Hirschmann M-SFP-LX+/LC EEC 942024001 Long-Reach Gigabit SFP

Hirschmann M-SFP-LX+/LC EEC 942024001 is a long-reach Gigabit Ethernet optical transceiver for compatible industrial switches. With duplex LC connectors and 9/125 µm single-mode fiber, the current manufacturer specification lists a 14 to 42 km link distance at 1310 nm.

Extended reach for industrial backbones

The M-SFP-LX+/LC EEC supports 1000 Mbit/s optical links where standard LX reach is insufficient. Typical applications include long industrial campuses, utility networks, transport infrastructure and connections between widely separated process areas.

The module is rated from -40°C to +85°C, uses approximately 1 W and has an IP20 enclosure. Digital diagnostics provide optical input power, optical output power and transceiver temperature for commissioning and maintenance.

Minimum link loss matters

This is not a drop-in choice for every short fiber run. The published range begins at 14 km and the optical budget begins at 5 dB, so an inadequately attenuated short link may overload the receiver. Calculate total link loss from fiber length, splices, connectors and patching, then confirm that both ends of the link meet the transceiver specifications.

Before ordering, verify switch compatibility, the matching optic at the remote end and the required project approvals. Any external attenuator should be selected only as part of a properly engineered optical design.

Request price and lead time

Send M-SFP-LX+/LC EEC, part number 942024001, with quantity, destination, switch model and estimated link loss. We can help check availability, lead time and sourcing options for your long-distance industrial fiber connection.

Disclaimer: HKXYTECH is an independent industrial products supplier. Hirschmann and Belden marks belong to their respective owners. Specifications and compatibility should be confirmed for the actual switch, software version, fiber plant and project requirements before ordering.
