Honeywell BW XT-XWHM-Y-CN Max XT II Four-Gas Detector

Honeywell BW XT-XWHM-Y-CN is a yellow BW Max XT II portable four-gas detector configured for combustible gas (LEL), oxygen (O2), hydrogen sulfide (H2S) and carbon monoxide (CO). Its integrated sampling pump makes it suitable for remote sampling and pre-entry checks where diffusion-only monitoring is not enough.

What does XT-XWHM-Y-CN mean?

In Honeywell BW ordering information, XT identifies the Max XT II family. The XWHM sensor code represents O2, combustible gas, H2S and CO. Y indicates the yellow housing, while CN is the published region code for China/New Zealand orders. Buyers should still confirm the destination-country certificate and charger configuration on the quotation.

Built-in pump for remote sampling

The BW Max XT II combines four-gas monitoring with an integrated pump. Honeywell lists a sampling draw of up to 75 ft / 23 m, enabling technicians to test tanks, vessels, utility spaces and other locations before entry. A pressure-based blockage alarm helps identify a restricted sample line.

• Measures LEL, O2, H2S and CO simultaneously.

• Visual, vibrating and 95 dB audible alarm types.

• IP66/67 ingress protection for demanding field conditions.

• One-button operation and continuous self-test functions.

• Compatible with supported Honeywell BW testing and calibration workflows.

Request XT-XWHM-Y-CN price and lead time

Send us the complete model, required quantity, delivery country and requested delivery date. We can help check current sourcing options, stock, lead time and quotation validity for XT-XWHM-Y-CN.

Disclaimer: HKXYTECH is an independent industrial products supplier. Honeywell and BW marks belong to their respective owners. Verify current certification, accessories and commercial terms before ordering.
