MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

News June 07, 2021

MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock



MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock




Description of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


The MTL4840 HART® connection system provides a simple interface between smart devices in the field and HART® instrument management software run on a PC.

The system is based on 16-channel modularity to provide a compact, easily configurable and expandable system. Using a standard RS485 serial link, up to 7936 individual HART® devices can be connected to a single workstation.


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


For the optimum solution, choose from a range of general purpose and IS termination boards. For maximum flexibility the BPHM64 HART® backplane locates an MTL4841 communications module and up to four MTL4842 interface modules. General purpose HART® connection units and IS backplanes are also available, each fitted with an interface cable for connection to the BPHM64 HART® backplane.MTL4841 and MTL4842 modules can also be located on HMU16 termination boards for general purpose applications or on BPMH16 / BPMH16U / BPSH16 / BPSH16-32 backplanes for IS isolator requirements.


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


The DIN-rail mounting HCU16 and HCU16AOHART® connect to 16 general purpose field instruments while maintaining channel to channel isolation. Resistor conditioning options are compatible with all I/O cards. It allows pass-through connections for transmitter power supply, input signal and common.


The HCU16AO unit includes HART® filters for I/O cards incompatible with HART® signals.

MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

BPMH16/BPMH16U/BPSH16/BPSH16-32 backplanes with MTL4840 HART® modules fitted, connect either 16 or 32 IS field instruments. Adapter cards are available for the BPMH16U for easy integration to I/O cards and users have a choice of a DIN-rail mounting option.

Numerous features may be included in the connection units and backplanes, as required. Channel to channel isolation; resistors where required for HART® signal conditioning; and HART® filters for analogue systems where the output signal interferes with HART® data or becomes unstable with the presence of the HART® signal.

Customised backplanes and connection units are available to provide direct connection from DCS I/O cables, replacing the standard termination board.

MTL HART multiplexers are certified by BASEEFA as a safety related sub-system to IEC61508.


Features of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


*  SIL3 rating
*  Connect up to 7936 loops to a single PC
*  LED indication of loop being scanned
*  Easily scalable modular system
*  Compact, ideal for new projects and upgrades
*  Channel to channel isolation option



MTL4841 COMMUNICATIONS MODULE of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


Host system interface
RS485 2-wire multidrop
Up to 31 MTL4841 modules can be connected to one host station
Unit address: switch-selectable on top of module

MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


Isolation  RS485 output isolated from backplane power supply
Serial communication parameters
RS485 Baud rate: 1.2, 9.6, 19.2, 38.4kbaud, switch-selectable on top of module
RS485 highway length: up to 1km
MTL system interface Links with up to 16 MTL4842 HART® interface modules via interface bus on backplane/ribbon cable
LED indicators  Green: one provided for power and status indication

MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


Power requirements
Powered from backplane
Power consumption
<1.0W
Instrument management software supported  See 'Instrument management software'


MTL4842 HART® INTERFACE MODULE of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL systems interface
Links up to 16 loops via backplanes
Receives multiplexer control signals via interface bus from
MTL4841 and selects one channel for communication

Unit address   Switch selectable on top of module
Interface bus  Total length of interface bus between module 1 and module 16 must not exceed 4m

MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


LED indicators
Green: one provided for power

Amber: one to indicate unit is selected by MTL4841
Red: four to identify loop address
Power requirements  Powered from backplane
Power consumption   <0.1W


MTL4000 SERIES MODULES of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


(See 'MTL4000 Series' for detailed specifications and circuit diagrams)
MTL4041A: Current repeater, 4/20mA, passive input for smart transmitters
MTL4041B: Repeater power supply, 4/20mA, for 2- or 3-wire transmitters
MTL4041P: High power repeater power supply, 4/20mA, for 2- or 3-wire transmitters
MTL4044: Repeater power supply, 4/20mA, two channel, for 2 wire transmitters
MTL4046/C: Isolating driver, for HART® valve positioners
MTL4046P: High power isolating driver for HART® valve positioners



MTL4840 SERIES ORDERING INFORMATION of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4840 Series modules of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4841            HART communications module pre-configured for Cornerstone™ protocol
MTL4841-AMS  HART communications module pre-configured for AMS Intelligent Device Manager
MTL4841-PRM  HART communications module pre-configured for PRM
MTL4842           HART interface module(communicates with up to 16 loops)


General purpose connection units of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


BPHM64 64 ch HART backplane HART interface connector
HCU16 HART connection unit No parallel resistor, 0Ω link fitted in series
HCU16-P250 HART connection unit 250Ω parallel resistor, 0Ω link fitted in series
HCU16-S200 HART connection unit No parallel resistor, 200Ω resistor fitted in series
HCU16-S150 HART connection unit No parallel resistor, 150Ω resistor fitted in series
HCU16AO 16 ch HART connection unit With HART filters
HMU16 16 ch HART communication unit


MTL4000 backplanes of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


BPMH16 16 ch backplane Safe-area multiway connector
BPSH16 16 ch backplane Safe-area screw-clamp connector
BPSH16-32 32 ch HART backplane
BPMH16U 16 ch HART backplane Requires backplane adapter card (call MTL for options)

Backplane accessories of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

ERK18 Earth rail kit For BPMH16 and BPSH16 backplanes
TSK18 Tagging strip kit For BPMH16 and BPSH16 backplanes
ELC38 38-way Elco connector For BPMH16 safe-area connection
FUS02 Fuse kit, pack of 10 Protects MTL4841/4842
FUS16 Fuse kit, pack of 10 Protects backplane module positions 1 to 16
VMPH16 Backplane mounting plate For DIN-rail and non-metallic surface mounting(BPMH16 and BPSH16 only)
DMK01 DIN-rail mounting kit DIN-rail mounting kit, T- or G-section (pack of 40) 16-way backplanes require 6
SMS01 Surface mounting kit Pack of 40 - 4 required for each backplane
HM64RIB10-xx Ribbon Cable 10-way -xx specifies the cable length - max 4m
HM64RIB20-xx Ribbon Cable 20-way -xx specifies the cable length - max 4.5m


Isolating interface modules and accessories of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL4041A Current repeater 4/20mA, passive input, for smart transmitters
MTL4041B Repeater power supply 4/20mA, for 2- or 3-wire transmitters
MTL4041P High power repeater power supply 4/20mA, for 2- or 3-wire transmitters
MTL4044 Repeater power supply 2ch, 4/20mA, smart, for 2-wire transmitters
MTL4046 Isolating driver For HART valve positioners
MTL4046C Isolating driver For HART valve positioners
MTL4046P High power isolating driver For HART valve positioners
CCH01 Crimp connector header
CRC01 Large crimps Pack of 100
CRC02 Small crimps Pack of 100
SCC01 Screw-clamp connector
MPL01 Module position label, blank Pack of 50

Literature of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


INM4840 MTL4840 instruction manual




Product Code      Description of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


intrinsically safe logo Symbol denotes that the equipment is suitable for use in hazardous area applications.
fsm logo Symbol denotes that the product has been assessed for functional safety applications.
SM45-55-AI SM45-55-AI is FSM FSM Safety Manual - Analogue Input Modules
SM45-55-AO SM45-55-AO is FSM FSM Safety Manual - Analogue Output Modules
SM45-55-BI SM45-55-BI is FSM FSM Safety Manual - Binary Input Modules
SM45-55-MMI SM45-55-MMI is FSM FSM Safety Manual - Machine Monitor Interfaces
SM45-55-SAD SM45-55-SAD is FSM FSM Safety Manual - Solenoid / Alarm Driver Modules

1. Intro of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

INA4500 MTL4500/4600 range Instructions for Safe Use
INM4500/4600 MTL4500/4600 range Instruction Manual
MTL4500-5500-ACC Backplanes, Enclosures & Accessories
MTL4500-5500-CS Common Specifications
MTL4500-5500-DS MTL4500-5500 range Data Set

2. Digital Input of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4501-SR MTL4501-SR is intrinsically safe MTL4501-SR is FSM 1ch DI failsafe solid-state output + LFD alarm
MTL4504 MTL4504 is intrinsically safe MTL4504 is FSM 1ch DI relay output + LFD alarm + phase reversal
MTL4510 MTL4510 is intrinsically safe 4ch DI solid-state output
MTL4510B MTL4510B is intrinsically safe 4ch DI multifunction solid-state output
MTL4511 MTL4511 is intrinsically safe MTL4511 is FSM 1ch DI relay output
MTL4513 MTL4513 is intrinsically safe 2ch DI solid-state output
MTL4514D MTL4514D is intrinsically safe MTL4514D is FSM 1ch switch/prox input, dual output relay
MTL4514_B MTL4514_B is intrinsically safe MTL4514_B is FSM 1ch DI relay output + LFD alarm
MTL4516 MTL4516 is intrinsically safe MTL4516 is FSM 2ch DI relay output
MTL4516C MTL4516C is intrinsically safe MTL4516C is FSM 2ch DI with changeover relay output
MTL4517 MTL4517 is intrinsically safe MTL4517 is FSM 2ch DI relay output + LFD alarm

3. Digital Output of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL4521 MTL4521 is intrinsically safe MTL4521 is FSM Loop powered solenoid driver
MTL4521L MTL4521L is intrinsically safe MTL4521L is FSM loop powered solenoid driver IIC
MTL4523 MTL4523 is intrinsically safe MTL4523 is FSM Solenoid driver with LFD
MTL4523L MTL4523L is intrinsically safe MTL4523L is FSM Loop powered solenoid driver + LFD
MTL4523R MTL4523R is intrinsically safe MTL4523R is FSM Solenoid driver with LFD
MTL4523V-VL MTL4523V-VL is intrinsically safe MTL4523V-VL is FSM Solenoid/Alarm driver with voltage control
MTL4524 MTL4524 is intrinsically safe MTL4524 is FSM Switch operated solenoid driver
MTL4524S MTL4524S is intrinsically safe MTL4524S is FSM Switch operated solenoid driver, 24V override
MTL4525 MTL4525 is intrinsically safe MTL4525 is FSM Switch operated solenoid driver low power
MTL4526 MTL4526 is intrinsically safe 2ch switch operated relay

4. Analogue Input of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL4541 MTL4541 is intrinsically safe MTL4541 is FSM 1ch 2/3 wire Transmitter repeater
MTL4541A MTL4541A is intrinsically safe 1ch Transmitter repeater, passive input
MTL4541AS MTL4541AS is intrinsically safe 1ch Transmitter repeater, passive input, current sink
MTL4541B MTL4541B is intrinsically safe MTL4541B is FSM MTL4041B replacement
MTL4541P MTL4541P is intrinsically safe MTL4041P replacement
MTL4541S MTL4541S is intrinsically safe MTL4541S is FSM 1ch 2/3 wire Transmitter repeater, current sink
MTL4541T MTL4541T is intrinsically safe 2/3 wire Transmitter repeater
MTL4544 MTL4544 is intrinsically safe MTL4544 is FSM 2ch 2/3 wire Transmitter repeater
MTL4544A MTL4544A is intrinsically safe 2ch Transmitter repeater, passive input
MTL4544AS MTL4544AS is intrinsically safe 2ch Transmitter repeater, passive input, current sink
MTL4544B MTL4544B is intrinsically safe MTL4044 replacement
MTL4544D MTL4544D is intrinsically safe MTL4544D is FSM 2/3 wire transmitter repeater, dual output
MTL4544S MTL4544S is intrinsically safe MTL4544S is FSM 2ch 2/3 transmitter repeater, current sink

5. Analogue Output of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL4546 MTL4546 is intrinsically safe MTL4546 is FSM 1ch 4-20mA smart isolating driver + LFD
MTL4546C MTL4546C is intrinsically safe MTL4546C is FSM 1ch 4-20mA smart isolating driver + oc LFD
MTL4546S MTL4546S is intrinsically safe 1ch 4-20mA HART isolating driver + LFD
MTL4546Y MTL4546Y is intrinsically safe MTL4546Y is FSM 1ch 4-20mA smart isolating driver + oc LFD
MTL4549 MTL4549 is intrinsically safe MTL4549 is FSM 2ch 4-20mA smart isolating driver + LFD
MTL4549C MTL4549C is intrinsically safe MTL4549C is FSM 2ch 4-20mA smart isolating driver + oc LFD
MTL4549Y MTL4549Y is intrinsically safe MTL4549Y is FSM 2ch 4-20mA smart isolating driver + oc LFD

6. Temperature Input of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL4573 MTL4573 is intrinsically safe 1ch Temperature converter, RTD / THC
MTL4575 MTL4575 is intrinsically safe 1ch Temperature converter, RTD / THC with alarm
MTL4576-RTD MTL4576-RTD is intrinsically safe 2ch Temperature converter, RTD
MTL4576-THC MTL4576-THC is intrinsically safe 2ch Temperature converter, THC
MTL4581 MTL4581 is intrinsically safe 1ch mV/THC isolator for low-level signals
MTL4582B MTL4582B is intrinsically safe MTL4582B is FSM 1ch resistance isolator to repeat RTD signals

7. Pulse and Vibration of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4531 MTL4531 is intrinsically safe MTL4531 is FSM 1ch vibration probe interface
MTL4532 MTL4532 is intrinsically safe 1ch pulse isolator, digital or analogue output

8. Fire and Smoke of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4561 MTL4561 is intrinsically safe MTL4561 is FSM 2ch loop-powered, for fire and smoke detectors

9. General of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL4599 Dummy isolator
MTL4599N General purpose feed-through module



Following is the part number & description   MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


Digital Input of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL5501-SR  1ch DI failsafe solid-state output + LFD alarm
MTL5510 4ch DI solid-state ouput
MTL5510B 4ch DI multifunction solid-state output
MTL5511 1ch DI relay output
MTL5513  2ch DI solid-state output
MTL5514  1ch DI relay output + LFD alarm
MTL5514D  1ch switch/prox input, dual output relay
MTL5516C 2ch DI with changeover relay output

MTL5517 2ch DI relay output + LFD alarm



Digital Output of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL5521 Loop powered solenoid driver, IIC
MTL5522  Loop powered solenoid driver, IIB
MTL5523 Solenoid driver with LFD
MTL5523V - VL  Solenoid/Alarm driver with voltage control
MTL5524  Switch operated solenoid driver
MTL5525 Loop powered solenoid driver low power

MTL5526 2ch switch operated relay


Analogue Input of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL5541 1ch 2/3 wire Transmitter repeater
MTL5541A  1ch Transmitter repeater, passive input
MTL5541AS 1ch Transmitter repeater, passive input, current sink
MTL5541S 1ch 2/3 wire Transmitter repeater, current sink
MTL5544  2ch 2/3 wire Transmitter repeater
MTL5544A  2ch Transmitter repeater, passive input
MTL5544AS  2ch Transmitter repeater, passive input, current sink
MTL5544D 1ch 2/3 wire Transmitter repeater, dual output

MTL5544S 2ch 2/3 wire Transmitter repeater, current sink


Analogue Output of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL5546 1ch 4-20mA smart isolating driver + LFD
MTL5546Y  1ch 4-20mA smart isolating driver + oc LFD
MTL5549 2ch 4-20mA smart isolating driver + LFD

MTL5549Y 2ch 4-20mA smart isolating driver + oc LFD


Temperature Input of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5575 1ch Temperature converter, RTD / THC with alarm
MTL5576-RTD 2ch Temperature converter, RTD
MTL5576-THC 2ch Temperature converter, THC
MTL5581 1ch mV/THC isolator for low-level signals

MTL5582 1ch resistance isolator


Pulse and Vibration of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MTL5531  1ch vibration probe interface
MTL5532  1ch pulse isolator, digital or analogue output

MTL5533 2ch vibration probe interface


Fire and Smoke of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5561  2ch loop-powered, for fire and smoke detectors


General of MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock

MPA5500  85 - 265V ac power adaptor
MTL5599 Dummy isolator
MTL5991 24V dc power supply



MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL7706 MTL7707 MTL7710 MTL7715 MTL7722 MTL7728 MTL7729 MTL7741 MTL7742 MTL7743 MTL7745 MTL7755 MTL7756 MTL7758 MTL7760 MTL7761 MTL7764 MTL7765 MTL7766 MTL7767 MTL7778 MTL7787 MTL7788 MTL7789 MTL7796 MTL7798 MTL7799


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL7706+ Shunt-Diode Safety Barrier
MTL7707+ Shunt-Diode Safety Barrier
MTL7707P+ Shunt-Diode Safety Barrier
MTL7710+ Shunt-Diode Safety Barrier
MTL7715+ Shunt-Diode Safety Barrier
MTL7715P+ Shunt-Diode Safety Barrier
MTL7722+ Shunt-Diode Safety Barrier
MTL7728+ Shunt-Diode Safety Barrier
MTL7728- Shunt-Diode Safety Barrier
MTL7728ac Shunt-Diode Safety Barrier
MTL7728P+ Shunt-Diode Safety Barrier
MTL7729P+ Shunt-Diode Safety Barrier
MTL7741 Shunt-Diode Safety Barrier
MTL7742 Shunt-Diode Safety Barrier
MTL7743 Shunt-Diode Safety Barrier
MTL7744 Shunt-Diode Safety Barrier
MTL7745 Shunt-Diode Safety Barrier
MTL7755ac Shunt-Diode Safety Barrier
MTL7756ac Shunt-Diode Safety Barrier
MTL7758+ Shunt-Diode Safety Barrier
MTL7758- Shunt-Diode Safety Barrier
MTL7760ac Shunt-Diode Safety Barrier
MTL7761ac Shunt-Diode Safety Barrier
MTL7761Pac Shunt-Diode Safety Barrier
MTL7764+ Shunt-Diode Safety Barrier
MTL7764ac Shunt-Diode Safety Barrier
MTL7765ac Shunt-Diode Safety Barrier
MTL7766ac Shunt-Diode Safety Barrier
MTL7766Pac Shunt-Diode Safety Barrier
MTL7767+ Shunt-Diode Safety Barrier
MTL7778ac Shunt-Diode Safety Barrier
MTL7779+ Shunt-Diode Safety Barrier
MTL7787+ Shunt-Diode Safety Barrier
MTL7787P+ Shunt-Diode Safety Barrier
MTL7788+ Shunt-Diode Safety Barrier
MTL7788R+ Shunt-Diode Safety Barrier
MTL7789+ Shunt-Diode Safety Barrier
MTL7796+ Shunt-Diode Safety Barrier
MTL7796– Shunt-Diode Safety Barrier
MTL7798 Power Feed Module
MTL7799 Dummy Barrier


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL7706+ MTL7707+ MTL7707P+ MTL7710+ MTL7715+ MTL7722+ MTL7728+ MTL7728- MTL7728AC MTL7728P+ MTL7729P+ MTL7741 MTL7742 MTL7743 MTL7744 MTL7745 MTL7755AC MTL7756AC MTL7758- MTL7758+ MTL7760AC MTL7761AC MTL7761PAC MTL7764+ MTL7764AC MTL7765AC MTL7766AC MTL7766PAC MTL7767+ MTL7787AC MTL7779+ MTL7787+ MTL7787- MTL7787P+ MTL7788+ MTL7788R+ MTL7789+ MTL7796- MTL7796+ MTL7798 MTL7799


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


BPL7700 ISP7000 TGL7700 TH7700 MLTHR7000 MLETL7000 IMB57 ERB57S ERB57O MLETM7 SAF7712 SAF7756 HAZ7734 HAZ7778


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL7706
MTL7707+
MTL7707P+
MTL7741
MTL7742
MTL7743
MTL7744
MTL7745
MTL7787+
MTL7787P+
MTL7788+
MTL7788R+
MTL7789+


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5011B , upgraded model: MTL5511
MTL5018 , upgraded model: MTL5516C
MTL5041 , upgraded model: MTL5541
MTL5042 , upgraded model: MTL5541
MTL5043 , upgraded model: MTL5544
MTL5044 , upgraded model: MTL5544
MTL5045 , upgraded model: MTL5546
MTL5046 , upgraded model: MTL5546
MTL5074 , upgraded model: MTL5575
MTL7787+
MTL5022 , upgraded model: MTL5522
MTL5031 , upgraded model: MTL5531 or MTL5533


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5011B MTL5018 MTL5041 MTL5042 MTL5043 MTL5044 MTL5045 MTL5046 MTL5074
MTL702+ MTL705+ MTL706+ MTL707+ MTL707P+ MTL708+ MTL710+ MTL710- MTL710AC MTL710P+ MTL710P- MTL715+ MTL715- MTL715P+ MTL722+ MTL722- MTL722P+ MTL728+ MTL728- MTL728AC MTL728P+ MTL729P+ MTL751AC MTL755AC



MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4013 MTL4014 MTL4015 MTL4016 MTL4017 MTL4021 MTL4023 MTL4024 MTL4025 MTL4031 MTL4032 MTL4041 MTL4042 MTL4043 MTL4044 MTL4045 MTL4046 MTL4047 MTL4053 MTL4061 MTL4073 MTL4081 MTL4215 MTL4216 MTL4220


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5011 MTL5012 MTL5014 MTL5015 MTL5017 MTL5018 MTL5021 MTL5022 MTL5023 MTL5024 MTL5025 MTL5031 MTL5040 MTL5041 MTL5043 MTL5046 MTL5044 MTL5045 MTL5049 MTL5042 MTL5051 MTL5053 MTL5061 MTL5074 MTL5081 MTL5099 MTL5314 MTL5349


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4501-SR, MTL4504, MTL4510, MTL4510B, MTL4511, MTL4513, MTL4514 (B)(D), MTL4516, MTL4516C, MTL4517, MTL4521, MTL4521L, MTL4523, MTL4523L, MTL4523R, MTL4523V, MTL4523VL, MTL4524, MTL4524S, MTL4525, MTL4526, MTL4531, MTL4532, MTL4533, MTL4541, MTL4541A, MTL4541AS, MTL4541B, MTL4541P, MTL4541S, MTL4541T, MTL4544, MTL4544A, MTL4544AS, MTL4544B, MTL4544D, MTL4544S, MTL4546, MTL4546C, MTL4546S, MTL4546Y, MTL4549, MTL4549C, MTL4549Y, MTL4561, MTL4575, MTL4576-RTD, MTL4576-THC, MTL4581


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5501-SR, MTL5510, MTL5510B, MTL5511, MTL5513, MTL5514, MTL5514D, MTL5516C, MTL5517, MTL5521, MTL5522, MTL5523, MTL5523V, MTL5523VL, MTL5524, MTL5525, MTL5526, MTL5531, MTL5532, MTL5533, MTL5541, MTL5541A, MTL5541AS, MTL5541S, MTL5544, MTL5544A, MTL5544AS, MTL5544D, MTL5544S, MTL5546, MTL5546Y, MTL5549, MTL5549Y, MTL5561, MTL5575, MTL5576-RTD, MTL5576-THC, MTL5581, MTL5582 MTL5544D MTL5575 MTL5516C MTL4541 MTL5541 MTL5546Y ICC212 IOP32 IOP32D


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


ICC201-I1-O1 ICC201-I1-O2 ICC201-I2-O1 ICC201-I2-O2 ICC201-I2-O2 ICC211-I1-O2 ICC211-I2-O1 ICC211-I2-O2 ICC212 ICC221
 ICC222 ICC241-T3 ICC241-T1 ICC241-T2 ICC301-I9-O1 ICC312 ICC316-T2 ICC317-T2-LFD ICC352-T1 ICC352-T2 ICC441 ICC446


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4510 MTL4510B MTL4511 MTL4513 MTL4514 MTL4514B MTL4514D MTL4516 MTL4516C MTL4517 MTL4521 MTL4521L MTL4523 MTL4524R MTL4523L MTL4524 MTL4524S MTL4524 MTL4526 MTL4531 MTL4532 MTL4541 MTL4541A MTL4541B MTL4544 MTL4544A MTL4544D MTL4544S MTL4546Y MTL4549 MTL4549Y MTL4546 MTL4573 MTL4575 MTL4576-RTD MTL4576-THC MTL4581 MTL4599 MTL4599N


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5514D MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5523V MTL5523VL MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5533 MTL5541 MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S MTL5546 MTL5546Y MTL5549 MTL5549Y MTL5561 MTL5573 MTL5575 MTL5576-RTD MTL5576-THC MTL5581 MTL5582 MTL5599 MTL5314 MTL5501-SR MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5533 MTL5541 MTL5541A MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4501-SR MTL4504 MTL4510 MTL4510B MTL4511 MTL4513 MTL4514 MTL4516 MTL4516C MTL4517 MTL4521 MTL4521L MTL4523 MTL4523R MTL4523L MTL4524 MTL4524S MTL4525 MTL4526 MTL4531 MTL4532 MTL4533 MTL4541 MTL4541A MTL4541AS MTL4541B MTL4541P MTL4541S MTL4544 MTL4544A MTL4544AS MTL4544B MTL4544D MTL4544S MTL4546 MTL4546C MTL4546Y MTL4549 MTL4549C MTL4549Y MTL4561 MTL4575 MTL4576-RTD MTL4576-THC MTL4599 MTL4599N


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


SD07 SD16 SD32 SD55 SD07X SD16X SD32X SD55X SD150X SD275X SD07R SD16R SD32R SD55R SD07R3 SD16R3 SD32R3 SD55R3 SDRTD SD32T3 SDPSTN SLP07D SLP16D SLP32D MA15/D/1/SI MA15/D/2/SI MA15/D/1TT/SI MA15/D/2TT/L MA30/D/1/SI MA30/D/2/SI MA30/D/3/SI MA05/D/1 MA05/D/2 MA10/D/1 MA10/D/2 MA05/SC/1 MA05/SC/2 MA10/SC/1 MA10/SC/2 MA05/I/1 MA05/I/2 MA10/I/1 MA10/I/2


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock



TP48-N TP48-N-NDI TP48-I TP48-I-NDI TP48-G TP48-G-NDI TP48-3-N-NDI TP48-3-I-NDI TP48-3-G-NDI TP48-3-N TP48-3-I TP48-3-G TP48-4-N-NDI TP48-4-I-NDI TP48-4-G-NDI TP48-4-N TP48-4-I TP48-4-G ICC201-I1-O1 ICC201-I1-O2 ICC201-I2-O1 ICC201-I2-O2 ICC201-I2-O2 ICC211-I1-O2 ICC211-I2-O1 ICC211-I2-O2 ICC212 ICC221 ICC222 ICC241-T3 ICC241-T1 ICC241-T2 ICC301-I9-O1 ICC312 ICC316-T2 ICC317-T2-LFD ICC352-T1 ICC352-T2 ICC441 ICC446


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5011B MTL5012 MTL5012S MTL5014 MTL5015 MTL5017 MTL5018 MTL5018AC MTL5021 MTL5021-SR MTL5022 MTL5022-SR MTL5023 MTL5024 MTL5025 MTL5025-SR MTL5031 MTL5032 MTL5040 MTL5041 MTL5042 MTL5042-SR MTL5043 MTL5044 MTL5045 MTL5046 MTL5049 MTL5051 MTL5061 MTL5061-SR MTL5074 MTL5074-RTD MTL5081 MTL5082 MTL5099 MTL5314 MTL5344 MTL5349 MTL5531-111LI MTL5531-115LI MTL5991 MPA5500 MTL5501-SR MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5514D MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5523V MTL5523VL MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5532-R MTL5533 MTL5541 MTL5541A MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S MTL5546 MTL5546Y MTL5549 MTL5549Y MTL5561 MTL5573 MTL5575 MTL5575-R MTL5576-RTD MTL5576-THC MTL5581 MTL5582 MTL5599


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL5510 MTL5510B MTL5511 MTL5513 MTL5514 MTL5514D MTL5516C MTL5517 MTL5521 MTL5522 MTL5523 MTL5523V MTL5523VL MTL5524 MTL5525 MTL5526 MTL5531 MTL5532 MTL5533 MTL5541 MTL5541AS MTL5541S MTL5544 MTL5544A MTL5544AS MTL5544D MTL5544S MTL5546 MTL5546Y MTL5549 MTL5549Y MTL5561 MTL5573 MTL5575 MTL5576-RTD MTL5576-THC MTL5581 MTL5582 MTL5599 MTL5314 MTL5011B MTL5014 MTL5022 MTL5024 MTL5031 MTL5042 MTL5042 MTL5046 MTL5074 MTL5082


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


MTL4510 MTL4510B MTL4511 MTL4513 MTL4514 MTL4514B MTL4514D MTL4516 MTL4516C MTL4517 MTL4521 MTL4521L  MTL4523 MTL4524R MTL4523L MTL4524 MTL4524S MTL4524 MTL4526 MTL4531 MTL4532 MTL4541 MTL4541A MTL4541B MTL4544 MTL4544A MTL4544D MTL4544S MTL4546Y MTL4549 MTL4549Y MTL4546 MTL4573 MTL4575 MTL4576-RTD MTL4576-THC MTL4581 MTL4599 MTL4599N


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock


HAZ1-3 HAZ4-6 SAF1-3 SAF4-6 SAF7-9 SAF10-12 PWR5000 HAZ-CJC TAG57 TGL57 PB-8T PB-16T PB-24T PB-32T IMB57 MLTHR2 ERB57S ERB57O ERL7 MLETM7 MS010 TH5000 PCS45 PCL45USB DX070 DX170 BMK08 BMK16 DMK01 DMP08 DVK16 MCC45 MCK45 SCK45 MPL01 PCL45USB PCS45 CPM08 CPM16U CPM32U CPS04 CGS08 CPS08 CPS16 CPS16C-250 CPS24 CPS16C BPS04 BPS08 ERK04 ERK06 ERK08 ERK16 HMP24 SVK16 TSK08 TSK16 TSK24


MTL4842 HART Interface Modules MTL4841 Communications Modules MTL4841 MTL4842 Modules Brand Original New In Stock



We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers,Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.


We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL,Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada,Moog etc.


Contact:
HONGKONG XIEYUAN TECH CO., LIMITED
Email:becky@hkxytech.com   Web:www.hkxytech.com
Mobile:+86-15972186287(Whatsapp & Wechat)
CONTACT ADDRESS

7-A16, Caishen Commercial Plaza, Hankou Railway Station, Wuhan, China

WRITE TO US

becky@hkxytech.com

CALL US

+86 027-8580 6199

MOBILE PHONE

+86 15972186287
