Honeywell SPXCDALMTXT Sensepoint XCD Toxic Gas Transmitter

Honeywell SPXCDALMTXT is a Sensepoint XCD toxic-gas transmitter body with an LM25 aluminum housing and M20 cable entries. This ordering code is supplied without a gas sensor; the compatible sensor cartridge must be selected separately for the required gas and measuring range.

Build the correct Sensepoint XCD measurement point

SPXCDALMTXT provides the field transmitter, display and connection platform for a compatible Sensepoint XCD toxic-gas sensor. The plug-in sensor determines the target gas and measuring range, so a complete purchase requires both parts to be matched carefully. Common toxic-gas applications may include carbon monoxide, hydrogen sulfide or hydrogen, subject to the supported sensor list and required certification.

Transmitter features and procurement checks

The Sensepoint XCD platform uses a tri-color backlit LCD for local status indication and magnetic switches for supported non-intrusive configuration. A 4–20 mA output and configurable alarm/fault relays support integration with compatible control systems. Optional communication and the final operating specification depend on the exact transmitter and sensor combination.

• Identify the target gas and required measuring range.

• Select the correct compatible plug-in sensor cartridge.

• Verify LM25 housing, M20 entries and installation accessories.

• Confirm destination approvals, outputs and commissioning requirements.

Request SPXCDALMTXT price and compatible sensor support

Send us the transmitter model, target gas, measuring range, quantity, delivery country and required date. We can help check sourcing options, compatible sensor selection, availability and lead time for Honeywell SPXCDALMTXT.

Disclaimer: HKXYTECH is an independent industrial products supplier. Honeywell and Sensepoint marks belong to their respective owners. Verify current sensor compatibility, approvals and installation requirements before ordering.
