-600WACFixed redundant

C9200L-48PXG-2Y48 ports full POE+ (8 mGig ports up to 10G, 40 ports up to 1G)2x 1/10/25G fixed uplinksPWR-C5-1KWACFixed redundant

All Catalyst 9200L models are available for out-of-box cloud management with the Meraki dashboard. Learn more about theCisco Catalyst 9200L-M.

Compact models

C9200CX-12T-2X2G12 ports data2x 1G copper, 1x 1G CU PD 802.3bt Class 6, 2x 10G SFP+ fixed uplinksPowered by 802.3bt class 6 PoEFanless

Optional auxiliary 80W AC or DC power adaptor

C9200CX-12P-2X2G12 ports PoE+2x 1G copper, 2x 10G SFP+ fixed uplinks315W AC internalFanless

C9200CX-8P-2X2G8 ports full PoE+2x 1G copper, 2x 10G SFP+ fixed uplinks315W AC internalFanless

C9200CX-8UXG-2X8 ports UPOE (4 mGig ports up to 10G, 4 ports up to 1G)2x 10G SFP+ fixed uplinks315W AC internalFanless

C9200CX-12P-2XGH12 ports PoE+2x 1G copper, 2x 10G SFP+ fixed uplinks315W HVDC/AC internalFanless

C9200CX-8P-2XGH8 ports full PoE+2x 1G copper, 2x 10G SFP+ fixed uplinks315W HVDC/AC internalFanless

C9200CX-8UXG-2XH8 ports UPOE (4 mGig ports up to 10G, 4 ports up to 1G)2x 10G SFP+ fixed uplinks315W HVDC/AC internalFanless

C9200CX-8PT-2G8 ports full PoE+2x 1G copper & UPOE+ uplinksPowered by UPOE+ ULs AND External 80W/150W PS (LVDC support)Fanless

Network module part numbers and descriptions

etwork moduleDescription

C9200-NM-2Y12 x 25G network module

C9200-NM-2Q12 x 40G network module

C9200-NM-4G24x 1G network module

C9200-NM-4X4x 1G/10G network module

C9200-NM-BLANKNo network module

PoE+ Power with primary and secondary power supplies

ModelPrimary power supplyAvailable PoE power with single primary power supply only1Optional secondary power supplyAvailable PoE power with additional secondary power supply1

C9200-24PPWR-C6-600WAC370WPWR-C6-600WAC740W

PWR-C6-715WDC=2485WPWR-C6-715WDC=740W

C9200-24PBPWR-C6-600WAC370WPWR-C6-600WAC740W

PWR-C6-715WDC=485WPWR-C6-715WDC=740W

C9200-24PXGPWR-C6-600WAC370WPWR-C6-600WAC740W

PWR-C6-715WDC=485WPWR-C6-715WDC=740W

C9200-48PPWR-C6-1KWAC740WPWR-C6-1KWAC1440W

PWR-C6-715WDC=485WPWR-C6-715WDC=970W

C9200-48PLPWR-C6-600WAC370WPWR-C6-600WAC740W

PWR-C6-715WDC=485WPWR-C6-715WDC=970W

C9200-48PBPWR-C6-1KWAC740WPWR-C6-1KWAC1440W

PWR-C6-715WDC=485WPWR-C6-715WDC=970W

C9200-48PXGPWR-C6-1KWAC740WPWR-C6-1KWAC1440W

PWR-C6-715WDC=485WPWR-C6-715WDC=970W

C9200L-24P-4GPWR-C5-600WAC370WPWR-C5-600WAC740W

PWR-C5-715WDC=2485WPWR-C5-715WDC=740W

C9200L-24P-4XPWR-C5-600WAC370WPWR-C5-600WAC740W

PWR-C5-715WDC=485WPWR-C5-715WDC=740W

C9200L-48P-4GPWR-C5-1KWAC740WPWR-C5-1KWAC1440W

PWR-C5-715WDC=485WPWR-C5-715WDC=970W

C9200L-48PL-4GPWR-C5-600WAC370WPWR-C5-600WAC740W

PWR-C5-715WDC=485WPWR-C5-715WDC=970W

C9200L-48P-4X3PWR-C5-1KWAC740WPWR-C5-1KWAC1440W

PWR-C5-715WDC=485WPWR-C5-715WDC=970W

C9200L-48PL-4XPWR-C5-600WAC370WPWR-C5-600WAC740W

PWR-C5-715WDC=485WPWR-C5-715WDC=970W

C9200L-24PXG-4XPWR-C5-600WAC370WPWR-C5-600WAC740W

PWR-C5-715WDC=485WPWR-C5-715WDC=740W

C9200L-48PXG-4XPWR-C5-1KWAC740WPWR-C5-1KWAC1440W

PWR-C5-715WDC=485WPWR-C5-715WDC=970W

C9200L-24PXG-2YPWR-C5-600WAC370WPWR-C5-600WAC740W

PWR-C5-715WDC=485WPWR-C5-715WDC=740W

C9200L-48PXG-2YPWR-C5-1KWAC740WPWR-C5-1KWAC1440W

PWR-C5-715WDC=485WPWR-C5-715WDC=970W

C9200CX-12P-2X2G315W AC Internal240WN/AN/A

C9200CX-8P-2X2G315W AC internal240WN/AN/A

C9200CX-8UXG-2X315W AC internal240WN/AN/A

C9200CX-12P-2XGH315W HVDC/AC internal240WN/AN/A

C9200CX-8P-2XGH315W HVDC/AC internal240WN/AN/A

C9200CX-8UXG-2XH315W HVDC/AC internal240WN/AN/A

C9200CX-8PT-2GExternal power adapter (80W) [LVDC support] and 802.3bt UPOE+ ULs180WExternal power adapter (150W) [LVDC support] and 802.3bt UPOE+ ULs240W

Bandwidth specifications

DescriptionSwitching capacitySwitch capacity with StackingForwarding rateForwarding rate with Stacking

C9200-24T128 Gbps288 Gbps95.23 Mpps214 Mpps

C9200-24P128 Gbps288 Gbps95.23 Mpps214 Mpps

C9200-24PB128 Gbps288 Gbps95.23 Mpps214 Mpps

C9200-24PXG352 Gbps532 Gbps261.90 Mpps395 Mpps

C9200-48T176 Gbps336 Gbps130.95 Mpps250 Mpps

C9200-48P176 Gbps336 Gbps130.95 Mpps250 Mpps

C9200-48PL176 Gbps336 Gbps130.95 Mpps250 Mpps

C9200-48PB176 Gbps336 Gbps130.95 Mpps250 Mpps

C9200-48PXG400 Gbps580 Gbps297.61 Mpps431 Mpps

C9200L-24T-4G56 Gbps136 Gbps41.67 Mpps101 Mpps

C9200L-24P-4G56 Gbps136 Gbps41.67 Mpps101 Mpps

C9200L-48T-4G104 Gbps184 Gbps77.38 Mpps137 Mpps

C9200L-48P-4G104 Gbps184 Gbps77.38 Mpps137 Mpps

C9200L-48PL-4G104 Gbps184 Gbps77.38 Mpps137 Mpps

C9200L-24T-4X128 Gbps208 Gbps95.23 Mpps155 Mpps

C9200L-24P-4X128 Gbps208 Gbps95.23 Mpps155 Mpps

C9200L-48T-4X176 Gbps256 Gbps130.95 Mpps190 Mpps

C9200L-48P-4X176 Gbps256 Gbps130.95 Mpps190 Mpps

C9200L-48PL-4X176 Gbps256 Gbps130.95 Mpps190 Mpps

C9200L-24PXG-4X272 Gbps352 Gbps214.28 Mpps262 Mpps

C9200L-24PXG-2Y292 Gbps372 Gbps229.16 Mpps277 Mpps

C9200L-48PXG-4X392 Gbps472 Gbps291.66 Mpps351 Mpps

C9200L-48PXG-2Y340 Gbps420 Gbps252.97 Mpps313 Mpps

C9200CX-12T-2X2G70 GbpsN/A52.08 MppsN/A

C9200CX-12P-2X2G68 GbpsN/A50.59 MppsN/A

C9200CX-8P-2X2G60 GbpsN/A44.64 MppsN/A

C9200CX-8UXG-2X128 GbpsN/A95.23 MbpsN/A

C9200CX-12P-2XGH68 GbpsN/A50.59 MppsN/A

C9200CX-8P-2XGH60 GbpsN/A44.64 MppsN/A

C9200CX-8UXG-2XH128 GbpsN/A95.23 MbpsN/A

C9200CX-8PT-2G20 GbpsN/A14.88 MbpsN/A

Model Dimensions

latform Physical Specifications

Chassis DimensionsChassis + FEP + Fan Dimensions (HxWxD)

ModelInchesCentimetersInchesCentimeters

C9200-24T1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-24P1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-24PB1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-24PXG1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-48T1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-48P1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-48PL1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-48PB1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200-48PXG1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200L-24T-4G1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-24P-4G1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-48T-4G1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-48P-4G1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-48PL-4G1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-24T-4X1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-24P-4X1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-48T-4X1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-48P-4X1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-48PL-4X1.73 x 17.5 x 11.34.4 x 44.5 x 28.81.73 x 17.5 x 12.94.4 x 44.5 x 32.9

C9200L-24PXG-4X1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200L-24PXG-2Y1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200L-48PXG-4X1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200L-48PXG-2Y1.73 x 17.5 x 13.84.4 x 44.5 x 35.01.73 x 17.5 x 15.44.4 x 44.5 x 39.1

C9200CX-12T-2X2G1.73 x 10.6 x 6.54.4 x 26.9 x 16.51.73 x 10.6 x 6.54.4 x 26.9 x 16.5

C9200CX-12P-2X2G1.73 x 10.6 x 9.64.4 x 26.9 x 24.41.73 x 10.6 x 9.64.4 x 26.9 x 24.4

C9200CX-8P-2X2G1.73 x 10.6 x 9.64.4 x 26.9 x 24.41.73 x 10.6 x 9.64.4 x 26.9 x 24.4

C9200CX-8UXG-2X1.73 x 10.6 x 9.64.4 x 26.9 x 24.41.73 x 10.6 x 9.64.4 x 26.9 x 24.4

C9200CX-12P-2XGH1.73 x 10.6 x 9.64.4 x 26.9 x 24.41.73 x 10.6 x 9.64.4 x 26.9 x 24.4

C9200CX-8P-2XGH1.73 x 10.6 x 9.64.4 x 26.9 x 24.41.73 x 10.6 x 9.64.4 x 26.9 x 24.4

C9200CX-8UXG-2XH1.73 x 10.6 x 9.64.4 x 26.9 x 24.41.73 x 10.6 x 9.64.4 x 26.9 x 24.4

C9200CX-8PT-2G1.73 x 10.6 x 6.54.4 x 26.9 x 16.51.73 x 10.6 x 6.54.4 x 26.9 x 16.5

Model Weights

ModelPoundsKilograms

C9200-24T11.025

C9200-24P12.125.5

C9200-24PB12.125

C9200-24PXG11.335.1

C9200-48T11.025

C9200-48P12.125.5

C9200-48PL12.125.5

C9200-48PB12.125.5

C9200-48PXG11.985.45

C9200L-24T-4G9.594.35

C9200L-24P-4G10.384.71

C9200L-48T-4G9.974.53

C9200L-48P-4G10.584.8

C9200L-48PL-4G10.584.8

C9200L-24T-4X9.594.35

C9200L-24P-4X10.384.71

C9200L-48T-4X9.974.53

C9200L-48P-4X10.584.8

C9200L-48PL-4X10.584.8

C9200L-24PXG-4X125.44

C9200L-24PXG-2Y125.44

C9200L-48PXG-4X12.65.71

C9200L-48PXG-2Y12.65.71

C9200CX-12T-2X2G41.81

C9200CX-12P-2X2G6.62.99

C9200CX-8P-2X2G6.62.99

C9200CX-8UXG-2X73.18

C9200CX-12P-2XGH6.62.99

C9200CX-8P-2XGH6.62.99

C9200CX-8UXG-2XH73.18

C9200CX-8PT-2G4.31.95

Model Mean time between failures metrics

Mean time between failures (hours)

C9200-24T587800

C9200-24P422310

C9200-24PB434220

C9200-24PXG353960

C9200-48T571440

C9200-48P375570

C9200-48PL375570

C9200-48PB384980

C9200-48PXG320440

C9200L-24T-4G531030

C9200L-24P-4G392210

C9200L-48T-4G508700

C9200L-48P-4G347760

C9200L-48PL-4G347760

C9200L-24T-4X525990

C9200L-24P-4X390310

C9200L-48T-4X503400

C9200L-48P-4X346270

C9200L-48PL-4X346270

C9200L-24PXG-4X379410

C9200L-24PXG-2Y374730

C9200L-48PXG-4X337360

C9200L-48PXG-2Y337260

C9200CX-12T-2X2G960180

C9200CX-12P-2X2G704430

C9200CX-8P-2X2G736000

C9200CX-8UXG-2X711500

C9200CX-12P-2XGH702630

C9200CX-8P-2XGH734030

C9200CX-8UXG-2XH709660

C9200CX-8PT-2G746530

PWR-C5-125WAC3332120

PWR-C5-600WAC1600060

PWR-C5-1KWAC1600060

PWR-C6-125WAC3332120

PWR-C6-600WAC1600060

PWR-C6-1KWAC1600060

Connectors

shows the supported connectors for Cisco Catalyst 9200 Series switches.

Measured P(W)

Half port trafficFull port trafficWeighted average PwNo linkPoE test (no traffic)

SKUFEPUplinkInput0.01%/ EEE0.10.30.510.01%/ EEE0.10.30.510.250.50.91

C9200- 24T125W (C5/C6)C9200-NM- 4X1G115VAC33.0936.0836.1536.236.3435.5141.7841.894242.2741.230.65TBDTBDTBDTBD

230VAC33.1535.953636.0636.1935.3641.541.6241.7442.0140.9430.53TBDTBDTBDTBD

C9200- 24T125WC9200-NM115VAC33.6236.9937.2937.5838.2635.414242.5543.1144.4941.58832.2TBDTBDTBDTBD

230VAC33.736.8537.1337.4138.135.441.7542.342.8544.2241.36431.9TBDTBDTBDTBD

C9200- 24P600W (C5/C6)C9200-NM- 4X1G115VAC43.5747.3747.4247.4747.6846.8253.7953.9154.0254.353.1440.75150.71251.67416.85457.98

230VAC43.3846.9246.9547.0347.1846.3553.2353.3453.4553.7652.5940.43148.14247.03406.62446.27

C9200-24P600W(C5/C6)C9200-NM-4X10G115VAC44.6248.4948.7949.1149.8847.0254.1854.7755.3456.7753.7242.55144.6245.42410.22451.45

230VAC44.3248.0648.3748.6649.446.4153.3853.9954.5155.9652.9442.26142.29241.14400.76440.37

C9200- 24PXG600W (C6)C9200-NM- 4X10G115VAC84.390.99192.394.295110.6111.6112.6115.2109.572.8296.8506.3858.3941.5

230VAC84.190.591.191.692.994.3108.8109.9111113.6107.8372.24287.8492.4826.7909.1

C9200-24PXG600W(C6)C9200-NM-2X25G115VAC83.4187.5988.5689.1990.8593.96101.38103.32104.89107.22101.2272.52187.94290.47452.61494.88

230VAC81.986.9787.6888.3890.0392.2199.79101.14102.45105.6599.6271.74185.45283.86441.83480.86

C9200-24PXG600W(C6)C9200-NM-2X40G115VAC82.3486.7887.9188.991.6492.97100.93103104.89108.81100.9271.72188.86289.2448.52496.28

230VAC80.0584.5385.6486.6989.2990.2699.2101.41103.56108.799.2671.72185.29282.86441.33480.95

C9200- 48T125W (C5/C6)C9200-NM- 4X1G115VAC36.5745.0945.4545.6345.736.9853.9555.3653.9155.8752.44536.98TBDTBDTBDTBD

230VAC36.9945.5845.6545.7145.8636.4854.5154.6454.755.0452.7636.48TBDTBDTBDTBD

C9200- 48T125W (C5/C6)C9200-NM- 4X10G115VAC38.8447.0748.6748.7150.4139.256.3358.3658.7561.855.16438.38TBDTBDTBDTBD

230VAC39.147.1147.9148.3749.6539.4656.3257.2558.1960.7255.07438.67TBDTBDTBDTBD

C9200- 48P1000W (C5/C6)C9200-NM- 4X1G115VAC56.0760.2560.3160.3660.5556.4569.3369.4669.5669.8768.150.42262.61467.5812.39899.99

230VAC55.6659.9860.0560.0560.2756.0969.0769.269.369.5867.8350.04258.08457.61785.35867.75

C9200- 48P1000W (C5/C6)C9200-NM- 4X10G115VAC54.2761.7162.262.6863.8856.11470.9370.9571.9274.3969.7952.26262.38467.41812.23899.4

230VAC53.8961.0961.662.0763.2455.7969.5270.4771.4373.8968.5851.34257.97457.3785.03867.35

C9200- 48PL600W (C6)C9200-NM- 4X1G115VAC43.5747.3747.4247.4747.6846.8253.7953.9154.0254.353.1440.75150.71251.67416.85457.98

230VAC43.3846.9246.9547.0347.1846.3553.2353.3453.4553.7652.5940.43148.14247.03406.62446.27

C9200-48PL600W(C6)C9200-NM-4X10G115VAC44.6248.4948.7949.1149.8847.0254.1854.7755.3456.7753.7242.55144.6245.42410.22451.45

230VAC44.3248.0648.3748.6649.446.4153.3853.9954.5155.9652.9442.26142.29241.14400.76440.37

C9200- 48PXG1000W (C6)C9200-NM- 4X10G115VAC84.2690.8691.0292.2694.1895.01110.55111.62112.62115.2109.4672.3296.81506.33858.27941.49

230VAC84.1490.5291.0591.5792.8594.25108.84109.94111113.6107.8673.2287.79492.42826.74909.07

C9200- 48PXG1000W (C6)C9200-NM- 2X25G115VAC87.8495.2395.9896.6998.3499.25113.66115.37116.7120.91112.9477.57300.71513.82872.63957.36

230VAC87.1294.1494.7995.4296.9997.59111.99113.52114.86117.82111.1376.53290.61492.91826.5910.08

C9200- 48PXG1000W (C6)C9200-NM- 2X40G115VAC88.0194.3595.596.4899.3698.72113.2115.13117.08121.84112.6176.84296.86503.87861.87957.4

230VAC87.0293.0994.1595.1697.7997.28111.43113.57115.66120.67110.9475.84291.54491.67824.85909.78

C9200L-24T- 4G125W (C5)Fixed115VAC30.0332.1532.1732.232.3332.0335.935.9836.0636.2335.54627.39no PoEno PoEno PoEno PoE

230VAC29.8132.2632.2332.2232.3531.8635.8635.9436.0336.2835.50227.5no PoEno PoEno PoEno PoE

C9200L-24P- 4G600W (C5)Fixed115VAC39.2843.9844.0444.0844.2238.9548.4748.648.744947.57139.59153.06256.56423.44466.34

230VAC38.8843.643.6643.6943.8338.5748.0948.2248.3548.6247.19139.2150.51252.1413.89455.15

C9200L-24T- 4X125W (C5)Fixed115VAC30.9931.9832.2132.4333.0433.2936.6237.0237.4738.636.48527.82no PoEno PoEno PoEno PoE

230VAC30.9832.0232.2432.4633.0233.2436.5936.9637.4138.5236.44827.9no PoEno PoEno PoEno PoE

C9200L-24P- 4X600W (C5)Fixed115VAC42.8344.1544.6244.7245.3945.4551.0851.5252.253.4950.75840.17144.82241.99401.32445.35

230VAC42.3644.1944.4744.6145.2844.649.3349.9150.3651.5149.07539.48142.32237.52392.77434.06

C9200L-48T- 4G125W (C5)Fixed115VAC33.8540.1140.240.2440.3432.7446.6546.8846.9647.3345.32733.85no PoEno PoEno PoEno PoE

230VAC33.6240.540.5740.6340.7433.0646.846.9147.0547.4945.49534.16no PoEno PoEno PoEno PoE

C9200L-48P- 4G1000W (C5)Fixed115VAC45.0752.1552.2252.2852.4444.658.5958.758.8159.157.24245.82270.96484.59842.07933.03

230VAC44.5551.551.5551.651.7744.0857.8257.9158.0458.2956.49345.17266.35474.24814.85899.58

C9200L-48PL- 4G600W (C5)Fixed115VAC39.2843.9844.0444.0844.2238.9548.4748.648.744947.57139.59153.06256.56423.44466.34

230VAC38.8843.643.6643.6943.8338.5748.0948.2248.3548.6247.19139.2150.51252.1413.89455.15

C9200L-48T- 4X125W (C5)Fixed115VAC35.5242.3642.943.3543.6935.0649.2750.2451.1953.648.28236.08no PoEno PoEno PoEno PoE

230VAC35.8442.643.0943.5844.8135.2749.4150.3651.3353.6748.42236.38no PoEno PoEno PoEno PoE

C9200L-48P- 4X1000W (C5)Fixed115VAC53.1256.8957.3457.857.8155.2263.9264.8665.8468.3663.49450.31262.59463.36789.46872.6

230VAC52.6356.3756.8257.358.4754.7163.4164.3265.2767.6462.96350.02258.64453.81766.04843.89

C9200L-48PL- 4X600W (C5)Fixed115VAC42.8344.1544.6244.7245.3945.4551.0851.5252.253.4950.75840.17144.82241.99401.32445.35

230VAC42.3644.1944.4744.6145.2844.649.3349.9150.3651.5149.07539.48142.32237.52392.77434.06

C9200L- 48PXG-4X1000W (C5)Fixed115VAC82.687.888.2888.7689.9592.56103.53104.55105.57108.19102.972.14291.62496.85842.43930.11

230VAC81.7786.6287.1187.688.8291.87102.05103.02103.98106.4101.4772.5286.71486.25814.71898.24

C9200L- 24PXG-4X600W (C5)Fixed115VAC70.9473.8874.3774.8476.0277.3784.1285.068688.3283.8664.54173.05271.04431.68472.39

230VAC70.173.0473.6274.0775.1576.7482.9683.8684.7887.0982.7564.04170.02265.51420.96459.88

C9200L- 48PXG-2Y1000W (C5)Fixed115VAC81.8185.1485.8186.4988.0889.496.3297.5198.71101.7696.1771.45294.56500.25846.33934.08

230VAC79.5982.9483.6484.2885.8188.295.1796.3697.52100.49570.28283.88483.54812.2894.11

C9200L- 24PXG-2Y600W (C5)Fixed115VAC70.5473.0473.7874.4676.176.2583.584.7886.0989.2683.3565.58178.82280.13446.82489.62

230VAC68.8972.0272.6673.3574.9375.328283.3484.6487.8781.9265.01175.55274.59434.38475.39

C9200CX-8P-2X2G315W ACFixed115VAC34.535.635.735.835.935.137.837.93838.337.633.386.9150.9254.3280.2

230VAC34.335.435.535.535.73537.537.637.83837.333.185.9148.8249.4274.5

C9200CX-8P-2XGH315W HVDC/ACFixed277VAC3435.335.335.435.534.837.537.637.737.937.232.889.6153.1254.4279.4

380VDC3435.135.135.235.434.637.337.437.537.73732.889.8153253.4278.7

C9200CX-12P-2X2G315W ACFixed115VAC34.93737.137.237.435.739.539.639.840.239.233.888152.3256.2281.9

230VAC34.636.736.736.83735.539.239.439.539.838.933.587.1150.4251.1276.7

C9200CX-12P-2XGH315W HVDC/ACFixed277VAC34.636.736.836.93735.339.139.339.439.738.733.492.3155.1255.9281.4

380VDC34.536.536.536.636.835.238.93939.239.638.633.392.7155256.5281.8

C9200CX-12T-2X2G80W ACFixed115VAC2021.92222.122.321.125.125.325.425.924.718.7no PoEno PoEno PoEno PoE

230VAC20.12222.122.222.421.125.125.325.425.924.818.8no PoEno PoEno PoEno PoE

C9200CX-8UXG-2X315W ACFixed115VAC43.445.145.345.345.546.750.350.550.650.95040.1105.5170.5275.7301.9

230VAC43.144.744.844.94546.549.950.150.250.549.639.9103.5166.8268.7293.9

C9200 CX-8UXG-2XH315W HVDC/ACFixed277VAC43.2454545.145.346.450.450.550.7515040.1103.1166.1267.4292.3

380VDC43.144.944.94545.146.55050.150.350.549.739.6103.7166.4267.3292.2

C9200 CX-8PT-2GNAFixed115VAC18.119.619.619.619.718.221.221.221.321.420.91852.587.3143.7158

230VAC18.219.719.719.819.818.321.321.421.421.52118.152.586.9142.5156.5

C9200 Models Ordering information

Product numberProduct description

C9200-24T-ACatalyst 9200 24-port Data Switch, Network Advantage

C9200-24T-ECatalyst 9200 24-port Data Switch, Network Essentials

C9200-24P-ACatalyst 9200 24-port PoE+ Switch, Network Advantage

C9200-24P-ECatalyst 9200 24-port PoE+ Switch. Network Essentials

C9200-24PB-ACatalyst 9200 24-port PoE+, enhanced VRF, Network Advantage

C9200-24PXG-ECatalyst 9200 24-port 8xmGig, 16x1G, PoE+, Network Essentials

C9200-24PXG-ACatalyst 9200 24-port 8xmGig, 16x1G, PoE+, Network Advantage

C9200-48T-ACatalyst 9200 48-port Data Switch, Network Advantage

C9200-48T-ECatalyst 9200 48-port Data Switch, Network Essentials

C9200-48P-ACatalyst 9200 48-port PoE+ Switch, Network Advantage

C9200-48P-ECatalyst 9200 48-port PoE+ Switch, Network Essentials

C9200-48PL-ACatalyst 9200 48-Port partial PoE+ Switch, Network Advantage

C9200-48PL-ECatalyst 9200 48-Port partial PoE+ Switch, Network Essentials

C9200-48PB-ACatalyst 9200 48-port PoE+, enhanced VRF, Network Advantage

C9200-48PXG-ECatalyst 9200 48-port 8xmGig, 40x1G, PoE+, Network Essentials

C9200-48PXG-ACatalyst 9200 48-port 8xmGig, 40x1G, PoE+, Network Advantage

Network modules

C9200 Models Ordering information

Modular uplink network modules for C9200 Models

Product numberProduct description

C9200-NM-2Y (=)Catalyst 9200 2 x 25 GE Network Module, spare

C9200-NM-2Q (=)Catalyst 9200 2 x 40GE Network Module, spare

C9200-NM-4G (=)Catalyst 9200 4 x 1GE Network Module, spare

C9200-NM-4X (=)Catalyst 9200 4 x 10GE Network Module, spare

C9200-NM-BLANK (=)Catalyst 9200 BLANK Network Module, spare

C9200L models

C9200L Models Ordering information

Product numberProduct description

C9200L-24T-4G-ACatalyst 9200L 24-port Data 4x1G uplink Switch, Network Advantage

C9200L-24T-4G-ECatalyst 9200L 24-port Data 4x1G uplink Switch, Network Essentials

C9200L-24P-4G-ACatalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Advantage

C9200L-24P-4G-ECatalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Essentials

C9200L-48T-4G-ACatalyst 9200L 48-port Data 4x1G uplink Switch, Network Advantage

C9200L-48T-4G-ECatalyst 9200L 48-port Data 4x1G uplink Switch, Network Essentials

C9200L-48P-4G-ACatalyst 9200L 48-port PoE+ 4x1G uplink Switch, Network Advantage

C9200L-48P-4G-ECatalyst 9200L 48-port PoE+ 4x1G uplink Switch, Network Essentials

C9200L-48PL-4G-ACatalyst 9200L 48-port partial PoE+ 4x1G uplink Switch, Network Advantage

C9200L-48PL-4G-ECatalyst 9200L 48-port partial PoE+ 4x1G uplink Switch, Network Essentials

C9200L-24T-4X-ACatalyst 9200L 24-port Data 4x10G uplink Switch, Network Advantage

C9200L-24T-4X-ECatalyst 9200L 24-port Data 4x10G uplink Switch, Network Essentials

C9200L-24P-4X-ACatalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Advantage

C9200L-24P-4X-ECatalyst 9200L 24-port PoE+ 4x10G uplink Switch, Network Essentials

C9200L-48T-4X-ACatalyst 9200L 48-port Data 4x10G uplink Switch, Network Advantage

C9200L-48T-4X-ECatalyst 9200L 48-port Data 4x10G uplink Switch, Network Essentials

C9200L-48P-4X-ACatalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Advantage

C9200L-48P-4X-ECatalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Essentials

C9200L-48PL-4X-ACatalyst 9200L 48-port partial PoE+ 4x10G uplink Switch, Network Advantage

C9200L-48PL-4X-ECatalyst 9200L 48-port partial PoE+ 4x10G uplink Switch, Network Essentials

C9200L-24PXG-4X-ECatalyst 9200L 24-port 8xmGig, 16x1G, 4x10G, PoE+, Network Essentials

C9200L-24PXG-4X-ACatalyst 9200L 24-port 8xmGig, 16x1G, 4x10G, PoE+, Network Advantage

C9200L-48PXG-4X-ECatalyst 9200L 48-port 12xmGig, 36x1G, 4x10G PoE+, Network Essentials

C9200L-48PXG-4X-ACatalyst 9200L 48-port 12xmGig, 36x1G, 4x10G PoE+, Network Advantage

C9200L-24PXG-2Y-ECatalyst 9200L 24-port 8xmGig, 16x1G, 2x25G, PoE+, Network Essentials

C9200L-24PXG-2Y-ACatalyst 9200L 24-port 8xmGig, 16x1G, 2x25G, PoE+, Network Advantage

C9200L-48PXG-2Y-ECatalyst 9200L 48-port 8xmGig, 40x1G, 2x25G PoE+, Network Essentials

C9200L-48PXG-2Y-ACatalyst 9200L 48-port 8xmGig, 40x1G, 2x25G PoE+, Network Advantage

C9200CX models

C9200CX Models Ordering information

Product numberProduct description

C9200CX-12T-2X2G-ECatalyst 9200CX 12-port 1G, 2x10G and 3x1G, data, Network Essentials

C9200CX-12T-2X2G-ACatalyst 9200CX 12-port 1G, 2x10G and 3x1G, data, Network Advantage

C9200CX-12P-2X2G-ECatalyst 9200CX 12-port 1G, 2x10G and 2x1G, PoE+, Network Essentials

C9200CX-12P-2X2G-ACatalyst 9200CX 12-port 1G, 2x10G and 2x1G, PoE+, Network Advantage

C9200CX-8P-2X2G-ECatalyst 9200CX 8-port 1G, 2x10G and 2x1G, PoE+, Network Essentials

C9200CX-8P-2X2G-ACatalyst 9200CX 8-port 1G, 2x10G and 2x1G, PoE+, Network Advantage

C9200CX-8UXG-2X-ECatalyst 9200CX 4-port mGig and 4-port 1G, 2x10G, UPOE, Network Essentials

C9200CX-8UXG-2X-ACatalyst 9200CX 4-port mGig and 4-port 1G, 2x10G, UPOE, Network Advantage

C9200CX-12P-2XGH-ECatalyst 9200CX 12-port 1G, 2x10G and 2x1G, PoE+, HVDC, Network Essentials

C9200CX-12P-2XGH-ACatalyst 9200CX 12-port 1G, 2x10G and 2x1G, PoE+, HVDC, Network Advantage

C9200CX-8P-2XGH-ECatalyst 9200CX 8-port 1G, 2x10G and 2x1G, PoE+, HVDC, Network Essentials

C9200CX-8P-2XGH-ACatalyst 9200CX 8-port 1G, 2x10G and 2x1G, PoE+, HVDC, Network Advantage

C9200CX-8UXG-2XH-ECatalyst 9200CX 4-port mGig and 4-port 1G, 2x10G, UPOE, HVDC, Network Essentials

C9200CX-8UXG-2XH-ACatalyst 9200CX 4-port mGig and 4-port 1G, 2x10G, UPOE, HVDC, Network Advantage

C9200CX-8PT-2G-ECatalyst 9200CX 8-port 1G, 2x1G, Pass-through, Network Essentials

C9200CX-8PT-2G-ACatalyst 9200CX 8-port 1G, 2x1G, Pass-through, Network Advantage

Software licenses

C9200 software licenses

C9200 Models Ordering information

C9200 Cisco DNA software licenses

Product numberProduct description

C9200-DNA-E-24C9200 Cisco DNA Essentials Term 24-port

C9200-DNA-E-24-3YC9200 Cisco DNA Essentials, 24-port, 3 Year Term license

C9200-DNA-E-24-5YC9200 Cisco DNA Essentials, 24-port, 5 Year Term license

C9200-DNA-E-24-7YC9200 Cisco DNA Essentials, 24-port, 7 Year Term license

C9200-DNA-E-48C9200 Cisco DNA Essentials Term 48-port

C9200-DNA-E-48-3YC9200 Cisco DNA Essentials, 48-port, 3 Year Term license

C9200-DNA-E-48-5YC9200 Cisco DNA Essentials, 48-port, 5 Year Term license

C9200-DNA-E-48-7YC9200 Cisco DNA Essentials, 48-port, 7 Year Term license

C9200-DNA-A-24C9200 Cisco DNA Advantage Term 24-port

C9200-DNA-A-24-3YC9200 Cisco DNA Advantage, 24-port, 3 Year Term license

C9200-DNA-A-24-5YC9200 Cisco DNA Advantage, 24-port, 5 Year Term license

C9200-DNA-A-24-7YC9200 Cisco DNA Advantage, 24-port, 7 Year Term license

C9200-DNA-A-48C9200 Cisco DNA Advantage Term 48-port

C9200-DNA-A-48-3YC9200 Cisco DNA Advantage, 48-port, 3 Year Term license

C9200-DNA-A-48-5YC9200 Cisco DNA Advantage, 48-port, 5 Year Term license

C9200-DNA-A-48-7YC9200 Cisco DNA Advantage, 48-port, 7 Year Term license

C9200-LIC=Electronic Cisco DNA Upgrade License for C9200 switches. Note: when upgrading from CiscoDNA Essentials to Cisco DNA Advantage, Network Essentials is upgraded to Network Advantage

C9200-24-E-AC9200 24-port NW and Cisco DNA Essentials to NW and Cisco DNA Advantage Upgrade

C9200-24-E-A-324-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 3Y

C9200-24-E-A-524-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 5Y

C9200-24-E-A-724-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 7Y

C9200-48-E-AC9200 48-port NW and Cisco DNA Essentials to NW and Cisco DNA Advantage Upgrade

C9200-48-E-A-348-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 3Y

C9200-48-E-A-548-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 5Y

C9200-48-E-A-748-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 7Y

C9200 Cisco Catalyst software licenses

Product numberProduct description

C9200-DNX-E-24-3YC9200 Cisco Catalyst Essentials, 24-port, 3 Year Term license

C9200-DNX-E-24-5YC9200 Cisco Catalyst Essentials, 24-port, 5 Year Term license

C9200-DNX-E-24-7YC9200 Cisco Catalyst Essentials, 24-port, 7 Year Term license

C9200-DNX-E-48-3YC9200 Cisco Catalyst Essentials, 48-port, 3 Year Term license

C9200-DNX-E-48-5YC9200 Cisco Catalyst Essentials, 48-port, 5 Year Term license

C9200-DNX-E-48-7YC9200 Cisco Catalyst Essentials, 48-port, 7 Year Term license

C9200-DNX-A-24-3YC9200 Cisco Catalyst Advantage, 24-port, 3 Year Term license

C9200-DNX-A-24-5YC9200 Cisco Catalyst Advantage, 24-port, 5 Year Term license

C9200-DNX-A-24-7YC9200 Cisco Catalyst Advantage, 24-port, 7 Year Term license

C9200-DNX-A-48-3YC9200 Cisco Catalyst Advantage, 48-port, 3 Year Term license

C9200-DNX-A-48-5YC9200 Cisco Catalyst Advantage, 48-port, 5 Year Term license

C9200-DNX-A-48-7YC9200 Cisco Catalyst Advantage, 48-port, 7 Year Term license

C9200L software licenses

C9200L Models Ordering information

C9200L Cisco DNA software licenses

Product NumberProduct Description

C9200L-DNA-E-24C9200L Cisco DNA Essentials Term 24-port

C9200L-DNA-E-24-3YC9200L Cisco DNA Essentials, 24-port, 3 Year Term license

C9200L-DNA-E-24-5YC9200L Cisco DNA Essentials, 24-port, 5 Year Term license

C9200L-DNA-E-24-7YC9200L Cisco DNA Essentials, 24-port, 7 Year Term license

C9200L-DNA-E-48C9200L Cisco DNA Essentials Term 48-port

C9200L-DNA-E-48-3YC9200L Cisco DNA Essentials, 48-port, 3 Year Term license

C9200L-DNA-E-48-5YC9200L Cisco DNA Essentials, 48-port, 5 Year Term license

C9200L-DNA-E-48-7YC9200L Cisco DNA Essentials, 48-port, 7 Year Term license

C9200L-DNA-A-24C9200L Cisco DNA Advantage Term 24-port

C9200L-DNA-A-24-3YC9200L Cisco DNA Advantage, 24-port, 3 Year Term license

C9200L-DNA-A-24-5YC9200L Cisco DNA Advantage, 24-port, 5 Year Term license

C9200L-DNA-A-24-7YC9200L Cisco DNA Advantage, 24-port, 7 Year Term license

C9200L-DNA-A-48C9200L Cisco DNA Advantage Term 48-port

C9200L-DNA-A-48-3YC9200L Cisco DNA Advantage, 48-port, 3 Year Term license

C9200L-DNA-A-48-5YC9200L Cisco DNA Advantage, 48-port, 5 Year Term license

C9200L-DNA-A-48-7YC9200L Cisco DNA Advantage, 48-port, 7 Year Term license

C9200L-LIC=Electronic Cisco DNA Upgrade License for C9200L switches.

Note:when upgrading from Cisco DNA Essentials to Cisco DNA Advantage, Network Essentials is upgraded to Network Advantage

C9200L-24-E-AC9200L 24-port NW and Cisco DNA Essentials to NW and Cisco DNA Advantage Upgrade

C9200L-24-E-A-324-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 3Y

C9200L-24-E-A-524-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 5Y

C9200L-24-E-A-724-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 7Y

C9200L-48-E-AC9200L 48-port NW and Cisco DNA Essentials to NW and Cisco DNA Advantage Upgrade

C9200L-48-E-A-348-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 3Y

C9200L-48-E-A-548-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 5Y

C9200L-48-E-A-748-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 7Y

C9200L Cisco Catalyst software licenses

Product numberProduct description

C9200L-DNX-E-24-3YC9200L Cisco Catalyst Essentials, 24-port, 3 Year Term license

C9200L-DNX-E-24-5YC9200L Cisco Catalyst Essentials, 24-port, 5 Year Term license

C9200L-DNX-E-24-7YC9200L Cisco Catalyst Essentials, 24-port, 7 Year Term license

C9200L-DNX-E-48-3YC9200L Cisco Catalyst Essentials, 48-port, 3 Year Term license

C9200L-DNX-E-48-5YC9200L Cisco Catalyst Essentials, 48-port, 5 Year Term license

C9200L-DNX-E-48-7YC9200L Cisco Catalyst Essentials, 48-port, 7 Year Term license

C9200L-DNX-A-24-3YC9200L Cisco Catalyst Advantage, 24-port, 3 Year Term license

C9200L-DNX-A-24-5YC9200L Cisco Catalyst Advantage, 24-port, 5 Year Term license

C9200L-DNX-A-24-7YC9200L Cisco Catalyst Advantage, 24-port, 7 Year Term license

C9200L-DNX-A-48-3YC9200L Cisco Catalyst Advantage, 48-port, 3 Year Term license

C9200L-DNX-A-48-5YC9200L Cisco Catalyst Advantage, 48-port, 5 Year Term license

C9200L-DNX-A-48-7YC9200L Cisco Catalyst Advantage, 48-port, 7 Year Term license

C9200CX software licenses

C9200CX Models Ordering information

C9200CX Cisco DNA software licenses

Product NumberProduct Description

C9200CX-DNA-E-8C9200CX Cisco DNA Essentials Term 8-port

C9200CX-DNAE-8-3YC9200CX Cisco DNA Essentials, 8-port, 3 Year Term license

C9200CX-DNAE-8-5YC9200CX Cisco DNA Essentials, 8-port, 5 Year Term license

C9200CX-DNAE-8-7YC9200CX Cisco DNA Essentials, 8-port, 7 Year Term license

C9200CX-DNA-A-8C9200CX Cisco DNA Advantage Term 8-port

C9200CX-DNAA-8-3YC9200CX Cisco DNA Advantage, 8-port, 3 Year Term license

C9200CX-DNAA-8-5YC9200CX Cisco DNA Advantage, 8-port, 5 Year Term license

C9200CX-DNAA-8-7YC9200CX Cisco DNA Advantage, 8-port, 7 Year Term license

C9200CX-DNA-E-12C9200CX Cisco DNA Essentials Term 12-port

C9200CX-DNAE-12-3YC9200CX Cisco DNA Essentials, 12-port, 3 Year Term license

C9200CX-DNAE-12-5YC9200CX Cisco DNA Essentials, 12-port, 5 Year Term license

C9200CX-DNAE-12-7YC9200CX Cisco DNA Essentials, 12-port, 7 Year Term license

C9200CX-DNA-A-12C9200CX Cisco DNA Advantage Term 12-port

C9200CX-DNAA-12-3YC9200CX Cisco DNA Advantage, 12-port, 3 Year Term license

C9200CX-DNAA-12-5YC9200CX Cisco DNA Advantage, 12-port, 5 Year Term license

C9200CX-DNAA-12-7YC9200CX Cisco DNA Advantage, 12-port, 7 Year Term license

C9200CX-LIC=Electronic Cisco DNA Upgrade License for C9200CX switches. Note: when upgrading from Cisco DNA Essentials to Cisco DNA Advantage, Network Essentials is upgraded to Network Advantage

C9200CX-8-E-AC9200CX 8-port NW and Cisco DNA Essentials to NW and Cisco DNA Advantage Upgrade

C9200CX-8-E-A-3C9200CX 8-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 3Y

C9200CX-8-E-A-5C9200CX 8-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 5Y

C9200CX-8-E-A-7C9200CX 8-port NW and Cisco DNA Ess to NW and DNA Adv Upgrade License 7Y

C9200CX-12-E-AC9200CX 12-port NW and Cisco DNA Essentials to NW and Cisco DNA Advantage Upgrade

C9200CX-12-E-A-3C9200CX 12-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 3Y

C9200CX-12-E-A-5C9200CX 12-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 5Y

C9200CX-12-E-A-7C9200CX 12-port NW and Cisco DNA Ess to NW and Cisco DNA Adv Upgrade License 7Y

C9200CX Cisco Catalyst software licenses

Product NumberProduct Description

C9200CX-DNXE-12-3YC9200CX Cisco Catalyst Essentials software subscription, 12P, 3 Yr Lic

C9200CX-DNXE-12-5YC9200CX Cisco Catalyst Essentials software subscription, 12P, 5 Yr Lic

C9200CX-DNXE-12-7YC9200CX Cisco Catalyst Essentials software subscription, 12P, 7 Yr Lic

C9200CX-DNXE-8-3YC9200CX Cisco Catalyst Essentials software subscription, 8P, 3 Yr Lic

C9200CX-DNXE-8-5YC9200CX Cisco Catalyst Essentials software subscription, 8P, 5 Yr Lic

C9200CX-DNXE-8-7YC9200CX Cisco Catalyst Essentials software subscription, 8P, 7 Yr Lic

C9200CX-DNXA-12-3YC9200CX Cisco Catalyst Advantage software subscription, 12P, 3 Yr Lic

C9200CX-DNXA-12-5YC9200CX Cisco Catalyst Advantage software subscription, 12P, 5 Yr Lic

C9200CX-DNXA-12-7YC9200CX Cisco Catalyst Advantage software subscription, 12P, 7 Yr Lic

C9200CX-DNXA-8-3YC9200CX Cisco Catalyst Advantage software subscription, 8P, 3 Yr Lic

C9200CX-DNXA-8-5YC9200CX Cisco Catalyst Advantage software subscription, 8P, 5 Yr Lic

C9200CX-DNXA-8-7YC9200CX Cisco Catalyst Advantage software subscription, 8P, 7 Yr Lic

Stacking Cables

StackWise Cable Ordering information

StackWise-80 and StackWise-160 Kit and cables

Product numberProduct description

C9200-STACK-KIT=C9200 Stack Kit Spare

C9200L-STACK-KIT=C9200L Stack Kit Spare

STACK-T4-50CM50CM Type 3 Stacking Cable

STACK-T4-50CM=50CM Type 3 Stacking Cable, spare

STACK-T4-1M1M Type 3 Stacking Cable

STACK-T4-1M=1M Type 3 Stacking Cable, spare

STACK-T4-3M3M Type 3 Stacking Cable

STACK-T4-3M=3M Type 3 Stacking Cable, spare

Power supplies

Power Supply Ordering information

Power supplies

Product NumberProduct Description

PWR-C5-125WAC (=)125W AC Config 5 Power Supply

PWR-C5-125WAC/2125W AC Config 5 Power Supply - Secondary Power Supply

PWR-C5-600WAC (=)600W AC Config 5 Power Supply

PWR-C5-600WAC/2600W AC Config 5 Power Supply - Secondary Power Supply

PWR-C5-1KWAC (=)1KW AC Config 5 Power Supply

PWR-C5-1KWAC/21KW AC Config 5 Power Supply - Secondary Power Supply

PWR-C5-715WDC=715W DC Config 5 Power Supply

PWR-C6-125WAC (=)125W AC Config 6 Power Supply

PWR-C6-125WAC/2125W AC Config 6 Power Supply - Secondary Power Supply

PWR-C6-600WAC (=)600W AC Config 6 Power Supply

PWR-C6-600WAC/2600W AC Config 6 Power Supply - Secondary Power Supply

PWR-C6-1KWAC (=)1KW AC Config 6 Power Supply

PWR-C6-1KWAC/21KW AC Config 6 Power Supply - Secondary Power Supply

PWR-C6-715WDC=715W DC Config 6 Power Supply

PWR-C5-BLANK=Blank Module

PWR-ADPTAC-DC power adapter for the C9200CX-12T-2X2G compact switch (80W)

C9K-80W-ADPTAC-DC slim power adapter for the C9200CX-12T-2X2G compact switch (80W)

C9K-150W-ADPTAC-DC slim power adapter for the C9200CX-8PT-2G compact switch (150W)

C9K-ADPT-DCDC-DC power adapter for the C9200CX-12T-2X2G compact switch (80W)

C9K-ADPT-BRKT-12TPower adaptor bracket for C9200CX-12T-2X2G

C9K-ADPT-BRKT-8PTPower adaptor bracket for C9200CX-8PT-2G

C9K-CMPCT-PWR-CLPPower clip for the C9200CX compact switches (not compatible with HVDC SKUs)

Spare power cords Ordering information

Spare power cords

Product NumberProduct Description

CAB-TA-NA=AC power cord for Cisco Catalyst (North America)

CAB-TA-AP=AC power cord for Cisco Catalyst (Australia)

CAB-TA-AR=AC power cord for Cisco Catalyst (Argentina)

CAB-TA-SW=AC power cord for Cisco Catalyst (Switzerland)

CAB-TA-UK=AC power cord for Cisco Catalyst (United Kingdom)

CAB-TA-JP=AC power cord for Cisco Catalyst (Japan)

CAB-TA-250V-JP=Japan 250VAC power cord for Cisco Catalyst (Japan)

CAB-TA-125V-JP=Japan 125V AC Type A Power Cable (Japan

CAB-TA-EU=AC power cord for Cisco Catalyst (Europe)

CAB-TA-IT=AC power cord for Cisco Catalyst (Italy)

CAB-TA-IN=AC power cord for Cisco Catalyst (India)

CAB-TA-CN=AC power cord for Cisco Catalyst (China)

CAB-TA-DN=AC power cord for Cisco Catalyst (Denmark)

CAB-TA-IS=AC power cord for Cisco Catalyst (Israel)

CAB-ACBZ-12A=AC power cord for Cisco Catalyst (Brazil), 12A/125V BR-3-20 plug up to 12A

CAB-ACBZ-10A=AC power cord for Cisco Catalyst (Brazil), 10A/250V BR-3-10 plug up to 10A

CAB-C15-CBNCabinet jumper power cord, 250VAC 13A, C14 -C15 connectors

Mounting Accessories Ordering information

Product NumberProduct Description

ACC-KIT-T1=Accessory kit with 19 inch Type 1 rack mount

RACK-KIT-T1=19, 23, 24 inch and ETSI Type 1 rack mount kit

4PT-KIT-T2=4 Point rack mount kit New

REC-KIT-T1=Recessed 1RU rack mount for 9200L and 9200 switches

C9K-MGNT-TRAYMagnet and Mounting Tray for compact switches

C9K-CMPCT-DIN-MNTDIN Rail Mount for compact switches

RACKMNT-19-CMPACT19-Inch Rack Mounting Brackets for compact switches

C9K-CMPCT-CBLE-GRDCable guard for compact switches (for C9K-WALL-TRAY)

C9K-WALL-TRAYWall mount bracket for compact switches

C9K-CMPCT-DESK-MNTUnder desk mount for compact switches

C9K-ACC-RBFTRubber Feet For Table Top Setup 9200 and 9300

C9K-ACC-SCR-412-24 and 10-32 Screws For Rack Installation, Qty 4

CAB-GUIDE-1RU1RU Cable Management Guides 9200 and 9300

We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.

We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL,Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada,Moog etc.

Contact:

HONGKONG XIEYUAN TECH CO., LIMITED

Email:becky@hkxytech.com Web:www.hkxytech.com

Mobile:+86-15972186287(Whatsapp & Wechat)

Latest News

Cisco Catalyst Switch C9200L-24T-4G-E Cisco Catalyst 24-Port C9200L-24T-4G-E Gigabit Switch… November 14, 2025
Orbinox EW Uni-directional AWWA C520-14 Knife Gate Valve November 05, 2025
Orbinox ET (SER.20) Uni-directional MSS SP-81 Knife Gate Valve November 05, 2025
Orbinox HK (SER.18) Uni-directional High Performance for Off-seating Pressure Knife Gate Valve Orbinox HK (SER.18) Valve… November 05, 2025
Orbinox EK (SER.15) Uni-directional High Performance Knife Gate Valve Orbinox EK (SER.15) Valve… November 05, 2025
Orbinox OEX (SER.10) Uni-directional Knife Gate Valve OEX (SER.10) Knife Gate Valve… November 05, 2025
